SDO HMI 2014-05-18 23:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.53 | 11.42 | 0.80 | 6.03 | -17.00 | 156.39 | -13.97 | 138.44 | 0.3467 | -511.3 | -17.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-18 23:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.53 | 6.11 | 0.80 | 3.19 | -16.58 | 158.88 | -11.48 | 142.48 | 0.3144 | 1156.1 | 812.4 | |
| 0.00 | 1.08 | 0.00 | 0.57 | -16.58 | 155.60 | -14.76 | 135.54 | 0.3501 | -901.0 | -776.6 | |
| 0.00 | 1.71 | 0.00 | 0.92 | -17.68 | 153.19 | -17.17 | 133.60 | 0.3900 | -899.0 | -788.5 | |
| 0.00 | 1.08 | 0.00 | 0.58 | -17.46 | 153.08 | -17.28 | 132.99 | 0.3890 | -814.0 | -713.4 | |
| 0.00 | 1.44 | 0.00 | 0.77 | -17.90 | 153.00 | -17.36 | 133.73 | 0.3945 | -765.0 | -588.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
