SDO HMI 2014-05-21 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.10 | 175.19 | 22.05 | 142.05 | -24.90 | 189.96 | 48.82 | 239.61 | 0.7936 | 549.1 | 239.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-21 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.10 | 166.82 | 22.05 | 135.74 | -24.82 | 190.19 | 49.05 | 239.80 | 0.7954 | 955.1 | 278.7 | |
| 0.00 | 0.90 | 0.00 | 0.68 | -25.81 | 185.91 | 44.76 | 236.91 | 0.7589 | -486.0 | -435.4 | |
| 0.00 | 0.99 | 0.00 | 0.75 | -25.78 | 185.70 | 44.56 | 236.86 | 0.7568 | -651.0 | -494.7 | |
| 0.00 | 0.72 | 0.00 | 0.54 | -25.40 | 185.10 | 43.95 | 237.06 | 0.7494 | -620.0 | -544.6 | |
| 0.00 | 1.44 | 0.00 | 1.08 | -25.69 | 185.19 | 44.04 | 236.74 | 0.7515 | -700.0 | -557.4 | |
| 0.00 | 1.53 | 0.00 | 1.15 | -26.33 | 185.35 | 44.20 | 236.03 | 0.7558 | -535.0 | -414.4 | |
| 0.00 | 0.90 | 0.00 | 0.69 | -27.53 | 185.61 | 44.47 | 234.68 | 0.7636 | -473.0 | -388.7 | |
| 0.00 | 1.08 | 0.00 | 0.81 | -28.52 | 183.88 | 42.73 | 232.65 | 0.7522 | -606.0 | -509.3 | |
| 0.00 | 0.81 | 0.00 | 0.61 | -28.76 | 183.76 | 42.62 | 232.31 | 0.7524 | -489.0 | -418.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
