SDO HMI 2014-05-22 20:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.68 | 114.06 | 18.76 | 94.74 | -10.80 | 66.11 | -52.99 | 102.14 | 0.8043 | 654.7 | 266.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-22 20:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.54 | 101.01 | 7.83 | 82.97 | -10.71 | 66.60 | -52.50 | 102.09 | 0.7995 | 868.2 | 285.3 | |
| 0.00 | 0.99 | 0.00 | 0.80 | -8.72 | 67.05 | -52.06 | 99.65 | 0.7929 | -429.0 | -383.5 | |
| 11.79 | -1.00 | 9.69 | -1.00 | -10.46 | 66.56 | -52.54 | 101.78 | 0.7996 | 913.8 | 999999 | |
| 0.00 | 1.62 | 0.00 | 1.36 | -12.58 | 65.88 | -53.23 | 104.30 | 0.8090 | 421.0 | 376.5 | |
| 0.00 | 1.71 | 0.00 | 1.44 | -13.10 | 65.72 | -53.39 | 104.92 | 0.8113 | 257.0 | 321.9 | |
| 0.27 | -1.00 | 0.22 | -1.00 | -10.92 | 66.19 | -52.92 | 102.29 | 0.8039 | 225.7 | 999999 | |
| 0.00 | 0.99 | 0.00 | 0.84 | -12.63 | 65.39 | -53.71 | 104.29 | 0.8139 | 323.0 | 251.7 | |
| 0.00 | 1.08 | 0.00 | 0.94 | -14.20 | 64.71 | -54.40 | 106.10 | 0.8226 | 506.0 | 367.3 | |
| 0.00 | 1.08 | 0.00 | 0.97 | -13.66 | 63.20 | -55.91 | 105.22 | 0.8361 | 297.0 | 294.8 | |
| 0.54 | 3.33 | 0.51 | 3.17 | -11.15 | 60.83 | -58.27 | 101.98 | 0.8551 | 575.3 | 477.7 | |
| 0.54 | -10.00 | 0.51 | -10.00 | -11.27 | 60.79 | -58.31 | 102.12 | 0.8556 | 567.2 | 999999 | |
| 0.00 | 2.25 | 0.00 | 2.25 | -12.75 | 59.16 | -59.94 | 103.66 | 0.8708 | -364.0 | -383.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
