SDO HMI 2014-06-03 04:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.64 | 36.99 | 8.18 | 19.34 | -18.91 | 330.28 | 1.14 | 183.39 | 0.3210 | 440.4 | 36.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-03 04:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.64 | 26.40 | 8.18 | 13.81 | -18.91 | 331.49 | 2.35 | 186.98 | 0.3208 | 1147.4 | 517.7 | |
| 0.00 | 1.27 | 0.00 | 0.66 | -19.10 | 330.62 | 1.48 | 184.37 | 0.3225 | 781.0 | 454.9 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -19.51 | 329.72 | 0.58 | 181.68 | 0.3286 | 739.0 | 535.9 | |
| 0.00 | 1.18 | 0.00 | 0.61 | -19.00 | 328.11 | -1.02 | 176.96 | 0.3204 | -701.0 | -514.3 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -18.90 | 327.69 | -1.44 | 175.70 | 0.3192 | -777.0 | -583.9 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -19.03 | 326.05 | -3.08 | 170.94 | 0.3244 | -856.0 | -621.8 | |
| 0.00 | 1.27 | 0.00 | 0.66 | -18.51 | 326.06 | -3.07 | 170.70 | 0.3160 | -855.0 | -672.7 | |
| 0.00 | 3.16 | 0.00 | 1.65 | -18.80 | 325.80 | -3.34 | 170.08 | 0.3215 | -1032.0 | -821.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
