SDO HMI 2014-06-03 01:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.27 | 39.67 | 9.02 | 20.76 | -18.96 | 329.96 | -0.83 | 177.58 | 0.3213 | 460.2 | -52.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-03 01:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.27 | 26.85 | 9.02 | 14.02 | -18.89 | 331.40 | 0.62 | 181.84 | 0.3179 | 1127.3 | 516.1 | |
| 0.00 | 0.99 | 0.00 | 0.52 | -19.02 | 330.54 | -0.25 | 179.26 | 0.3199 | 859.0 | 675.4 | |
| 0.00 | 1.08 | 0.00 | 0.58 | -22.16 | 330.30 | -0.49 | 178.77 | 0.3716 | 663.0 | 505.2 | |
| 0.00 | 2.08 | 0.00 | 1.09 | -18.82 | 327.55 | -3.24 | 170.37 | 0.3211 | -880.0 | -660.2 | |
| 0.00 | 1.08 | 0.00 | 0.57 | -19.08 | 326.25 | -4.53 | 166.84 | 0.3295 | -830.0 | -674.4 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -19.05 | 326.06 | -4.73 | 166.27 | 0.3297 | -833.0 | -626.9 | |
| 0.00 | 2.98 | 0.00 | 1.56 | -18.53 | 325.98 | -4.81 | 165.64 | 0.3218 | -897.0 | -789.9 | |
| 0.00 | 3.25 | 0.00 | 1.71 | -18.79 | 325.84 | -4.94 | 165.46 | 0.3265 | -877.0 | -622.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
