SDO HMI 2014-07-02 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.91 | 0.00 | 7.40 | -13.17 | 254.37 | -45.98 | 110.62 | 0.7492 | 262.3 | 249.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-02 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 0.58 | -13.02 | 257.71 | -42.65 | 111.69 | 0.7127 | 549.0 | 458.4 | |
| 0.00 | 0.73 | 0.00 | 0.51 | -12.67 | 257.74 | -42.62 | 111.24 | 0.7110 | 647.0 | 538.4 | |
| 0.00 | 0.82 | 0.00 | 0.58 | -12.58 | 257.46 | -42.90 | 111.01 | 0.7139 | 657.0 | 591.8 | |
| 0.00 | 0.91 | 0.00 | 0.65 | -12.71 | 256.70 | -43.65 | 110.87 | 0.7230 | 544.0 | 429.5 | |
| 0.00 | 1.36 | 0.00 | 1.00 | -12.49 | 254.90 | -45.45 | 109.90 | 0.7423 | 639.0 | 511.8 | |
| 0.00 | 3.09 | 0.00 | 2.28 | -12.74 | 254.84 | -45.51 | 110.21 | 0.7438 | 624.0 | 424.0 | |
| 0.00 | 0.36 | 0.00 | 0.29 | -15.35 | 250.89 | -49.46 | 112.08 | 0.7930 | -390.0 | -395.0 | |
| 0.00 | 0.73 | 0.00 | 0.60 | -14.29 | 249.50 | -50.85 | 110.34 | 0.8037 | -333.0 | -363.0 | |
| 0.00 | 1.09 | 0.00 | 0.91 | -14.65 | 249.29 | -51.07 | 110.70 | 0.8067 | -576.0 | -501.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
