SDO HMI 2014-05-26 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.22 | 104.23 | 73.14 | 398.37 | -18.87 | 150.73 | 82.33 | 251.08 | 0.9893 | -109.2 | -49.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-26 16:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.93 | 37.42 | 53.96 | 243.07 | -18.61 | 153.89 | 85.49 | 251.43 | 0.9970 | -164.2 | -71.4 | |
| 1.08 | 4.96 | 3.39 | 15.28 | -17.44 | 149.20 | 80.80 | 252.55 | 0.9879 | 476.3 | 225.1 | |
| 0.00 | 2.34 | 0.00 | 10.04 | -18.56 | 151.94 | 83.53 | 251.47 | 0.9940 | 325.0 | 290.7 | |
| 3.07 | 11.99 | 6.93 | 27.72 | -17.64 | 145.60 | 77.20 | 252.22 | 0.9769 | -102.1 | -182.7 | |
| 0.00 | 1.80 | 0.00 | 3.94 | -17.97 | 145.06 | 76.66 | 251.85 | 0.9750 | -291.0 | -251.2 | |
| 0.00 | 3.25 | 0.00 | 7.17 | -18.90 | 145.11 | 76.70 | 250.91 | 0.9753 | 493.0 | 420.7 | |
| 0.00 | 1.44 | 0.00 | 3.04 | -18.88 | 144.52 | 76.12 | 250.89 | 0.9732 | 508.0 | 486.6 | |
| 1.35 | 9.56 | 2.84 | 20.24 | -19.14 | 144.48 | 76.07 | 250.63 | 0.9730 | 529.9 | 251.0 | |
| 2.79 | 22.27 | 6.02 | 47.86 | -20.33 | 144.72 | 76.32 | 249.42 | 0.9742 | -554.0 | -392.0 | |
| 0.00 | 9.20 | 0.00 | 20.01 | -21.47 | 144.71 | 76.31 | 248.25 | 0.9745 | 214.0 | 199.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
