SDO HMI 2014-06-05 01:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.43 | 27.41 | 3.30 | 16.33 | -19.84 | 332.27 | 27.95 | 232.58 | 0.5566 | 483.5 | 430.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-05 01:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.78 | -20.90 | 335.26 | 30.94 | 233.61 | 0.5988 | 663.0 | 496.8 | |
| 3.35 | 5.97 | 2.07 | 3.69 | -21.26 | 335.07 | 30.75 | 232.95 | 0.5993 | 859.5 | 621.3 | |
| 0.00 | 0.63 | 0.00 | 0.39 | -20.94 | 334.81 | 30.49 | 233.21 | 0.5940 | 719.0 | 574.1 | |
| 1.36 | 12.75 | 0.80 | 7.54 | -18.71 | 332.43 | 28.11 | 234.55 | 0.5499 | 846.5 | 741.6 | |
| 0.72 | -4.00 | 0.43 | -4.00 | -18.68 | 332.24 | 27.92 | 234.43 | 0.5474 | 1020.2 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.65 | -23.03 | 331.11 | 26.79 | 226.89 | 0.5704 | 520.0 | 506.8 | |
| 0.00 | 1.36 | 0.00 | 0.82 | -23.40 | 331.04 | 26.73 | 226.32 | 0.5729 | 646.0 | 526.5 | |
| 0.00 | 1.36 | 0.00 | 0.77 | -18.87 | 327.32 | 23.00 | 229.10 | 0.4911 | -755.0 | -571.7 | |
| 0.00 | 2.98 | 0.00 | 1.69 | -18.58 | 327.24 | 22.92 | 229.49 | 0.4875 | -728.0 | -597.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
