SDO HMI 2014-06-11 14:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 11.07 | 0.00 | 7.55 | 4.19 | 260.47 | 42.70 | 275.66 | 0.6752 | 332.0 | 181.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-11 14:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.27 | 0.00 | 0.24 | 6.84 | 273.95 | 56.18 | 277.83 | 0.8348 | -467.0 | -428.0 | |
| 0.00 | 1.72 | 0.00 | 1.42 | 2.28 | 270.82 | 53.05 | 272.41 | 0.8015 | -529.0 | -400.7 | |
| 0.00 | 1.45 | 0.00 | 1.21 | 5.63 | 271.09 | 53.32 | 276.58 | 0.8056 | -171.0 | -221.5 | |
| 0.00 | 0.91 | 0.00 | 0.59 | 5.22 | 258.17 | 40.40 | 277.35 | 0.6531 | 618.0 | 458.9 | |
| 0.00 | 0.82 | 0.00 | 0.52 | 1.59 | 257.07 | 39.30 | 271.81 | 0.6357 | 579.0 | 464.0 | |
| 0.00 | 1.09 | 0.00 | 0.69 | 9.28 | 256.10 | 38.33 | 284.07 | 0.6332 | 654.0 | 588.9 | |
| 0.00 | 1.18 | 0.00 | 0.73 | -1.37 | 254.77 | 37.00 | 266.95 | 0.6047 | 377.0 | 378.4 | |
| 0.00 | 0.91 | 0.00 | 0.57 | 9.81 | 255.15 | 37.38 | 285.19 | 0.6221 | 491.0 | 375.1 | |
| 0.00 | 0.72 | 0.00 | 0.43 | 4.41 | 250.96 | 33.19 | 277.14 | 0.5522 | 608.0 | 512.5 | |
| 0.00 | 1.00 | 0.00 | 0.58 | 1.22 | 249.41 | 31.64 | 271.38 | 0.5267 | 663.0 | 538.3 | |
| 0.00 | 1.00 | 0.00 | 0.57 | 4.27 | 248.33 | 30.56 | 277.40 | 0.5133 | 829.0 | 643.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
