SDO HMI 2014-06-29 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 46.07 | 305.81 | 89.30 | 603.91 | -10.62 | 268.29 | -74.52 | 101.71 | 0.9679 | 286.1 | 141.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-29 08:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 1.25 | -11.50 | 272.75 | -70.05 | 103.12 | 0.9472 | -83.0 | -124.9 | |
| 0.00 | 3.54 | 0.00 | 5.72 | -12.05 | 271.66 | -71.15 | 103.56 | 0.9534 | 495.0 | 329.3 | |
| 0.00 | 1.18 | 0.00 | 1.93 | -11.68 | 271.50 | -71.31 | 103.16 | 0.9540 | 344.0 | 328.8 | |
| 0.00 | 0.27 | 0.00 | 0.48 | -12.65 | 270.12 | -72.69 | 104.01 | 0.9613 | 210.0 | 195.7 | |
| 0.00 | 2.73 | 0.00 | 4.75 | -11.92 | 270.32 | -72.48 | 103.27 | 0.9599 | 205.0 | 260.6 | |
| 0.00 | 0.27 | 0.00 | 0.49 | -12.44 | 269.96 | -72.85 | 103.77 | 0.9619 | 255.0 | 256.3 | |
| 0.00 | 2.82 | 0.00 | 5.23 | -12.38 | 269.35 | -73.46 | 103.63 | 0.9646 | -109.0 | -159.5 | |
| 7.09 | 163.90 | 12.10 | 290.01 | -10.38 | 270.57 | -72.23 | 101.70 | 0.9579 | 931.2 | 213.9 | |
| 19.99 | -8.00 | 35.55 | -8.00 | -10.26 | 269.80 | -73.01 | 101.49 | 0.9615 | 433.9 | 999999 | |
| 0.00 | 1.27 | 0.00 | 2.54 | -11.68 | 268.15 | -74.66 | 102.78 | 0.9695 | 248.0 | 144.3 | |
| 1.73 | 4.09 | 3.37 | 8.00 | -9.74 | 268.20 | -74.60 | 100.79 | 0.9684 | -48.1 | -87.5 | |
| 8.63 | 100.85 | 19.87 | 228.17 | -11.71 | 266.06 | -76.74 | 102.61 | 0.9776 | -203.4 | 55.4 | |
| 5.36 | -12.00 | 11.27 | -12.00 | -10.16 | 267.18 | -75.63 | 101.13 | 0.9728 | 183.5 | 999999 | |
| 0.00 | 1.54 | 0.00 | 5.06 | -14.30 | 262.56 | -80.25 | 104.91 | 0.9890 | 78.0 | 74.5 | |
| 3.27 | 20.53 | 7.14 | 45.14 | -9.07 | 266.51 | -76.30 | 99.95 | 0.9751 | 303.4 | 152.4 | |
| 0.00 | 0.27 | 0.00 | 0.62 | -9.81 | 265.98 | -76.83 | 100.66 | 0.9773 | 111.0 | 111.0 | |
| 0.00 | 1.73 | 0.00 | 4.52 | -11.06 | 264.45 | -78.35 | 101.81 | 0.9828 | 219.0 | 226.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
