SDO HMI 2014-06-04 07:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 56.63 | 317.44 | 28.87 | 162.18 | -4.60 | 300.91 | -13.35 | 108.10 | 0.2435 | 646.2 | 415.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-04 07:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.64 | -5.45 | 303.31 | -10.95 | 115.47 | 0.2104 | 854.0 | 665.2 | |
| 5.07 | 26.05 | 2.58 | 13.25 | -5.60 | 302.37 | -11.89 | 114.33 | 0.2260 | 1258.8 | 664.7 | |
| 8.14 | -2.00 | 4.14 | -2.00 | -5.56 | 302.09 | -12.17 | 113.72 | 0.2302 | 1127.2 | 999999 | |
| 1.00 | 2.71 | 0.51 | 1.38 | -5.59 | 301.75 | -12.51 | 113.26 | 0.2357 | 932.2 | 658.4 | |
| 0.00 | 1.45 | 0.00 | 0.74 | -5.69 | 301.37 | -12.89 | 113.01 | 0.2423 | 836.0 | 704.2 | |
| 39.44 | 238.81 | 20.11 | 121.77 | -4.22 | 301.21 | -13.05 | 106.99 | 0.2365 | 1429.8 | 456.2 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -5.62 | 301.15 | -13.11 | 112.44 | 0.2453 | 989.0 | 850.6 | |
| 0.00 | 2.62 | 0.00 | 1.34 | -5.71 | 300.77 | -13.49 | 112.22 | 0.2518 | 421.0 | 586.3 | |
| 1.36 | -6.00 | 0.69 | -6.00 | -4.13 | 300.68 | -13.58 | 106.01 | 0.2447 | 830.8 | 999999 | |
| 0.00 | 2.08 | 0.00 | 1.07 | -6.05 | 300.61 | -13.65 | 113.20 | 0.2565 | 950.0 | 780.8 | |
| 0.54 | 6.69 | 0.28 | 3.44 | -6.20 | 300.29 | -13.97 | 113.28 | 0.2625 | 972.5 | 690.5 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -6.54 | 300.12 | -14.14 | 114.21 | 0.2673 | -785.0 | -622.1 | |
| 0.45 | -11.00 | 0.23 | -11.00 | -6.08 | 300.10 | -14.16 | 112.58 | 0.2646 | 983.6 | 999999 | |
| 0.00 | 0.90 | 0.00 | 0.47 | -6.57 | 299.96 | -14.30 | 114.08 | 0.2699 | -700.0 | -530.9 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -5.93 | 299.79 | -14.47 | 111.62 | 0.2685 | 1001.0 | 859.0 | |
| 0.00 | 1.54 | 0.00 | 0.79 | -3.49 | 299.78 | -14.48 | 102.65 | 0.2569 | 617.0 | 355.9 | |
| 0.63 | 1.72 | 0.33 | 0.88 | -5.80 | 299.57 | -14.69 | 110.91 | 0.2712 | 992.6 | 843.6 | |
| 0.00 | 0.72 | 0.00 | 0.37 | -5.62 | 299.55 | -14.71 | 110.23 | 0.2706 | 842.0 | 721.1 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -5.99 | 299.47 | -14.79 | 111.41 | 0.2739 | 729.0 | 495.4 | |
| 0.00 | 0.90 | 0.00 | 0.47 | -6.38 | 299.43 | -14.83 | 112.71 | 0.2770 | 629.0 | 412.6 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -6.60 | 299.26 | -15.00 | 113.20 | 0.2809 | -875.0 | -685.8 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -2.18 | 299.17 | -15.09 | 97.27 | 0.2634 | -719.0 | -507.1 | |
| 0.00 | 1.36 | 0.00 | 0.70 | -3.48 | 298.90 | -15.36 | 101.96 | 0.2715 | 807.0 | 610.0 | |
| 0.00 | 1.27 | 0.00 | 0.66 | -6.32 | 298.48 | -15.78 | 111.30 | 0.2914 | -623.0 | -412.6 | |
| 0.00 | 5.52 | 0.00 | 2.85 | -3.70 | 298.23 | -16.03 | 102.23 | 0.2832 | 750.0 | 694.8 | |
| 0.00 | 1.45 | 0.00 | 0.75 | -8.47 | 297.98 | -16.28 | 117.20 | 0.3131 | -859.0 | -626.3 | |
| 0.00 | 0.54 | 0.00 | 0.28 | -8.34 | 297.86 | -16.40 | 116.68 | 0.3140 | -673.0 | -547.0 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -8.92 | 297.35 | -16.91 | 117.64 | 0.3258 | -927.0 | -607.1 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -9.69 | 297.24 | -17.02 | 119.58 | 0.3331 | -732.0 | -544.4 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -9.45 | 297.26 | -17.00 | 118.94 | 0.3310 | -735.0 | -588.4 | |
| 0.00 | 1.54 | 0.00 | 0.80 | -2.29 | 297.33 | -16.93 | 96.91 | 0.2943 | 899.0 | 754.1 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -7.08 | 296.85 | -17.41 | 111.78 | 0.3211 | -956.0 | -816.1 | |
| 0.00 | 1.72 | 0.00 | 0.90 | -7.23 | 296.72 | -17.54 | 112.07 | 0.3241 | -873.0 | -694.2 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -8.86 | 296.48 | -17.78 | 116.34 | 0.3381 | -747.0 | -623.8 | |
| 0.00 | 1.54 | 0.00 | 0.81 | -6.65 | 296.03 | -18.23 | 109.69 | 0.3314 | -814.0 | -593.6 | |
| 0.00 | 0.81 | 0.00 | 0.43 | -7.08 | 295.82 | -18.44 | 110.70 | 0.3370 | -557.0 | -424.2 | |
| 0.00 | 1.72 | 0.00 | 0.91 | -4.69 | 294.55 | -19.71 | 102.93 | 0.3464 | -907.0 | -680.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
