SDO HMI 2014-06-11 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 15.41 | 0.00 | 10.32 | 5.65 | 259.63 | 41.31 | 278.12 | 0.6603 | 303.2 | 212.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-11 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 0.72 | 7.12 | 274.00 | 55.68 | 278.21 | 0.8302 | -380.0 | -282.4 | |
| 0.00 | 1.27 | 0.00 | 1.04 | 5.12 | 271.22 | 52.90 | 275.97 | 0.8009 | -461.0 | -373.8 | |
| 0.00 | 1.45 | 0.00 | 1.18 | 2.25 | 270.81 | 52.49 | 272.39 | 0.7956 | -564.0 | -475.8 | |
| 0.00 | 1.00 | 0.00 | 0.66 | 8.00 | 259.25 | 40.93 | 281.47 | 0.6642 | 567.0 | 500.0 | |
| 0.00 | 1.18 | 0.00 | 0.76 | 5.19 | 258.16 | 39.84 | 277.39 | 0.6456 | 601.0 | 455.7 | |
| 0.00 | 1.90 | 0.00 | 1.19 | 0.75 | 255.97 | 37.65 | 270.48 | 0.6130 | 293.0 | 362.8 | |
| 0.00 | 1.81 | 0.00 | 1.15 | 9.29 | 256.06 | 37.74 | 284.25 | 0.6255 | 650.0 | 424.3 | |
| 0.00 | 1.72 | 0.00 | 1.08 | 9.23 | 255.00 | 36.68 | 284.49 | 0.6112 | 428.0 | 314.9 | |
| 0.00 | 1.81 | 0.00 | 1.13 | 9.26 | 254.70 | 36.38 | 284.64 | 0.6072 | 620.0 | 468.2 | |
| 0.00 | 1.18 | 0.00 | 0.68 | 1.25 | 249.39 | 31.07 | 271.47 | 0.5182 | 743.0 | 578.5 | |
| 0.00 | 1.27 | 0.00 | 0.73 | 4.31 | 248.31 | 29.99 | 277.58 | 0.5049 | 838.0 | 677.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
