SDO HMI 2014-05-30 03:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.91 | 173.09 | 13.49 | 86.80 | -9.12 | 24.79 | 2.17 | 194.80 | 0.1530 | 570.6 | 373.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-05-30 03:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.67 | 147.38 | 4.35 | 73.87 | -9.13 | 25.82 | 3.20 | 201.11 | 0.1539 | 1132.5 | 441.2 | |
| 17.97 | -1.00 | 9.00 | -1.00 | -9.01 | 25.45 | 2.83 | 199.13 | 0.1497 | 1376.7 | 999999 | |
| 0.27 | -1.00 | 0.14 | -1.00 | -9.25 | 25.27 | 2.65 | 197.47 | 0.1527 | 914.7 | 999999 | |
| 0.00 | 1.08 | 0.00 | 0.54 | -9.53 | 23.48 | 0.86 | 185.67 | 0.1511 | 693.0 | 554.2 | |
| 0.00 | 3.70 | 0.00 | 1.85 | -9.40 | 23.30 | 0.68 | 184.53 | 0.1487 | 913.0 | 840.0 | |
| 0.00 | 3.16 | 0.00 | 1.59 | -10.14 | 23.24 | 0.62 | 183.79 | 0.1614 | 752.0 | 715.5 | |
| 0.00 | 3.79 | 0.00 | 1.90 | -9.71 | 23.08 | 0.46 | 182.98 | 0.1538 | 863.0 | 919.6 | |
| 0.00 | 1.08 | 0.00 | 0.54 | -9.99 | 22.93 | 0.31 | 181.93 | 0.1585 | 897.0 | 719.2 | |
| 0.00 | 2.35 | 0.00 | 1.18 | -9.06 | 20.22 | -2.40 | 163.74 | 0.1483 | -1099.0 | -886.4 | |
| 0.00 | 1.17 | 0.00 | 0.59 | -8.88 | 20.19 | -2.43 | 163.19 | 0.1454 | -1061.0 | -824.3 | |
| 0.00 | 1.81 | 0.00 | 0.91 | -10.11 | 19.93 | -2.69 | 163.89 | 0.1670 | -718.0 | -507.1 | |
| 0.00 | 3.07 | 0.00 | 1.54 | -8.29 | 19.70 | -2.92 | 158.60 | 0.1386 | -835.0 | -707.9 | |
| 0.00 | 1.26 | 0.00 | 0.63 | -5.41 | 14.36 | -8.26 | 118.75 | 0.1639 | -794.0 | -568.4 | |
| 0.00 | 0.90 | 0.00 | 0.46 | -7.66 | 13.32 | -9.30 | 126.33 | 0.1996 | -780.0 | -591.6 | |
| 0.00 | 1.35 | 0.00 | 0.69 | -12.06 | 13.13 | -9.49 | 140.20 | 0.2530 | -701.0 | -551.9 | |
| 0.00 | 0.99 | 0.00 | 0.51 | -11.88 | 12.98 | -9.64 | 139.27 | 0.2523 | -804.0 | -626.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
