SDO HMI 2014-06-09 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.64 | 82.40 | 21.54 | 82.32 | -3.24 | 304.93 | 60.14 | 266.07 | 0.8698 | 622.8 | 163.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-09 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.40 | 79.23 | 12.48 | 79.32 | -3.28 | 305.23 | 60.44 | 266.04 | 0.8724 | 531.1 | 154.2 | |
| 4.26 | -1.00 | 4.22 | -1.00 | -3.15 | 304.78 | 59.99 | 266.16 | 0.8686 | 754.6 | 999999 | |
| 3.62 | -1.00 | 3.56 | -1.00 | -3.27 | 304.43 | 59.64 | 266.01 | 0.8655 | 790.4 | 999999 | |
| 1.36 | 3.17 | 1.28 | 3.00 | -2.96 | 303.15 | 58.35 | 266.31 | 0.8540 | 616.9 | 492.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
