SDO HMI 2014-06-08 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.06 | 197.60 | 20.17 | 132.77 | -3.57 | 303.60 | 42.28 | 264.45 | 0.6767 | 448.9 | 252.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-08 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.94 | -0.70 | 305.34 | 44.02 | 268.79 | 0.6973 | 470.0 | 399.7 | |
| 0.00 | 0.91 | 0.00 | 0.62 | -6.41 | 304.78 | 43.46 | 260.52 | 0.6953 | 483.0 | 403.2 | |
| 25.08 | 168.78 | 17.01 | 114.54 | -3.50 | 304.25 | 42.93 | 264.66 | 0.6851 | 1055.3 | 313.0 | |
| 0.00 | 1.45 | 0.00 | 0.95 | -4.41 | 301.72 | 40.40 | 262.99 | 0.6534 | 669.0 | 553.1 | |
| 1.36 | 4.44 | 0.88 | 2.87 | -2.61 | 301.35 | 40.03 | 265.72 | 0.6466 | 822.3 | 550.3 | |
| 0.00 | 0.54 | 0.00 | 0.35 | -5.14 | 300.65 | 39.33 | 261.69 | 0.6403 | 700.0 | 599.7 | |
| 0.00 | 1.00 | 0.00 | 0.63 | -2.11 | 299.83 | 38.51 | 266.36 | 0.6258 | -320.0 | -248.8 | |
| 0.00 | 1.99 | 0.00 | 1.26 | -2.57 | 299.73 | 38.41 | 265.62 | 0.6247 | -567.0 | -458.5 | |
| 1.00 | 7.43 | 0.63 | 4.68 | -2.26 | 299.57 | 38.25 | 266.09 | 0.6222 | -665.5 | -636.7 | |
| 2.26 | -9.00 | 1.43 | -9.00 | -2.36 | 299.37 | 38.06 | 265.93 | 0.6197 | -843.5 | 999999 | |
| 0.00 | 1.72 | 0.00 | 1.08 | -2.66 | 299.08 | 37.76 | 265.41 | 0.6158 | -782.0 | -568.6 | |
| 0.00 | 1.00 | 0.00 | 0.63 | -7.52 | 298.71 | 37.39 | 257.48 | 0.6189 | -571.0 | -437.3 | |
| 0.00 | 0.91 | 0.00 | 0.57 | -5.53 | 298.46 | 37.14 | 260.64 | 0.6113 | -588.0 | -494.3 | |
| 0.00 | 1.09 | 0.00 | 0.67 | -8.41 | 297.26 | 35.94 | 255.61 | 0.6017 | -702.0 | -494.0 | |
| 0.00 | 1.63 | 0.00 | 0.98 | -7.57 | 295.45 | 34.13 | 256.39 | 0.5744 | 674.0 | 385.8 | |
| 0.36 | 1.99 | 0.22 | 1.19 | -7.72 | 294.69 | 33.37 | 255.86 | 0.5642 | -844.0 | -655.7 | |
| 0.00 | 1.36 | 0.00 | 0.81 | -8.03 | 294.57 | 33.25 | 255.28 | 0.5634 | -597.0 | -528.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
