SDO HMI 2014-05-24 02:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.28 | 124.16 | 21.69 | 92.19 | -18.35 | 148.54 | 45.99 | 246.53 | 0.7459 | 288.5 | 192.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-24 02:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.72 | 0.00 | 0.63 | -19.04 | 156.05 | 53.49 | 247.80 | 0.8228 | 434.0 | 347.6 | |
| 0.00 | 0.81 | 0.00 | 0.65 | -18.93 | 152.11 | 49.55 | 246.92 | 0.7847 | 73.0 | 56.6 | |
| 0.00 | 1.53 | 0.00 | 1.19 | -16.85 | 151.28 | 48.72 | 249.31 | 0.7711 | 556.0 | 447.2 | |
| 0.90 | 2.25 | 0.70 | 1.75 | -17.23 | 151.36 | 48.81 | 248.85 | 0.7729 | 579.8 | 443.1 | |
| 4.33 | 17.57 | 3.42 | 13.91 | -18.75 | 151.83 | 49.28 | 247.07 | 0.7815 | 722.3 | 344.9 | |
| 0.00 | 1.08 | 0.00 | 0.83 | -17.08 | 150.73 | 48.18 | 248.86 | 0.7660 | 568.0 | 440.2 | |
| 0.00 | 4.33 | 0.00 | 3.38 | -18.88 | 151.30 | 48.74 | 246.75 | 0.7764 | 689.0 | 542.6 | |
| 1.62 | 4.24 | 1.26 | 3.28 | -18.80 | 150.87 | 48.32 | 246.73 | 0.7719 | 618.7 | 573.7 | |
| 0.00 | 0.90 | 0.00 | 0.69 | -18.20 | 150.60 | 48.05 | 247.41 | 0.7675 | 526.0 | 456.4 | |
| 0.63 | 2.34 | 0.48 | 1.77 | -17.42 | 149.71 | 47.15 | 248.14 | 0.7560 | 730.7 | 654.7 | |
| 0.00 | 1.17 | 0.00 | 0.90 | -19.03 | 150.19 | 47.64 | 246.22 | 0.7656 | 598.0 | 509.7 | |
| 0.00 | 1.53 | 0.00 | 1.14 | -17.08 | 149.13 | 46.58 | 248.40 | 0.7489 | 678.0 | 572.1 | |
| 0.00 | 1.71 | 0.00 | 1.29 | -18.22 | 149.33 | 46.77 | 246.99 | 0.7542 | 510.0 | 502.4 | |
| 1.80 | 4.60 | 1.34 | 3.43 | -17.97 | 148.96 | 46.41 | 247.20 | 0.7496 | 557.7 | 368.2 | |
| 0.00 | 1.71 | 0.00 | 1.26 | -17.95 | 148.45 | 45.89 | 247.06 | 0.7440 | 284.0 | 271.6 | |
| 5.14 | 12.08 | 3.83 | 9.03 | -18.96 | 148.75 | 46.20 | 245.85 | 0.7503 | 595.5 | 357.5 | |
| 0.00 | 1.17 | 0.00 | 0.83 | -14.26 | 147.02 | 44.46 | 251.55 | 0.7179 | 440.0 | 381.9 | |
| 1.17 | 3.96 | 0.86 | 2.90 | -18.44 | 147.88 | 45.32 | 246.23 | 0.7394 | -409.6 | -313.3 | |
| 0.81 | 13.07 | 0.59 | 9.42 | -17.46 | 147.42 | 44.87 | 247.37 | 0.7314 | -437.9 | -487.6 | |
| 0.63 | -19.00 | 0.46 | -19.00 | -17.62 | 147.34 | 44.78 | 247.13 | 0.7310 | -458.1 | 999999 | |
| 0.00 | 1.26 | 0.00 | 0.91 | -17.81 | 147.35 | 44.80 | 246.88 | 0.7317 | 171.0 | 79.6 | |
| 2.88 | 4.87 | 2.09 | 3.53 | -18.38 | 147.31 | 44.76 | 246.11 | 0.7331 | -592.9 | -379.5 | |
| 0.63 | -19.00 | 0.45 | -19.00 | -17.95 | 146.95 | 44.39 | 246.56 | 0.7277 | -610.1 | 999999 | |
| 0.00 | 1.80 | 0.00 | 1.34 | -21.07 | 147.82 | 45.26 | 242.81 | 0.7475 | 590.0 | 479.8 | |
| 0.00 | 1.17 | 0.00 | 0.86 | -20.56 | 147.49 | 44.93 | 243.34 | 0.7422 | 431.0 | 364.5 | |
| 0.00 | 1.80 | 0.00 | 1.31 | -19.92 | 147.16 | 44.61 | 244.04 | 0.7366 | 564.0 | 480.0 | |
| 5.50 | 30.37 | 3.92 | 21.64 | -17.86 | 146.34 | 43.78 | 246.46 | 0.7207 | -620.0 | 55.4 | |
| 1.89 | -27.00 | 1.34 | -27.00 | -18.22 | 146.01 | 43.45 | 245.86 | 0.7182 | 645.2 | 999999 | |
| 0.00 | 0.63 | 0.00 | 0.44 | -17.82 | 145.40 | 42.85 | 246.18 | 0.7100 | 525.0 | 480.4 | |
| 0.00 | 0.81 | 0.00 | 0.58 | -19.59 | 145.79 | 43.23 | 243.94 | 0.7206 | 617.0 | 488.3 | |
| 0.00 | 1.17 | 0.00 | 0.83 | -19.76 | 145.18 | 42.63 | 243.47 | 0.7146 | 525.0 | 488.0 | |
| 0.00 | 0.99 | 0.00 | 0.70 | -19.64 | 145.01 | 42.45 | 243.57 | 0.7123 | 300.0 | 325.4 | |
| 1.35 | 2.52 | 0.95 | 1.77 | -19.71 | 144.64 | 42.08 | 243.32 | 0.7085 | 768.8 | 635.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
