SDO HMI 2014-05-22 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 64.57 | 236.83 | 49.30 | 179.93 | -11.18 | 79.18 | -48.74 | 103.18 | 0.7586 | -178.0 | -33.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-22 04:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.53 | 0.00 | 1.06 | -10.74 | 83.97 | -43.94 | 103.47 | 0.7034 | 690.0 | 619.6 | |
| 17.11 | 67.46 | 11.91 | 46.94 | -9.90 | 83.73 | -44.18 | 102.24 | 0.7048 | 950.5 | 415.1 | |
| 0.27 | -2.00 | 0.19 | -2.00 | -10.27 | 83.58 | -44.33 | 102.73 | 0.7072 | 622.0 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.57 | -8.60 | 83.12 | -44.79 | 100.31 | 0.7103 | -510.0 | -460.2 | |
| 0.00 | 0.54 | 0.00 | 0.38 | -10.40 | 82.60 | -45.32 | 102.73 | 0.7192 | 290.0 | 279.2 | |
| 0.00 | 0.99 | 0.00 | 0.72 | -11.82 | 81.23 | -46.68 | 104.41 | 0.7376 | 596.0 | 413.2 | |
| 0.00 | 2.52 | 0.00 | 1.84 | -10.65 | 81.26 | -46.66 | 102.83 | 0.7354 | 65.0 | 171.4 | |
| 0.00 | 2.52 | 0.00 | 1.84 | -11.01 | 81.14 | -46.78 | 103.30 | 0.7373 | 638.0 | 441.6 | |
| 0.00 | 1.89 | 0.00 | 1.40 | -12.18 | 80.74 | -47.18 | 104.79 | 0.7438 | 735.0 | 516.0 | |
| 0.81 | 2.52 | 0.60 | 1.87 | -12.30 | 80.66 | -47.25 | 104.94 | 0.7449 | 619.2 | 485.6 | |
| 0.00 | 0.81 | 0.00 | 0.62 | -13.92 | 79.54 | -48.37 | 106.83 | 0.7603 | 346.0 | 307.9 | |
| 0.00 | 1.35 | 0.00 | 1.02 | -12.33 | 79.40 | -48.52 | 104.73 | 0.7590 | 442.0 | 325.0 | |
| 0.90 | 2.16 | 0.68 | 1.64 | -12.02 | 79.24 | -48.67 | 104.30 | 0.7602 | 571.7 | 404.8 | |
| 2.43 | 7.20 | 1.87 | 5.53 | -12.32 | 78.74 | -49.18 | 104.59 | 0.7662 | 609.7 | 305.5 | |
| 2.34 | -14.00 | 1.80 | -14.00 | -12.41 | 78.67 | -49.25 | 104.70 | 0.7671 | 422.6 | 999999 | |
| 0.00 | 1.17 | 0.00 | 0.89 | -11.09 | 78.99 | -48.93 | 103.03 | 0.7616 | -673.0 | -602.6 | |
| 0.00 | 1.17 | 0.00 | 0.89 | -10.23 | 79.13 | -48.79 | 101.93 | 0.7589 | -495.0 | -381.4 | |
| 0.81 | 5.13 | 0.62 | 3.91 | -10.77 | 78.82 | -49.09 | 102.60 | 0.7630 | -577.6 | -595.3 | |
| 0.00 | 0.99 | 0.00 | 0.76 | -12.15 | 78.45 | -49.47 | 104.33 | 0.7692 | -277.0 | -264.2 | |
| 0.00 | 1.17 | 0.00 | 0.92 | -12.69 | 77.43 | -50.49 | 104.84 | 0.7808 | -679.0 | -540.0 | |
| 26.48 | 80.78 | 20.84 | 63.65 | -11.35 | 77.39 | -50.53 | 103.13 | 0.7794 | -904.8 | -292.0 | |
| 0.00 | 2.61 | 0.00 | 2.08 | -12.80 | 76.90 | -51.01 | 104.89 | 0.7865 | -458.0 | -430.8 | |
| 1.44 | 51.51 | 1.15 | 41.40 | -12.39 | 76.72 | -51.20 | 104.34 | 0.7879 | -792.8 | -218.2 | |
| 2.43 | -23.00 | 1.95 | -23.00 | -11.77 | 76.64 | -51.28 | 103.54 | 0.7879 | -772.9 | 999999 | |
| 9.55 | -23.00 | 7.69 | -23.00 | -11.98 | 76.43 | -51.48 | 103.78 | 0.7903 | -682.0 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
