SDO HMI 2014-06-30 12:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 133.81 | 736.81 | 134.70 | 742.75 | -10.71 | 268.07 | -59.30 | 103.96 | 0.8723 | 307.9 | 202.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-30 12:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 1.06 | -12.93 | 275.93 | -51.45 | 108.36 | 0.8053 | 488.0 | 400.4 | |
| 2.09 | 4.00 | 1.87 | 3.57 | -12.11 | 272.73 | -54.65 | 106.55 | 0.8341 | -523.4 | -358.1 | |
| 0.00 | 0.82 | 0.00 | 0.75 | -13.17 | 272.11 | -55.27 | 107.65 | 0.8418 | 445.0 | 446.0 | |
| 0.00 | 2.00 | 0.00 | 1.80 | -11.62 | 272.27 | -55.10 | 105.88 | 0.8373 | 207.0 | 62.4 | |
| 2.36 | 322.93 | 2.22 | 308.46 | -11.44 | 270.59 | -56.78 | 105.29 | 0.8521 | 673.3 | 335.8 | |
| 10.45 | -5.00 | 9.85 | -5.00 | -10.66 | 270.37 | -57.00 | 104.35 | 0.8528 | 968.9 | 999999 | |
| 0.27 | -5.00 | 0.26 | -5.00 | -10.16 | 270.40 | -56.97 | 103.78 | 0.8518 | 1031.0 | 999999 | |
| 0.00 | 1.09 | 0.00 | 1.05 | -12.00 | 269.83 | -57.54 | 105.78 | 0.8597 | 395.0 | 398.7 | |
| 0.00 | 0.91 | 0.00 | 0.89 | -12.40 | 269.46 | -57.92 | 106.15 | 0.8635 | 254.0 | 211.8 | |
| 0.00 | 1.73 | 0.00 | 1.68 | -12.08 | 269.51 | -57.86 | 105.80 | 0.8626 | 481.0 | 428.2 | |
| 21.89 | -5.00 | 20.94 | -5.00 | -10.53 | 269.83 | -57.54 | 104.09 | 0.8573 | 808.6 | 999999 | |
| 0.00 | 0.27 | 0.00 | 0.27 | -12.06 | 269.22 | -58.15 | 105.72 | 0.8650 | 294.0 | 291.3 | |
| 0.00 | 3.09 | 0.00 | 3.01 | -11.49 | 269.36 | -58.02 | 105.10 | 0.8629 | 38.0 | 78.0 | |
| 0.00 | 0.45 | 0.00 | 0.48 | -15.98 | 267.31 | -60.06 | 109.71 | 0.8868 | 302.0 | 336.8 | |
| 21.35 | -5.00 | 20.55 | -5.00 | -9.98 | 269.53 | -57.85 | 103.40 | 0.8592 | 651.9 | 999999 | |
| 0.00 | 0.73 | 0.00 | 0.78 | -15.73 | 267.12 | -60.26 | 109.39 | 0.8879 | 483.0 | 428.6 | |
| 1.00 | -5.00 | 0.98 | -5.00 | -10.56 | 269.12 | -58.26 | 103.99 | 0.8635 | 22.9 | 999999 | |
| 0.00 | 7.54 | 0.00 | 7.54 | -12.18 | 268.58 | -58.80 | 105.73 | 0.8706 | 549.0 | 304.3 | |
| 1.54 | -5.00 | 1.51 | -5.00 | -10.25 | 269.09 | -58.28 | 103.63 | 0.8633 | 18.9 | 999999 | |
| 0.00 | 2.54 | 0.00 | 2.55 | -11.25 | 268.36 | -59.02 | 104.63 | 0.8710 | 358.0 | 271.6 | |
| 2.82 | -5.00 | 2.77 | -5.00 | -9.70 | 268.72 | -58.66 | 102.93 | 0.8658 | 385.9 | 999999 | |
| 0.00 | 0.64 | 0.00 | 0.64 | -10.53 | 268.29 | -59.09 | 103.80 | 0.8705 | 228.0 | 191.7 | |
| 2.54 | -5.00 | 2.53 | -5.00 | -10.00 | 268.39 | -58.99 | 103.21 | 0.8689 | 234.8 | 999999 | |
| 5.09 | 326.56 | 5.16 | 343.79 | -10.87 | 267.81 | -59.56 | 104.09 | 0.8749 | 338.4 | 112.2 | |
| 1.54 | -24.00 | 1.57 | -24.00 | -10.50 | 267.68 | -59.69 | 103.65 | 0.8755 | 465.9 | 999999 | |
| 1.91 | -24.00 | 1.97 | -24.00 | -11.04 | 267.31 | -60.06 | 104.20 | 0.8792 | -335.3 | 999999 | |
| 0.00 | 0.73 | 0.00 | 0.78 | -12.94 | 266.27 | -61.11 | 106.12 | 0.8901 | -593.0 | -534.4 | |
| 28.43 | -24.00 | 30.24 | -24.00 | -11.80 | 266.53 | -60.84 | 104.90 | 0.8865 | -576.7 | 999999 | |
| 3.45 | -24.00 | 3.60 | -24.00 | -10.75 | 266.91 | -60.46 | 103.79 | 0.8821 | 233.4 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.84 | -9.02 | 267.26 | -60.12 | 101.90 | 0.8771 | 487.0 | 411.7 | |
| 10.90 | -24.00 | 11.32 | -24.00 | -9.87 | 266.94 | -60.43 | 102.82 | 0.8807 | 624.6 | 999999 | |
| 0.00 | 1.91 | 0.00 | 2.11 | -13.51 | 265.55 | -61.82 | 106.61 | 0.8962 | -596.0 | -533.3 | |
| 0.00 | 1.27 | 0.00 | 1.31 | -9.40 | 267.02 | -60.35 | 102.30 | 0.8795 | 360.0 | 300.9 | |
| 0.00 | 1.82 | 0.00 | 1.88 | -8.54 | 266.83 | -60.55 | 101.29 | 0.8801 | 483.0 | 420.7 | |
| 0.55 | 1.73 | 0.56 | 1.77 | -7.57 | 267.01 | -60.37 | 100.23 | 0.8775 | 534.0 | 463.6 | |
| 0.00 | 0.91 | 0.00 | 1.01 | -12.48 | 265.41 | -61.97 | 105.44 | 0.8960 | -276.0 | -214.0 | |
| 2.45 | 38.24 | 2.59 | 40.58 | -9.37 | 266.33 | -61.04 | 102.15 | 0.8850 | 487.4 | 24.3 | |
| 7.09 | -37.00 | 7.47 | -37.00 | -9.03 | 266.31 | -61.07 | 101.76 | 0.8848 | 518.1 | 999999 | |
| 0.00 | 2.09 | 0.00 | 2.25 | -9.45 | 265.79 | -61.59 | 102.16 | 0.8894 | 360.0 | 255.4 | |
| 0.00 | 1.36 | 0.00 | 1.53 | -11.47 | 264.81 | -62.57 | 104.23 | 0.8992 | -209.0 | -180.5 | |
| 6.09 | 9.36 | 6.74 | 10.37 | -9.65 | 264.93 | -62.45 | 102.24 | 0.8962 | 383.2 | 300.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
