SDO HMI 2014-06-11 10:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 7.98 | 0.00 | 4.76 | 6.10 | 252.79 | 32.83 | 280.20 | 0.5487 | 591.1 | 473.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-11 10:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 0.81 | 5.84 | 258.52 | 38.55 | 278.61 | 0.6293 | 61.0 | 118.1 | |
| 0.00 | 1.36 | 0.00 | 0.83 | 6.44 | 255.05 | 35.08 | 280.33 | 0.5826 | 661.0 | 478.2 | |
| 0.00 | 0.72 | 0.00 | 0.44 | 6.20 | 254.91 | 34.94 | 279.94 | 0.5803 | 691.0 | 550.0 | |
| 0.00 | 1.45 | 0.00 | 0.89 | 9.49 | 254.82 | 34.85 | 285.54 | 0.5872 | 629.0 | 561.9 | |
| 0.00 | 1.09 | 0.00 | 0.62 | 4.28 | 248.67 | 28.70 | 277.83 | 0.4854 | 639.0 | 525.2 | |
| 0.00 | 1.27 | 0.00 | 0.72 | 4.31 | 248.25 | 28.29 | 278.00 | 0.4791 | 837.0 | 631.9 | |
| 0.00 | 0.82 | 0.00 | 0.45 | 4.51 | 245.21 | 25.25 | 279.31 | 0.4326 | 620.0 | 525.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
