SDO HMI 2014-06-30 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 97.62 | 499.47 | 117.17 | 609.34 | -20.14 | 258.95 | -62.88 | 113.63 | 0.9132 | 227.4 | -34.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-06-30 22:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.09 | 0.00 | 2.14 | -21.49 | 264.38 | -57.45 | 116.48 | 0.8781 | 454.0 | 321.9 | |
| 11.26 | 210.73 | 11.94 | 238.94 | -21.14 | 263.24 | -58.60 | 115.76 | 0.8858 | 691.8 | -268.0 | |
| 1.45 | -2.00 | 1.57 | -2.00 | -21.40 | 262.69 | -59.15 | 115.89 | 0.8904 | 393.9 | 999999 | |
| 12.26 | -2.00 | 13.47 | -2.00 | -21.26 | 262.06 | -59.77 | 115.57 | 0.8945 | 372.3 | 999999 | |
| 0.00 | 0.54 | 0.00 | 0.67 | -23.92 | 259.49 | -62.35 | 117.75 | 0.9166 | -376.0 | -352.2 | |
| 0.00 | 1.18 | 0.00 | 1.30 | -20.09 | 261.66 | -60.18 | 114.20 | 0.8951 | 311.0 | 216.6 | |
| 8.81 | -2.00 | 10.07 | -2.00 | -21.12 | 260.83 | -61.00 | 115.10 | 0.9028 | -705.6 | 999999 | |
| 0.64 | 1.63 | 0.75 | 1.94 | -22.08 | 259.98 | -61.86 | 115.92 | 0.9102 | -591.4 | -547.4 | |
| 0.64 | -2.00 | 0.75 | -2.00 | -21.75 | 259.95 | -61.88 | 115.56 | 0.9098 | -523.9 | 999999 | |
| 4.81 | -2.00 | 5.66 | -2.00 | -21.48 | 260.08 | -61.75 | 115.30 | 0.9084 | -635.0 | 999999 | |
| 5.72 | -2.00 | 6.71 | -2.00 | -21.25 | 260.04 | -61.79 | 115.04 | 0.9083 | -610.7 | 999999 | |
| 4.45 | 7.63 | 5.37 | 9.21 | -21.94 | 259.38 | -62.46 | 115.62 | 0.9138 | -377.2 | -171.6 | |
| 0.00 | 1.18 | 0.00 | 1.46 | -22.57 | 258.87 | -62.96 | 116.16 | 0.9180 | -201.0 | -141.2 | |
| 0.00 | 0.73 | 0.00 | 0.87 | -21.54 | 259.40 | -62.43 | 115.20 | 0.9130 | -324.0 | -275.4 | |
| 0.00 | 1.09 | 0.00 | 1.38 | -22.50 | 258.27 | -63.56 | 115.94 | 0.9216 | 392.0 | 358.3 | |
| 0.00 | 2.36 | 0.00 | 2.99 | -22.30 | 258.21 | -63.62 | 115.72 | 0.9217 | 417.0 | 365.9 | |
| 0.00 | 1.73 | 0.00 | 2.03 | -20.34 | 259.72 | -62.11 | 113.99 | 0.9089 | -168.0 | -170.7 | |
| 1.45 | -2.00 | 1.80 | -2.00 | -21.68 | 258.57 | -63.27 | 115.15 | 0.9185 | -41.3 | 999999 | |
| 0.00 | 0.91 | 0.00 | 1.15 | -22.07 | 258.18 | -63.65 | 115.47 | 0.9215 | 289.0 | 260.0 | |
| 0.00 | 1.00 | 0.00 | 1.28 | -22.08 | 257.79 | -64.05 | 115.39 | 0.9239 | 380.0 | 414.2 | |
| 0.00 | 0.91 | 0.00 | 1.22 | -23.24 | 256.76 | -65.07 | 116.37 | 0.9316 | 105.0 | 79.9 | |
| 0.73 | 2.09 | 0.92 | 2.65 | -21.64 | 257.93 | -63.91 | 114.96 | 0.9224 | -386.5 | -305.6 | |
| 0.00 | 2.00 | 0.00 | 2.59 | -20.75 | 257.13 | -64.70 | 113.84 | 0.9259 | 312.0 | 233.1 | |
| 0.00 | 3.00 | 0.00 | 4.23 | -22.30 | 255.37 | -66.46 | 115.09 | 0.9381 | -404.0 | -246.5 | |
| 45.40 | 258.67 | 58.16 | 333.29 | -19.15 | 257.16 | -64.68 | 112.15 | 0.9235 | 560.8 | 120.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
