SDO HMI 2014-05-23 11:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 80.26 | 274.31 | 46.99 | 160.92 | -11.13 | 79.84 | -31.02 | 108.45 | 0.5338 | 12.8 | -8.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-23 11:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.68 | 84.24 | 2.61 | 46.86 | -10.20 | 84.79 | -26.06 | 109.22 | 0.4597 | 858.2 | 460.2 | |
| 21.08 | -1.00 | 11.74 | -1.00 | -9.86 | 84.79 | -26.06 | 108.50 | 0.4583 | 1098.3 | 999999 | |
| 0.00 | 1.17 | 0.00 | 0.67 | -10.87 | 82.71 | -28.14 | 109.37 | 0.4929 | 775.0 | 563.4 | |
| 0.00 | 1.35 | 0.00 | 0.77 | -10.56 | 82.47 | -28.39 | 108.63 | 0.4952 | 878.0 | 690.2 | |
| 0.00 | 0.99 | 0.00 | 0.57 | -11.05 | 82.17 | -28.68 | 109.41 | 0.5015 | 770.0 | 632.6 | |
| 0.00 | 1.71 | 0.00 | 0.98 | -11.05 | 81.96 | -28.90 | 109.29 | 0.5045 | 798.0 | 615.6 | |
| 5.86 | 20.54 | 3.37 | 11.81 | -11.66 | 81.82 | -29.04 | 110.38 | 0.5091 | 1004.1 | 659.7 | |
| 3.87 | -7.00 | 2.23 | -7.00 | -11.91 | 81.79 | -29.06 | 110.83 | 0.5106 | 916.2 | 999999 | |
| 1.98 | -7.00 | 1.14 | -7.00 | -11.54 | 81.65 | -29.20 | 110.06 | 0.5109 | 745.1 | 999999 | |
| 0.00 | 1.80 | 0.00 | 1.03 | -10.61 | 81.68 | -29.17 | 108.32 | 0.5066 | 737.0 | 562.2 | |
| 0.00 | 1.53 | 0.00 | 0.88 | -10.76 | 81.53 | -29.33 | 108.53 | 0.5095 | 675.0 | 520.6 | |
| 0.00 | 0.81 | 0.00 | 0.47 | -10.70 | 81.32 | -29.53 | 108.30 | 0.5122 | 808.0 | 692.3 | |
| 0.00 | 2.88 | 0.00 | 1.67 | -11.56 | 80.94 | -29.91 | 109.71 | 0.5210 | 680.0 | 614.2 | |
| 0.00 | 0.45 | 0.00 | 0.26 | -10.63 | 81.01 | -29.84 | 108.02 | 0.5164 | 586.0 | 475.6 | |
| 0.00 | 2.34 | 0.00 | 1.37 | -11.82 | 80.11 | -30.74 | 109.77 | 0.5337 | 697.0 | 470.6 | |
| 0.00 | 2.34 | 0.00 | 1.38 | -11.44 | 79.22 | -31.63 | 108.64 | 0.5446 | -850.0 | -727.5 | |
| 0.00 | 1.26 | 0.00 | 0.75 | -11.56 | 79.06 | -31.79 | 108.78 | 0.5473 | -774.0 | -709.9 | |
| 0.00 | 1.44 | 0.00 | 0.86 | -12.51 | 78.93 | -31.92 | 110.40 | 0.5529 | -556.0 | -485.8 | |
| 0.90 | 2.16 | 0.53 | 1.28 | -10.93 | 78.51 | -32.34 | 107.43 | 0.5526 | -828.2 | -726.0 | |
| 0.00 | 2.16 | 0.00 | 1.29 | -11.08 | 78.13 | -32.72 | 107.53 | 0.5585 | -722.0 | -496.8 | |
| 9.91 | 69.01 | 5.94 | 41.49 | -10.98 | 77.59 | -33.26 | 107.13 | 0.5656 | -1081.6 | -395.3 | |
| 6.40 | -21.00 | 3.85 | -21.00 | -11.19 | 77.23 | -33.63 | 107.35 | 0.5713 | -939.5 | 999999 | |
| 0.00 | 2.25 | 0.00 | 1.37 | -12.54 | 76.99 | -33.86 | 109.54 | 0.5792 | -835.0 | -681.3 | |
| 3.78 | -21.00 | 2.28 | -21.00 | -11.37 | 77.13 | -33.73 | 107.62 | 0.5733 | -795.6 | 999999 | |
| 0.90 | -21.00 | 0.54 | -21.00 | -11.37 | 76.94 | -33.91 | 107.54 | 0.5758 | -647.2 | 999999 | |
| 5.05 | 73.88 | 3.07 | 45.16 | -12.26 | 76.55 | -34.30 | 108.87 | 0.5842 | -1033.0 | -273.9 | |
| 2.70 | -26.00 | 1.65 | -26.00 | -12.01 | 76.55 | -34.30 | 108.46 | 0.5833 | -900.5 | 999999 | |
| 13.15 | -26.00 | 8.04 | -26.00 | -12.16 | 76.26 | -34.59 | 108.59 | 0.5877 | -868.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
