SDO HMI 2014-07-02 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 78.99 | 373.21 | 50.62 | 240.45 | 15.10 | 259.88 | -38.26 | 69.68 | 0.6392 | -312.1 | -96.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-02 17:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.64 | 0.00 | 0.39 | 17.78 | 265.61 | -32.53 | 62.85 | 0.5776 | -710.0 | -617.6 | |
| 0.00 | 1.00 | 0.00 | 0.60 | 14.56 | 265.18 | -32.95 | 68.42 | 0.5683 | -698.0 | -542.5 | |
| 0.00 | 1.91 | 0.00 | 1.15 | 12.44 | 264.62 | -33.52 | 72.30 | 0.5682 | -794.0 | -641.0 | |
| 0.00 | 2.27 | 0.00 | 1.36 | 12.16 | 264.58 | -33.56 | 72.79 | 0.5678 | -586.0 | -466.8 | |
| 0.00 | 1.00 | 0.00 | 0.60 | 12.83 | 264.48 | -33.66 | 71.67 | 0.5714 | -708.0 | -577.8 | |
| 0.00 | 1.09 | 0.00 | 0.69 | 19.42 | 263.03 | -35.11 | 61.76 | 0.6179 | -577.0 | -444.9 | |
| 0.00 | 1.36 | 0.00 | 0.85 | 17.20 | 263.03 | -35.11 | 65.18 | 0.6075 | -704.0 | -581.5 | |
| 1.73 | 195.59 | 1.08 | 123.11 | 15.58 | 262.32 | -35.82 | 68.07 | 0.6100 | -886.6 | -377.5 | |
| 11.62 | -8.00 | 7.31 | -8.00 | 16.16 | 261.84 | -36.30 | 67.36 | 0.6183 | -1098.7 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.67 | 12.19 | 262.34 | -35.80 | 73.54 | 0.5984 | -788.0 | -650.9 | |
| 19.79 | -8.00 | 12.45 | -8.00 | 15.68 | 261.67 | -36.47 | 68.18 | 0.6187 | -1177.5 | 999999 | |
| 2.81 | -8.00 | 1.76 | -8.00 | 14.87 | 261.79 | -36.35 | 69.40 | 0.6142 | -969.0 | 999999 | |
| 4.45 | -8.00 | 2.81 | -8.00 | 16.06 | 261.51 | -36.63 | 67.67 | 0.6221 | -751.9 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.75 | 17.18 | 261.26 | -36.88 | 66.05 | 0.6296 | -574.0 | -501.2 | |
| 0.00 | 1.27 | 0.00 | 0.81 | 16.83 | 261.26 | -36.88 | 66.58 | 0.6282 | -538.0 | -457.7 | |
| 3.27 | -8.00 | 2.06 | -8.00 | 14.99 | 261.53 | -36.61 | 69.32 | 0.6179 | -749.0 | 999999 | |
| 2.36 | -8.00 | 1.49 | -8.00 | 15.96 | 261.29 | -36.85 | 67.92 | 0.6245 | -517.0 | 999999 | |
| 0.00 | 5.27 | 0.00 | 3.26 | 11.93 | 262.03 | -36.11 | 74.06 | 0.6019 | -648.0 | -628.8 | |
| 0.00 | 1.09 | 0.00 | 0.68 | 12.39 | 261.92 | -36.22 | 73.34 | 0.6046 | -790.0 | -658.9 | |
| 0.00 | 1.54 | 0.00 | 0.99 | 17.14 | 260.99 | -37.15 | 66.23 | 0.6328 | -554.0 | -416.4 | |
| 0.00 | 0.64 | 0.00 | 0.41 | 17.01 | 260.78 | -37.36 | 66.52 | 0.6349 | -388.0 | -292.6 | |
| 1.45 | 2.81 | 0.90 | 1.74 | 10.35 | 261.94 | -36.19 | 76.67 | 0.5992 | -666.9 | -557.4 | |
| 0.00 | 1.45 | 0.00 | 0.90 | 12.20 | 261.64 | -36.50 | 73.74 | 0.6078 | -561.0 | -495.1 | |
| 0.00 | 1.00 | 0.00 | 0.64 | 16.22 | 260.60 | -37.54 | 67.80 | 0.6342 | -25.0 | -98.8 | |
| 0.00 | 0.82 | 0.00 | 0.52 | 15.96 | 260.57 | -37.57 | 68.20 | 0.6336 | -150.0 | -101.4 | |
| 0.00 | 1.91 | 0.00 | 1.23 | 17.02 | 260.13 | -38.01 | 66.78 | 0.6430 | 596.0 | 558.2 | |
| 0.00 | 2.36 | 0.00 | 1.51 | 15.14 | 260.23 | -37.91 | 69.59 | 0.6351 | -453.0 | -400.3 | |
| 0.00 | 1.27 | 0.00 | 0.81 | 14.15 | 260.39 | -37.75 | 71.07 | 0.6298 | -703.0 | -617.5 | |
