SDO HMI 2014-05-24 22:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.54 | 215.04 | 20.73 | 109.94 | -10.58 | 81.09 | -10.45 | 133.47 | 0.2415 | 121.9 | -6.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-24 22:00:38 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.08 | 70.10 | 0.54 | 35.28 | -10.08 | 86.11 | -5.43 | 147.88 | 0.1761 | 986.5 | 485.6 | |
| 17.21 | -1.00 | 8.66 | -1.00 | -10.02 | 85.77 | -5.77 | 146.11 | 0.1784 | 1313.8 | 999999 | |
| 0.00 | 0.99 | 0.00 | 0.50 | -10.33 | 85.26 | -6.27 | 144.85 | 0.1876 | 641.0 | 488.7 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -11.43 | 84.71 | -6.83 | 145.84 | 0.2085 | 933.0 | 659.8 | |
| 0.00 | 1.53 | 0.00 | 0.78 | -11.71 | 84.67 | -6.87 | 146.45 | 0.2128 | 716.0 | 585.1 | |
| 0.00 | 1.17 | 0.00 | 0.59 | -11.71 | 84.48 | -7.05 | 145.74 | 0.2146 | 983.0 | 818.6 | |
| 0.00 | 2.07 | 0.00 | 1.05 | -10.44 | 84.08 | -7.46 | 140.49 | 0.2015 | 910.0 | 766.2 | |
| 0.00 | 1.35 | 0.00 | 0.68 | -10.01 | 83.87 | -7.66 | 138.29 | 0.1983 | 986.0 | 890.3 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -10.63 | 83.83 | -7.71 | 140.14 | 0.2067 | 786.0 | 616.2 | |
| 0.00 | 2.79 | 0.00 | 1.41 | -10.01 | 83.19 | -8.35 | 135.86 | 0.2063 | 844.0 | 680.7 | |
| 0.00 | 1.89 | 0.00 | 0.96 | -10.13 | 82.22 | -9.32 | 133.15 | 0.2195 | 877.0 | 749.4 | |
| 0.00 | 1.89 | 0.00 | 0.96 | -10.65 | 81.98 | -9.56 | 134.17 | 0.2285 | 977.0 | 721.1 | |
| 0.00 | 0.99 | 0.00 | 0.50 | -10.06 | 81.94 | -9.60 | 132.11 | 0.2223 | 801.0 | 653.4 | |
| 0.00 | 3.51 | 0.00 | 1.79 | -10.43 | 81.58 | -9.96 | 132.31 | 0.2309 | 927.0 | 709.8 | |
| 0.00 | 1.80 | 0.00 | 0.92 | -10.03 | 81.03 | -10.51 | 129.47 | 0.2336 | 972.0 | 859.5 | |
| 0.99 | 19.55 | 0.51 | 9.98 | -10.37 | 80.93 | -10.61 | 130.31 | 0.2386 | 1095.6 | 761.8 | |
| 0.99 | -16.00 | 0.51 | -16.00 | -10.12 | 80.78 | -10.76 | 129.11 | 0.2379 | 1072.1 | 999999 | |
| 1.35 | -16.00 | 0.69 | -16.00 | -10.42 | 80.55 | -10.99 | 129.53 | 0.2442 | 1018.9 | 999999 | |
| 0.00 | 2.25 | 0.00 | 1.15 | -10.21 | 80.40 | -11.14 | 128.46 | 0.2439 | 789.0 | 616.1 | |
| 2.07 | 33.25 | 1.06 | 17.04 | -9.80 | 79.09 | -12.45 | 124.16 | 0.2578 | -1255.3 | -591.3 | |
| 0.00 | 2.43 | 0.00 | 1.25 | -10.41 | 78.69 | -12.85 | 125.27 | 0.2691 | -1165.0 | -918.8 | |
| 0.00 | 1.35 | 0.00 | 0.70 | -10.87 | 78.06 | -13.47 | 125.40 | 0.2820 | -756.0 | -556.3 | |
| 3.69 | 26.40 | 1.91 | 13.68 | -11.05 | 77.74 | -13.80 | 125.30 | 0.2882 | -1176.1 | -872.5 | |
| 0.00 | 1.17 | 0.00 | 0.60 | -7.83 | 77.59 | -13.95 | 114.76 | 0.2642 | -916.0 | -782.9 | |
| 0.00 | 1.89 | 0.00 | 0.99 | -12.68 | 77.36 | -14.18 | 129.06 | 0.3091 | -746.0 | -627.5 | |
| 5.95 | -23.00 | 3.09 | -23.00 | -11.32 | 77.18 | -14.36 | 125.05 | 0.2983 | -1022.3 | 999999 | |
| 0.00 | 0.99 | 0.00 | 0.51 | -7.86 | 77.33 | -14.20 | 114.49 | 0.2683 | -949.0 | -869.4 | |
| 0.00 | 1.08 | 0.00 | 0.56 | -9.42 | 77.14 | -14.39 | 119.32 | 0.2825 | -725.0 | -565.6 | |
| 0.00 | 1.08 | 0.00 | 0.56 | -12.12 | 76.94 | -14.59 | 126.81 | 0.3090 | -932.0 | -750.9 | |
| 0.63 | 23.34 | 0.33 | 12.18 | -12.34 | 76.90 | -14.64 | 127.29 | 0.3117 | -1131.0 | -653.3 | |
| 0.00 | 2.79 | 0.00 | 1.45 | -11.97 | 76.79 | -14.75 | 126.12 | 0.3096 | -1084.0 | -889.5 | |
| 6.58 | -30.00 | 3.43 | -30.00 | -12.21 | 76.55 | -14.99 | 126.34 | 0.3151 | -1142.8 | 999999 | |
| 0.00 | 0.81 | 0.00 | 0.42 | -10.61 | 76.10 | -15.44 | 121.18 | 0.3072 | -799.0 | -574.9 | |
| 0.00 | 4.42 | 0.00 | 2.35 | -13.39 | 73.32 | -18.22 | 124.18 | 0.3692 | -56.0 | -170.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
