SDO HMI 2014-06-08 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 28.06 | 174.12 | 19.37 | 119.51 | -3.53 | 303.82 | 43.60 | 264.66 | 0.6934 | 584.9 | 257.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-08 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.54 | 0.00 | 1.10 | -6.07 | 305.84 | 45.62 | 261.34 | 0.7212 | 580.0 | 477.3 | |
| 0.00 | 0.54 | 0.00 | 0.38 | -6.40 | 304.92 | 44.70 | 260.73 | 0.7105 | 525.0 | 436.7 | |
| 27.07 | 152.57 | 18.72 | 105.55 | -3.50 | 304.33 | 44.11 | 264.77 | 0.6999 | 1029.5 | 321.3 | |
| 0.00 | 1.18 | 0.00 | 0.78 | -4.43 | 301.76 | 41.54 | 263.10 | 0.6682 | 666.0 | 527.2 | |
| 0.36 | 4.07 | 0.24 | 2.69 | -2.57 | 301.34 | 41.11 | 265.86 | 0.6609 | 897.5 | 706.6 | |
| 0.00 | 1.99 | 0.00 | 1.28 | -2.53 | 299.77 | 39.55 | 265.77 | 0.6401 | -510.0 | -398.0 | |
| 0.63 | 7.33 | 0.41 | 4.70 | -2.26 | 299.61 | 39.38 | 266.19 | 0.6376 | -613.3 | -657.6 | |
| 0.00 | 0.91 | 0.00 | 0.58 | -2.62 | 299.07 | 38.84 | 265.56 | 0.6306 | -557.0 | -519.9 | |
| 0.00 | 0.45 | 0.00 | 0.29 | -6.75 | 298.86 | 38.64 | 259.02 | 0.6339 | -649.0 | -612.6 | |
| 0.00 | 1.00 | 0.00 | 0.64 | -7.45 | 298.73 | 38.51 | 257.88 | 0.6337 | -627.0 | -483.4 | |
| 0.00 | 1.36 | 0.00 | 0.82 | -7.81 | 294.71 | 34.48 | 256.10 | 0.5800 | -786.0 | -688.7 | |
| 0.00 | 1.18 | 0.00 | 0.70 | -5.96 | 292.72 | 32.50 | 258.68 | 0.5470 | -399.0 | -417.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
