SDO HMI 2014-07-02 15:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.49 | 158.03 | 43.95 | 158.75 | -8.06 | 239.75 | -59.50 | 101.04 | 0.8706 | 139.6 | 84.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-02 15:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.54 | 4.81 | 2.42 | 4.57 | -8.23 | 241.64 | -57.61 | 101.56 | 0.8550 | 660.2 | 536.6 | |
| 1.63 | 3.00 | 1.58 | 2.89 | -8.66 | 241.13 | -58.12 | 101.96 | 0.8601 | 643.3 | 545.2 | |
| 18.16 | 74.38 | 17.42 | 71.52 | -7.48 | 241.17 | -58.08 | 100.61 | 0.8582 | 692.0 | 308.9 | |
| 0.00 | 1.36 | 0.00 | 1.33 | -7.23 | 240.57 | -58.67 | 100.22 | 0.8631 | 266.0 | 208.9 | |
| 6.45 | 20.62 | 6.40 | 20.56 | -8.77 | 240.15 | -59.10 | 101.91 | 0.8687 | 422.2 | -62.6 | |
| 0.00 | 3.63 | 0.00 | 3.60 | -8.33 | 240.14 | -59.11 | 101.42 | 0.8682 | -30.0 | 24.7 | |
| 0.00 | 1.27 | 0.00 | 1.25 | -7.33 | 240.31 | -58.94 | 100.30 | 0.8655 | 102.0 | 123.0 | |
| 0.00 | 1.36 | 0.00 | 1.37 | -8.48 | 239.67 | -59.57 | 101.50 | 0.8723 | -230.0 | -165.9 | |
| 0.00 | 0.82 | 0.00 | 0.81 | -7.36 | 239.82 | -59.42 | 100.25 | 0.8697 | 245.0 | 174.6 | |
| 0.00 | 1.54 | 0.00 | 1.58 | -9.24 | 239.28 | -59.97 | 102.30 | 0.8765 | 229.0 | 149.5 | |
| 0.82 | 7.90 | 0.82 | 8.00 | -7.25 | 239.42 | -59.83 | 100.07 | 0.8730 | 352.0 | 56.0 | |
| 0.00 | 1.36 | 0.00 | 1.40 | -6.94 | 238.67 | -60.57 | 99.61 | 0.8788 | -401.0 | -331.5 | |
| 5.90 | 10.63 | 6.28 | 11.29 | -8.68 | 237.92 | -61.33 | 101.45 | 0.8869 | -559.0 | -377.8 | |
| 1.36 | 5.18 | 1.48 | 5.63 | -9.58 | 237.45 | -61.80 | 102.37 | 0.8915 | -639.9 | -504.9 | |
| 0.00 | 1.63 | 0.00 | 1.78 | -9.92 | 237.34 | -61.91 | 102.74 | 0.8928 | -472.0 | -415.6 | |
| 0.00 | 2.91 | 0.00 | 3.19 | -8.17 | 236.87 | -62.37 | 100.73 | 0.8944 | -667.0 | -520.7 | |
| 0.00 | 0.73 | 0.00 | 0.81 | -8.66 | 236.32 | -62.92 | 101.19 | 0.8991 | -512.0 | -435.0 | |
| 6.63 | 13.44 | 7.55 | 15.31 | -8.59 | 235.93 | -63.31 | 101.05 | 0.9019 | -444.5 | -172.2 | |
| 0.00 | 0.73 | 0.00 | 0.93 | -11.03 | 233.12 | -66.13 | 103.29 | 0.9239 | -414.0 | -342.4 | |
| 0.00 | 0.73 | 0.00 | 0.93 | -9.17 | 232.87 | -66.37 | 101.26 | 0.9238 | -152.0 | -236.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
