SDO HMI 2014-06-07 17:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 44.70 | 247.10 | 26.63 | 147.62 | -3.50 | 302.75 | 33.70 | 263.54 | 0.5591 | 318.0 | 224.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-07 17:00:39 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.85 | 184.03 | 18.65 | 111.31 | -3.67 | 303.84 | 34.79 | 263.43 | 0.5753 | 1151.6 | 355.3 | |
| 1.00 | -1.00 | 0.60 | -1.00 | -3.24 | 303.60 | 34.55 | 264.14 | 0.5713 | 991.1 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.71 | -5.68 | 303.39 | 34.34 | 259.84 | 0.5724 | 715.0 | 581.2 | |
| 0.00 | 0.63 | 0.00 | 0.37 | -3.94 | 301.79 | 32.74 | 262.58 | 0.5462 | 716.0 | 656.0 | |
| 0.00 | 0.45 | 0.00 | 0.26 | -2.60 | 301.17 | 32.11 | 264.95 | 0.5352 | 619.0 | 568.6 | |
| 0.00 | 1.18 | 0.00 | 0.69 | -4.61 | 301.13 | 32.08 | 261.20 | 0.5378 | -644.0 | -458.0 | |
| 0.00 | 0.72 | 0.00 | 0.42 | -2.38 | 300.91 | 31.86 | 265.32 | 0.5312 | 737.0 | 602.2 | |
| 0.00 | 1.45 | 0.00 | 0.85 | -4.06 | 300.78 | 31.73 | 262.14 | 0.5317 | 899.0 | 645.8 | |
| 0.00 | 2.53 | 0.00 | 1.48 | -3.82 | 300.63 | 31.58 | 262.57 | 0.5290 | 815.0 | 635.8 | |
| 0.00 | 1.63 | 0.00 | 0.95 | -2.41 | 300.55 | 31.50 | 265.21 | 0.5259 | 923.0 | 709.1 | |
| 0.00 | 1.63 | 0.00 | 0.94 | -2.63 | 299.98 | 30.93 | 264.72 | 0.5177 | 299.0 | 190.7 | |
| 0.00 | 3.17 | 0.00 | 1.83 | -1.89 | 299.97 | 30.92 | 266.14 | 0.5167 | -432.0 | -461.4 | |
| 1.09 | 39.27 | 0.63 | 22.58 | -2.96 | 299.85 | 30.80 | 264.05 | 0.5162 | 864.5 | -293.3 | |
| 0.00 | 1.00 | 0.00 | 0.58 | -6.72 | 299.86 | 30.81 | 256.88 | 0.5243 | -565.0 | -459.5 | |
| 11.04 | -13.00 | 6.34 | -13.00 | -2.53 | 299.34 | 30.29 | 264.81 | 0.5080 | -857.0 | 999999 | |
| 0.72 | -13.00 | 0.41 | -13.00 | -2.68 | 299.07 | 30.02 | 264.46 | 0.5040 | -994.2 | 999999 | |
| 0.00 | 1.90 | 0.00 | 1.09 | -2.59 | 298.82 | 29.77 | 264.60 | 0.5002 | -970.0 | -810.4 | |
| 0.00 | 0.63 | 0.00 | 0.36 | -4.73 | 298.72 | 29.67 | 260.33 | 0.5024 | -655.0 | -532.6 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -7.73 | 298.69 | 29.64 | 254.48 | 0.5106 | -657.0 | -536.0 | |
| 0.00 | 1.54 | 0.00 | 0.88 | -4.51 | 298.46 | 29.41 | 260.68 | 0.4981 | -790.0 | -685.1 | |
| 0.00 | 0.90 | 0.00 | 0.52 | -5.06 | 298.35 | 29.30 | 259.55 | 0.4976 | -836.0 | -675.1 | |
| 0.00 | 0.90 | 0.00 | 0.50 | -1.67 | 295.08 | 26.02 | 265.97 | 0.4415 | -716.0 | -598.4 | |
| 0.00 | 1.36 | 0.00 | 0.73 | -5.57 | 292.00 | 22.95 | 255.72 | 0.4021 | -728.0 | -539.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
