SDO HMI 2014-05-18 18:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.36 | 269.27 | 22.66 | 151.25 | -24.36 | 190.98 | 17.84 | 216.44 | 0.4723 | 694.9 | 320.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-18 18:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37.84 | 251.38 | 21.26 | 141.29 | -24.24 | 191.38 | 18.24 | 217.21 | 0.4740 | 1279.1 | 392.2 | |
| 2.52 | -1.00 | 1.40 | -1.00 | -23.89 | 190.59 | 17.46 | 216.55 | 0.4626 | 988.1 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.35 | -22.79 | 189.86 | 16.73 | 217.01 | 0.4427 | -529.0 | -489.1 | |
| 0.00 | 1.08 | 0.00 | 0.60 | -25.01 | 189.60 | 16.47 | 213.50 | 0.4673 | 622.0 | 504.2 | |
| 0.00 | 4.94 | 0.00 | 2.72 | -24.65 | 186.34 | 13.21 | 208.55 | 0.4363 | -770.0 | -668.1 | |
| 0.00 | 1.35 | 0.00 | 0.75 | -25.84 | 185.68 | 12.54 | 206.01 | 0.4476 | -867.0 | -604.9 | |
| 0.00 | 1.08 | 0.00 | 0.60 | -26.01 | 185.45 | 12.32 | 205.43 | 0.4484 | -790.0 | -550.7 | |
| 0.00 | 3.95 | 0.00 | 2.21 | -27.44 | 185.40 | 12.27 | 203.87 | 0.4678 | -558.0 | -576.5 | |
| 0.00 | 1.26 | 0.00 | 0.72 | -30.36 | 185.68 | 12.55 | 201.68 | 0.5095 | -749.0 | -582.9 | |
| 0.00 | 1.44 | 0.00 | 0.81 | -27.98 | 185.22 | 12.08 | 203.04 | 0.4741 | -705.0 | -533.6 | |
| 0.00 | 1.08 | 0.00 | 0.60 | -27.75 | 184.52 | 11.39 | 202.08 | 0.4668 | -738.0 | -578.8 | |
| 0.00 | 1.08 | 0.00 | 0.60 | -27.01 | 184.38 | 11.25 | 202.51 | 0.4556 | -798.0 | -660.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
