SDO HMI 2014-06-30 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 81.27 | 466.97 | 108.33 | 631.58 | -20.17 | 259.01 | -65.60 | 113.05 | 0.9301 | 162.3 | -35.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-30 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.27 | 0.00 | 1.31 | -19.77 | 266.59 | -58.02 | 114.41 | 0.8785 | 417.0 | 370.9 | |
| 9.72 | 198.12 | 11.19 | 247.73 | -21.17 | 263.35 | -61.26 | 115.08 | 0.9045 | 668.2 | -198.9 | |
| 0.00 | 2.81 | 0.00 | 3.09 | -19.28 | 264.41 | -60.20 | 113.30 | 0.8937 | 52.0 | 129.0 | |
| 8.72 | -2.00 | 10.50 | -2.00 | -21.29 | 262.07 | -62.54 | 114.89 | 0.9132 | 289.2 | 999999 | |
| 0.00 | 4.36 | 0.00 | 5.70 | -22.18 | 260.00 | -64.60 | 115.36 | 0.9273 | -532.0 | -443.4 | |
| 0.36 | 1.18 | 0.44 | 1.43 | -20.16 | 261.55 | -63.06 | 113.57 | 0.9147 | 63.5 | 51.9 | |
| 7.63 | -2.00 | 9.62 | -2.00 | -21.12 | 260.74 | -63.87 | 114.40 | 0.9213 | -648.1 | 999999 | |
| 0.64 | -2.00 | 0.83 | -2.00 | -21.82 | 259.93 | -64.68 | 114.96 | 0.9272 | -563.3 | 999999 | |
| 3.18 | -2.00 | 4.10 | -2.00 | -21.28 | 260.15 | -64.45 | 114.44 | 0.9251 | -590.4 | 999999 | |
| 7.81 | -2.00 | 10.19 | -2.00 | -21.52 | 259.95 | -64.66 | 114.65 | 0.9267 | -547.6 | 999999 | |
| 3.81 | 6.36 | 5.11 | 8.53 | -22.01 | 259.37 | -65.24 | 115.04 | 0.9308 | -329.7 | -157.3 | |
| 0.36 | 1.45 | 0.50 | 2.02 | -22.68 | 258.59 | -66.02 | 115.58 | 0.9361 | 20.8 | -2.2 | |
| 0.00 | 1.18 | 0.00 | 1.67 | -23.00 | 258.29 | -66.32 | 115.84 | 0.9382 | 218.0 | 245.5 | |
| 0.00 | 1.18 | 0.00 | 1.68 | -22.83 | 258.20 | -66.41 | 115.65 | 0.9385 | 286.0 | 321.2 | |
| 0.00 | 7.90 | 0.00 | 11.26 | -22.31 | 257.95 | -66.66 | 115.06 | 0.9391 | 373.0 | 356.4 | |
| 0.00 | 0.82 | 0.00 | 1.06 | -20.34 | 259.68 | -64.93 | 113.35 | 0.9266 | -319.0 | -231.8 | |
| 0.00 | 1.91 | 0.00 | 2.58 | -21.07 | 258.92 | -65.69 | 113.96 | 0.9321 | -160.0 | -222.8 | |
| 0.00 | 1.54 | 0.00 | 2.23 | -20.75 | 257.30 | -67.31 | 113.30 | 0.9408 | 200.0 | 229.9 | |
| 0.00 | 1.36 | 0.00 | 1.99 | -21.03 | 257.05 | -67.56 | 113.54 | 0.9425 | 206.0 | 118.5 | |
| 0.00 | 1.00 | 0.00 | 1.33 | -18.71 | 258.85 | -65.76 | 111.46 | 0.9295 | 145.0 | 124.0 | |
| 39.04 | 234.53 | 55.85 | 337.97 | -19.15 | 257.18 | -67.43 | 111.60 | 0.9397 | 437.3 | 66.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
