SDO HMI 2014-05-28 14:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.59 | 160.16 | 16.05 | 84.17 | -8.89 | 25.04 | -18.01 | 114.10 | 0.3360 | 908.8 | 423.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-28 14:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.72 | 0.00 | 0.38 | -11.31 | 27.33 | -15.72 | 123.82 | 0.3211 | 825.0 | 718.9 | |
| 5.77 | 142.48 | 3.02 | 74.72 | -8.75 | 25.63 | -17.41 | 114.36 | 0.3261 | 1341.8 | 426.5 | |
| 11.55 | -2.00 | 6.06 | -2.00 | -8.99 | 25.40 | -17.65 | 114.76 | 0.3313 | 1274.2 | 999999 | |
| 9.93 | -2.00 | 5.21 | -2.00 | -8.78 | 25.28 | -17.77 | 114.02 | 0.3317 | 1222.3 | 999999 | |
| 2.26 | -2.00 | 1.19 | -2.00 | -8.84 | 25.02 | -18.03 | 113.89 | 0.3360 | 906.6 | 999999 | |
| 1.08 | -2.00 | 0.57 | -2.00 | -8.83 | 24.79 | -18.26 | 113.64 | 0.3394 | 633.9 | 999999 | |
| 0.00 | 1.08 | 0.00 | 0.57 | -8.13 | 24.76 | -18.29 | 111.65 | 0.3357 | 472.0 | 404.7 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -7.85 | 24.03 | -19.02 | 110.16 | 0.3454 | 609.0 | 497.8 | |
| 0.00 | 3.43 | 0.00 | 1.82 | -8.15 | 23.59 | -19.46 | 110.58 | 0.3537 | 980.0 | 787.4 | |
| 0.00 | 0.72 | 0.00 | 0.38 | -8.49 | 23.35 | -19.70 | 111.24 | 0.3593 | 652.0 | 560.6 | |
| 0.00 | 1.26 | 0.00 | 0.67 | -9.77 | 23.04 | -20.01 | 114.25 | 0.3714 | 729.0 | 591.9 | |
| 0.00 | 0.54 | 0.00 | 0.29 | -9.92 | 22.67 | -20.38 | 114.25 | 0.3778 | 717.0 | 714.8 | |
| 0.00 | 2.62 | 0.00 | 1.40 | -9.71 | 22.58 | -20.46 | 113.64 | 0.3778 | 792.0 | 750.9 | |
| 0.00 | 2.80 | 0.00 | 1.50 | -9.74 | 22.29 | -20.76 | 113.42 | 0.3824 | 933.0 | 726.5 | |
| 0.00 | 1.53 | 0.00 | 0.83 | -9.44 | 20.01 | -23.04 | 110.79 | 0.4146 | -867.0 | -640.1 | |
| 0.00 | 2.17 | 0.00 | 1.18 | -8.67 | 19.36 | -23.68 | 108.55 | 0.4206 | -842.0 | -658.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
