SDO HMI 2014-06-10 20:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 19.49 | 0.00 | 11.24 | 4.61 | 257.15 | 29.47 | 279.39 | 0.4941 | 318.4 | 300.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-10 20:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.54 | 0.00 | 0.37 | 4.90 | 271.57 | 43.90 | 276.55 | 0.6977 | -537.0 | -384.7 | |
| 0.00 | 0.91 | 0.00 | 0.61 | 5.03 | 270.28 | 42.60 | 276.89 | 0.6815 | -695.0 | -580.4 | |
| 0.00 | 1.18 | 0.00 | 0.79 | 5.18 | 270.25 | 42.57 | 277.12 | 0.6813 | -606.0 | -534.2 | |
| 0.00 | 0.81 | 0.00 | 0.55 | 5.21 | 270.05 | 42.37 | 277.19 | 0.6787 | -741.0 | -588.0 | |
| 0.00 | 0.72 | 0.00 | 0.48 | -0.42 | 269.00 | 41.33 | 268.82 | 0.6627 | -518.0 | -431.8 | |
| 0.00 | 1.00 | 0.00 | 0.60 | 0.75 | 262.60 | 34.93 | 270.62 | 0.5746 | 697.0 | 518.0 | |
| 0.00 | 1.27 | 0.00 | 0.73 | -0.54 | 258.14 | 30.46 | 268.12 | 0.5093 | 705.0 | 586.4 | |
| 0.00 | 1.27 | 0.00 | 0.72 | 4.68 | 256.99 | 29.31 | 278.65 | 0.4955 | 550.0 | 436.1 | |
| 0.00 | 1.09 | 0.00 | 0.62 | 4.65 | 256.67 | 29.00 | 278.67 | 0.4907 | 685.0 | 528.8 | |
| 0.00 | 1.81 | 0.00 | 1.03 | 7.22 | 256.72 | 29.04 | 283.80 | 0.4979 | 615.0 | 633.2 | |
| 0.00 | 1.18 | 0.00 | 0.67 | 9.99 | 255.69 | 28.01 | 289.76 | 0.4935 | 574.0 | 448.8 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 4.49 | 251.35 | 23.67 | 280.01 | 0.4081 | 725.0 | 547.8 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 4.74 | 251.19 | 23.51 | 280.67 | 0.4063 | 778.0 | 635.8 | |
| 0.00 | 1.72 | 0.00 | 0.91 | 4.35 | 248.57 | 20.89 | 280.83 | 0.3636 | 735.0 | 547.6 | |
| 0.00 | 1.72 | 0.00 | 0.90 | 6.84 | 245.83 | 18.16 | 289.75 | 0.3302 | 860.0 | 719.9 | |
| 0.00 | 0.91 | 0.00 | 0.47 | 6.78 | 245.35 | 17.67 | 290.05 | 0.3223 | 841.0 | 623.3 | |
| 0.00 | 1.18 | 0.00 | 0.61 | 1.63 | 243.69 | 16.02 | 274.21 | 0.2778 | 745.0 | 577.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
