SDO HMI 2014-05-26 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.90 | 99.36 | 12.38 | 51.01 | -10.61 | 82.25 | 11.64 | 229.24 | 0.2618 | 183.9 | 27.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-26 12:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 19.75 | 35.17 | 10.27 | 18.30 | -9.92 | 86.22 | 15.61 | 240.49 | 0.3059 | 1210.5 | 521.9 | |
| 0.00 | 1.80 | 0.00 | 0.93 | -10.57 | 84.88 | 14.26 | 236.38 | 0.2922 | 877.0 | 695.2 | |
| 0.00 | 0.99 | 0.00 | 0.51 | -11.10 | 84.36 | 13.75 | 233.90 | 0.2899 | 821.0 | 625.8 | |
| 0.00 | 1.53 | 0.00 | 0.79 | -10.70 | 83.86 | 13.25 | 234.08 | 0.2794 | 602.0 | 547.6 | |
| 0.00 | 1.26 | 0.00 | 0.65 | -10.80 | 82.82 | 12.21 | 231.59 | 0.2663 | 796.0 | 716.8 | |
| 0.00 | 1.89 | 0.00 | 0.97 | -10.49 | 82.72 | 12.10 | 232.29 | 0.2618 | 752.0 | 764.2 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -10.06 | 82.64 | 12.02 | 233.46 | 0.2565 | 941.0 | 778.4 | |
| 0.00 | 11.18 | 0.00 | 5.72 | -10.06 | 82.35 | 11.74 | 232.81 | 0.2526 | 1233.0 | 932.3 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -10.52 | 82.18 | 11.57 | 230.95 | 0.2550 | 860.0 | 573.7 | |
| 0.00 | 2.80 | 0.00 | 1.43 | -10.06 | 81.54 | 10.92 | 230.83 | 0.2417 | 915.0 | 710.2 | |
| 1.08 | 2.44 | 0.55 | 1.24 | -9.85 | 81.06 | 10.45 | 230.31 | 0.2332 | 1144.0 | 856.9 | |
| 0.00 | 3.34 | 0.00 | 1.70 | -11.02 | 80.94 | 10.33 | 226.26 | 0.2447 | -821.0 | -715.9 | |
| 0.00 | 1.80 | 0.00 | 0.92 | -11.85 | 80.21 | 9.60 | 221.78 | 0.2461 | -1070.0 | -867.2 | |
| 0.00 | 1.35 | 0.00 | 0.69 | -12.13 | 80.19 | 9.58 | 220.95 | 0.2493 | -778.0 | -591.4 | |
| 0.00 | 1.62 | 0.00 | 0.82 | -9.88 | 79.99 | 9.38 | 227.19 | 0.2199 | -901.0 | -729.2 | |
| 0.00 | 1.35 | 0.00 | 0.69 | -11.79 | 79.71 | 9.10 | 220.43 | 0.2397 | -922.0 | -677.1 | |
| 0.00 | 1.44 | 0.00 | 0.73 | -9.55 | 79.55 | 8.94 | 226.99 | 0.2105 | -927.0 | -726.2 | |
| 0.00 | 3.16 | 0.00 | 1.61 | -12.10 | 79.53 | 8.92 | 219.04 | 0.2417 | -961.0 | -769.1 | |
| 0.00 | 1.17 | 0.00 | 0.59 | -9.73 | 79.24 | 8.63 | 225.35 | 0.2088 | -938.0 | -707.4 | |
| 0.00 | 1.17 | 0.00 | 0.60 | -12.41 | 79.07 | 8.46 | 216.76 | 0.2410 | -848.0 | -590.3 | |
| 0.00 | 3.79 | 0.00 | 1.93 | -11.98 | 78.05 | 7.44 | 214.43 | 0.2250 | -900.0 | -796.2 | |
| 0.00 | 7.76 | 0.00 | 3.93 | -11.06 | 77.87 | 7.26 | 216.30 | 0.2105 | -952.0 | -800.7 | |
| 3.07 | 4.87 | 1.56 | 2.47 | -12.17 | 77.09 | 6.47 | 210.39 | 0.2188 | -1110.1 | -868.7 | |
| 0.00 | 3.25 | 0.00 | 1.64 | -11.55 | 76.29 | 5.68 | 208.68 | 0.2030 | -931.0 | -730.7 | |
| 0.00 | 1.08 | 0.00 | 0.55 | -12.32 | 73.63 | 3.02 | 195.10 | 0.1982 | -784.0 | -687.0 | |
| 0.00 | 0.99 | 0.00 | 0.50 | -13.94 | 73.18 | 2.56 | 191.26 | 0.2233 | -886.0 | -661.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
