SDO HMI 2014-05-27 06:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.82 | 56.58 | 29.43 | 128.27 | -14.54 | 137.76 | 77.09 | 255.36 | 0.9756 | 187.5 | 108.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-27 06:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.99 | 35.37 | 5.08 | 88.06 | -14.37 | 139.38 | 78.71 | 255.60 | 0.9817 | -154.7 | 109.1 | |
| 1.26 | -1.00 | 3.24 | -1.00 | -14.59 | 139.34 | 78.67 | 255.37 | 0.9816 | -147.4 | 999999 | |
| 6.41 | -1.00 | 15.49 | -1.00 | -14.60 | 138.72 | 78.05 | 255.34 | 0.9795 | 556.9 | 999999 | |
| 0.00 | 1.53 | 0.00 | 2.88 | -13.67 | 135.18 | 74.51 | 256.17 | 0.9655 | 28.0 | 37.5 | |
| 0.00 | 2.80 | 0.00 | 5.05 | -13.34 | 134.54 | 73.87 | 256.48 | 0.9626 | -24.0 | -12.6 | |
| 0.00 | 1.99 | 0.00 | 5.02 | -17.47 | 139.26 | 78.59 | 252.43 | 0.9816 | 118.0 | 131.7 | |
| 0.00 | 1.53 | 0.00 | 2.84 | -14.33 | 134.95 | 74.28 | 255.47 | 0.9646 | 163.0 | 94.6 | |
| 1.99 | 9.93 | 3.63 | 18.57 | -14.55 | 134.80 | 74.13 | 255.23 | 0.9640 | -123.3 | 284.0 | |
| 1.17 | 3.43 | 1.99 | 5.85 | -13.48 | 133.55 | 72.88 | 256.29 | 0.9579 | -467.2 | -378.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
