SDO HMI 2014-07-02 00:16:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 113.70 | 674.46 | 93.89 | 559.30 | -19.88 | 258.42 | -48.92 | 117.71 | 0.8025 | 402.4 | 97.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-02 00:16:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.09 | 0.00 | 0.79 | -22.81 | 267.26 | -40.09 | 125.51 | 0.7315 | 663.0 | 489.2 | |
| 0.00 | 1.18 | 0.00 | 0.87 | -23.26 | 266.74 | -40.60 | 125.75 | 0.7390 | 593.0 | 511.9 | |
| 0.00 | 1.00 | 0.00 | 0.74 | -24.44 | 266.29 | -41.06 | 126.88 | 0.7498 | 105.0 | 115.0 | |
| 0.00 | 1.63 | 0.00 | 1.20 | -23.17 | 266.51 | -40.83 | 125.51 | 0.7407 | 347.0 | 361.1 | |
| 0.00 | 0.27 | 0.00 | 0.21 | -23.18 | 264.46 | -42.89 | 124.36 | 0.7602 | 362.0 | 364.7 | |
| 0.00 | 1.00 | 0.00 | 0.72 | -19.67 | 265.63 | -41.71 | 120.72 | 0.7311 | 426.0 | 409.6 | |
| 0.00 | 0.64 | 0.00 | 0.50 | -23.04 | 262.53 | -44.82 | 123.21 | 0.7775 | -560.0 | -458.0 | |
| 0.00 | 0.64 | 0.00 | 0.48 | -19.77 | 263.75 | -43.60 | 119.88 | 0.7508 | 625.0 | 560.9 | |
| 2.63 | 208.60 | 2.02 | 164.56 | -21.35 | 263.08 | -44.27 | 121.47 | 0.7645 | 831.4 | -194.0 | |
| 0.00 | 2.18 | 0.00 | 1.68 | -21.65 | 262.96 | -44.39 | 121.78 | 0.7671 | 125.0 | 122.7 | |
| 0.00 | 1.54 | 0.00 | 1.21 | -22.51 | 262.52 | -44.83 | 122.57 | 0.7751 | -153.0 | -158.9 | |
| 0.00 | 1.18 | 0.00 | 0.94 | -23.27 | 261.91 | -45.44 | 123.17 | 0.7842 | -451.0 | -471.6 | |
| 4.27 | -9.00 | 3.28 | -9.00 | -21.16 | 262.73 | -44.61 | 121.08 | 0.7670 | 882.4 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.62 | -20.65 | 262.93 | -44.42 | 120.56 | 0.7629 | 565.0 | 430.6 | |
| 3.09 | -9.00 | 2.37 | -9.00 | -20.93 | 262.78 | -44.57 | 120.82 | 0.7655 | 822.4 | 999999 | |
| 3.81 | -9.00 | 2.95 | -9.00 | -21.01 | 262.38 | -44.97 | 120.72 | 0.7697 | 810.9 | 999999 | |
| 9.26 | -9.00 | 7.23 | -9.00 | -21.12 | 261.91 | -45.43 | 120.64 | 0.7747 | 705.0 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.80 | -22.55 | 261.27 | -46.07 | 122.03 | 0.7868 | -553.0 | -442.8 | |
| 0.00 | 2.27 | 0.00 | 1.83 | -22.37 | 260.82 | -46.52 | 121.61 | 0.7901 | -473.0 | -461.8 | |
| 0.64 | 2.72 | 0.52 | 2.24 | -23.37 | 260.22 | -47.12 | 122.49 | 0.7997 | -714.4 | -578.2 | |
| 0.64 | 2.27 | 0.49 | 1.76 | -19.91 | 261.59 | -45.76 | 119.04 | 0.7727 | 347.9 | 153.8 | |
| 0.00 | 0.45 | 0.00 | 0.37 | -23.07 | 260.22 | -47.13 | 122.14 | 0.7985 | -429.0 | -446.0 | |
| 0.00 | 0.64 | 0.00 | 0.53 | -23.59 | 259.72 | -47.62 | 122.52 | 0.8050 | -342.0 | -333.0 | |
| 0.00 | 0.82 | 0.00 | 0.67 | -22.67 | 260.06 | -47.29 | 121.60 | 0.7983 | -489.0 | -431.1 | |
| 0.00 | 1.36 | 0.00 | 1.07 | -20.20 | 260.96 | -46.39 | 119.10 | 0.7799 | -583.0 | -511.7 | |
