SDO HMI 2014-05-21 19:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.07 | 41.94 | 13.15 | 49.61 | -18.13 | 197.30 | 64.41 | 250.88 | 0.9084 | 305.9 | 10.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-21 19:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.24 | 22.68 | 3.98 | 28.13 | -18.53 | 198.40 | 65.51 | 250.57 | 0.9167 | 538.0 | -114.8 | |
| 3.42 | -1.00 | 4.22 | -1.00 | -18.75 | 198.49 | 65.60 | 250.34 | 0.9174 | 375.7 | 999999 | |
| 2.16 | 4.59 | 2.56 | 5.44 | -18.01 | 197.50 | 64.60 | 251.03 | 0.9102 | 553.6 | 449.2 | |
| 0.54 | 3.06 | 0.63 | 3.58 | -17.70 | 197.21 | 64.32 | 251.33 | 0.9080 | 508.5 | 346.2 | |
| 0.00 | 3.33 | 0.00 | 3.94 | -18.46 | 197.43 | 64.54 | 250.53 | 0.9101 | 401.0 | 391.7 | |
| 0.00 | 0.54 | 0.00 | 0.60 | -17.43 | 195.53 | 62.64 | 251.43 | 0.8957 | 285.0 | 275.0 | |
| 0.45 | 1.62 | 0.49 | 1.78 | -18.11 | 195.18 | 62.29 | 250.63 | 0.8938 | -377.2 | -239.8 | |
| 0.00 | 1.62 | 0.00 | 1.60 | -14.94 | 192.25 | 59.35 | 253.82 | 0.8675 | 474.0 | 378.1 | |
| 1.26 | 4.50 | 1.27 | 4.54 | -16.37 | 192.74 | 59.85 | 252.25 | 0.8731 | -642.0 | -501.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
