SDO HMI 2014-06-05 11:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 14.48 | 0.00 | 8.39 | 4.46 | 268.48 | -30.36 | 81.05 | 0.5086 | -490.4 | -430.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-05 11:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.81 | 0.00 | 0.45 | 3.85 | 273.14 | -25.70 | 80.88 | 0.4400 | -836.0 | -608.3 | |
| 0.00 | 1.54 | 0.00 | 0.85 | 3.79 | 273.00 | -25.83 | 81.06 | 0.4419 | -892.0 | -710.0 | |
| 0.00 | 1.36 | 0.00 | 0.75 | 6.11 | 272.84 | -25.99 | 75.99 | 0.4510 | -833.0 | -692.1 | |
| 0.00 | 0.90 | 0.00 | 0.50 | 3.64 | 272.91 | -25.93 | 81.43 | 0.4431 | -919.0 | -804.9 | |
| 0.00 | 1.72 | 0.00 | 0.95 | 3.30 | 272.78 | -26.05 | 82.22 | 0.4444 | -947.0 | -816.0 | |
| 0.00 | 1.18 | 0.00 | 0.66 | 3.61 | 270.96 | -27.88 | 82.04 | 0.4731 | -655.0 | -560.0 | |
| 0.00 | 1.18 | 0.00 | 0.66 | 3.77 | 270.64 | -28.19 | 81.80 | 0.4782 | -691.0 | -490.5 | |
| 0.00 | 1.27 | 0.00 | 0.72 | 3.19 | 270.35 | -28.49 | 83.08 | 0.4816 | -894.0 | -720.5 | |
| 0.00 | 1.99 | 0.00 | 1.12 | 3.07 | 270.21 | -28.62 | 83.36 | 0.4835 | -698.0 | -537.3 | |
| 0.00 | 1.18 | 0.00 | 0.78 | 5.27 | 257.34 | -41.49 | 81.92 | 0.6687 | 505.0 | 462.1 | |
| 0.00 | 0.72 | 0.00 | 0.50 | 10.01 | 255.21 | -43.62 | 75.51 | 0.7040 | 450.0 | 398.5 | |
| 0.00 | 0.63 | 0.00 | 0.45 | 7.15 | 253.90 | -44.93 | 79.79 | 0.7143 | 525.0 | 481.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