| 2.36 | -9.00 | 1.89 | -9.00 | -21.01 | 260.54 | -46.81 | 119.88 | 0.7871 | -963.1 | 999999 | |
| 4.00 | -9.00 | 3.18 | -9.00 | -20.71 | 260.57 | -46.78 | 119.54 | 0.7857 | -861.6 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.96 | -21.59 | 260.15 | -47.20 | 120.39 | 0.7931 | -727.0 | -666.3 | |
| 0.00 | 0.91 | 0.00 | 0.71 | -19.51 | 260.94 | -46.40 | 118.27 | 0.7773 | 399.0 | 343.9 | |
| 12.26 | -9.00 | 9.88 | -9.00 | -21.09 | 260.17 | -47.18 | 119.81 | 0.7909 | -784.1 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.66 | -21.47 | 259.96 | -47.38 | 120.16 | 0.7943 | -282.0 | -363.8 | |
| 3.00 | 6.08 | 2.45 | 4.97 | -21.61 | 259.65 | -47.69 | 120.20 | 0.7977 | -492.1 | -320.1 | |
| 0.00 | 1.45 | 0.00 | 1.20 | -22.06 | 259.41 | -47.94 | 120.61 | 0.8017 | -356.0 | -256.3 | |
| 0.00 | 1.09 | 0.00 | 0.90 | -21.75 | 259.44 | -47.90 | 120.27 | 0.8002 | -27.0 | -56.8 | |
| 0.00 | 2.91 | 0.00 | 2.37 | -21.18 | 259.65 | -47.70 | 119.69 | 0.7961 | -442.0 | -345.8 | |
| 0.00 | 2.82 | 0.00 | 2.32 | -21.70 | 259.17 | -48.17 | 120.09 | 0.8024 | 206.0 | 122.5 | |
| 0.00 | 5.45 | 0.00 | 4.51 | -21.51 | 258.96 | -48.38 | 119.78 | 0.8036 | 256.0 | 247.1 | |
| 0.00 | 1.54 | 0.00 | 1.26 | -20.49 | 259.40 | -47.94 | 118.78 | 0.7957 | 20.0 | -20.0 | |
| 0.00 | 1.45 | 0.00 | 1.20 | -20.87 | 258.99 | -48.35 | 119.05 | 0.8009 | 14.0 | 144.5 | |
| 0.00 | 1.00 | 0.00 | 0.85 | -21.58 | 257.98 | -49.37 | 119.45 | 0.8127 | 647.0 | 553.6 | |
| 1.09 | 2.91 | 0.96 | 2.57 | -23.58 | 256.72 | -50.63 | 121.22 | 0.8306 | -547.8 | -377.7 | |
| 65.11 | 397.86 | 55.25 | 338.49 | -19.02 | 256.83 | -50.51 | 116.03 | 0.8142 | 1009.6 | 264.0 | |
| 0.00 | 1.36 | 0.00 | 1.26 | -22.76 | 254.42 | -52.93 | 119.43 | 0.8468 | -310.0 | -329.7 | |
| 0.00 | 2.54 | 0.00 | 2.34 | -22.26 | 254.48 | -52.87 | 118.89 | 0.8448 | 98.0 | 95.0 | |
| 0.00 | 1.36 | 0.00 | 1.22 | -19.95 | 254.95 | -52.39 | 116.44 | 0.8338 | 511.0 | 336.1 | |
| 0.00 | 1.00 | 0.00 | 0.90 | -20.06 | 254.63 | -52.71 | 116.46 | 0.8369 | 60.0 | 98.9 | |
| 0.00 | 0.54 | 0.00 | 0.51 | -21.86 | 253.64 | -53.70 | 118.15 | 0.8504 | -435.0 | -398.7 | |
| 0.00 | 0.27 | 0.00 | 0.25 | -21.39 | 253.79 | -53.56 | 117.67 | 0.8478 | -328.0 | -346.3 | |
| 1.54 | 2.72 | 1.42 | 2.51 | -20.98 | 253.95 | -53.40 | 117.27 | 0.8453 | 376.0 | 396.2 | |
| 0.00 | 0.82 | 0.00 | 0.75 | -20.30 | 253.70 | -53.65 | 116.41 | 0.8455 | -478.0 | -479.0 | |
| 0.00 | 1.63 | 0.00 | 1.46 | -17.82 | 254.21 | -53.14 | 113.75 | 0.8343 | -346.0 | -341.7 | |
| 0.00 | 0.54 | 0.00 | 0.50 | -19.39 | 253.32 | -54.03 | 115.26 | 0.8462 | -588.0 | -564.7 | |
| 0.00 | 0.91 | 0.00 | 0.84 | -18.50 | 252.86 | -54.48 | 114.10 | 0.8477 | -225.0 | -210.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
