SDO HMI 2014-05-18 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 46.58 | 256.57 | 25.50 | 140.41 | -24.18 | 191.39 | 12.75 | 208.30 | 0.4265 | 815.2 | 358.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-18 08:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.42 | 246.13 | 6.26 | 134.75 | -24.19 | 191.90 | 13.26 | 209.24 | 0.4302 | 1203.1 | 409.1 | |
| 4.14 | -1.00 | 2.26 | -1.00 | -23.86 | 191.83 | 13.19 | 209.53 | 0.4253 | 1257.8 | 999999 | |
| 30.48 | -1.00 | 16.69 | -1.00 | -24.19 | 191.52 | 12.89 | 208.56 | 0.4273 | 1300.7 | 999999 | |
| 0.54 | -1.00 | 0.29 | -1.00 | -23.90 | 190.54 | 11.90 | 207.07 | 0.4161 | 969.2 | 999999 | |
| 0.00 | 0.90 | 0.00 | 0.49 | -22.73 | 190.30 | 11.67 | 208.06 | 0.3982 | 685.0 | 544.3 | |
| 0.00 | 1.08 | 0.00 | 0.58 | -24.15 | 187.22 | 8.58 | 200.08 | 0.3984 | -807.0 | -689.4 | |
| 0.00 | 1.26 | 0.00 | 0.68 | -24.25 | 186.72 | 8.09 | 198.92 | 0.3972 | -851.0 | -755.9 | |
| 0.00 | 2.52 | 0.00 | 1.36 | -24.12 | 186.55 | 7.91 | 198.65 | 0.3944 | -971.0 | -812.9 | |
| 0.00 | 1.26 | 0.00 | 0.68 | -24.35 | 186.56 | 7.92 | 198.48 | 0.3979 | -819.0 | -742.4 | |
| 0.00 | 1.08 | 0.00 | 0.59 | -25.73 | 185.67 | 7.03 | 195.48 | 0.4147 | -947.0 | -781.9 | |
| 0.00 | 1.08 | 0.00 | 0.60 | -27.94 | 184.56 | 5.92 | 191.89 | 0.4443 | -700.0 | -575.0 | |
| 0.00 | 1.26 | 0.00 | 0.68 | -25.94 | 183.75 | 5.11 | 191.29 | 0.4108 | -797.0 | -610.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