| 0.00 | 2.00 | 0.00 | 1.27 | 14.42 | 260.25 | -37.88 | 70.69 | 0.6324 | -718.0 | -605.8 | |
| 0.00 | 2.09 | 0.00 | 1.32 | 12.75 | 260.56 | -37.57 | 73.19 | 0.6235 | -643.0 | -477.6 | |
| 0.00 | 0.73 | 0.00 | 0.46 | 10.88 | 260.86 | -37.27 | 76.10 | 0.6149 | -372.0 | -353.5 | |
| 0.00 | 2.00 | 0.00 | 1.28 | 15.54 | 259.98 | -38.16 | 69.08 | 0.6395 | 605.0 | 429.4 | |
| 0.00 | 1.09 | 0.00 | 0.69 | 13.43 | 260.29 | -37.85 | 72.22 | 0.6290 | -512.0 | -439.8 | |
| 0.00 | 0.82 | 0.00 | 0.52 | 14.26 | 259.97 | -38.17 | 71.04 | 0.6356 | -272.0 | -334.1 | |
| 0.00 | 5.08 | 0.00 | 3.31 | 16.49 | 259.28 | -38.86 | 67.92 | 0.6515 | 906.0 | 730.8 | |
| 0.00 | 2.45 | 0.00 | 1.59 | 15.61 | 259.15 | -38.98 | 69.28 | 0.6501 | 772.0 | 536.2 | |
| 0.00 | 1.09 | 0.00 | 0.71 | 16.23 | 258.93 | -39.21 | 68.44 | 0.6549 | 517.0 | 494.5 | |
| 0.00 | 1.73 | 0.00 | 1.11 | 14.05 | 259.24 | -38.89 | 71.60 | 0.6442 | 651.0 | 566.9 | |
| 2.09 | 6.81 | 1.36 | 4.45 | 15.47 | 258.78 | -39.36 | 69.62 | 0.6543 | 840.4 | 715.3 | |
| 0.00 | 1.00 | 0.00 | 0.66 | 16.00 | 258.65 | -39.48 | 68.88 | 0.6575 | 529.0 | 470.9 | |
| 0.00 | 0.82 | 0.00 | 0.53 | 13.48 | 259.15 | -38.99 | 72.49 | 0.6438 | -486.0 | -402.0 | |
| 0.00 | 1.18 | 0.00 | 0.77 | 14.07 | 258.99 | -39.14 | 71.65 | 0.6474 | 603.0 | 564.4 | |
| 0.00 | 1.09 | 0.00 | 0.71 | 15.06 | 258.54 | -39.60 | 70.32 | 0.6560 | 818.0 | 700.5 | |
| 0.00 | 0.91 | 0.00 | 0.60 | 15.89 | 258.22 | -39.91 | 69.19 | 0.6624 | 626.0 | 609.8 | |
| 0.00 | 1.45 | 0.00 | 0.96 | 15.20 | 258.30 | -39.84 | 70.18 | 0.6594 | 762.0 | 685.2 | |
| 0.00 | 1.18 | 0.00 | 0.78 | 16.07 | 257.85 | -40.29 | 69.06 | 0.6676 | 808.0 | 600.9 | |
| 0.00 | 1.27 | 0.00 | 0.84 | 15.82 | 257.87 | -40.27 | 69.42 | 0.6666 | 643.0 | 512.3 | |
| 4.09 | 32.78 | 2.72 | 21.95 | 16.31 | 257.58 | -40.56 | 68.80 | 0.6716 | 781.8 | 666.3 | |
| 21.61 | 41.22 | 14.19 | 27.11 | 13.45 | 258.02 | -40.12 | 72.88 | 0.6581 | -851.1 | -92.9 | |
| 2.72 | -48.00 | 1.82 | -48.00 | 15.58 | 257.30 | -40.84 | 69.96 | 0.6728 | 951.2 | 999999 | |
| 0.00 | 5.63 | 0.00 | 3.79 | 16.55 | 257.06 | -41.08 | 68.65 | 0.6786 | 655.0 | 481.8 | |
| 0.00 | 0.91 | 0.00 | 0.61 | 15.22 | 256.80 | -41.34 | 70.64 | 0.6779 | 580.0 | 547.7 | |
| 0.00 | 1.09 | 0.00 | 0.74 | 15.96 | 256.53 | -41.61 | 69.66 | 0.6832 | 349.0 | 268.0 | |
| 1.00 | 3.90 | 0.67 | 2.64 | 14.64 | 256.38 | -41.76 | 71.60 | 0.6813 | 886.5 | 716.8 | |
| 0.00 | 1.91 | 0.00 | 1.29 | 15.05 | 256.29 | -41.85 | 71.05 | 0.6836 | 590.0 | 524.1 | |
| 0.00 | 2.09 | 0.00 | 1.42 | 12.68 | 255.45 | -42.68 | 74.66 | 0.6881 | -710.0 | -552.8 | |
| 0.00 | 1.82 | 0.00 | 1.23 | 10.92 | 255.70 | -42.43 | 77.16 | 0.6818 | 567.0 | 417.1 | |
| 0.00 | 0.73 | 0.00 | 0.51 | 16.02 | 254.48 | -43.66 | 70.20 | 0.7075 | -584.0 | -472.5 | |
| 0.00 | 1.63 | 0.00 | 1.15 | 16.07 | 254.07 | -44.07 | 70.25 | 0.7124 | -614.0 | -483.2 | |
| 0.00 | 1.54 | 0.00 | 1.06 | 12.51 | 254.89 | -43.25 | 75.04 | 0.6947 | -280.0 | -249.9 | |
| 0.00 | 0.91 | 0.00 | 0.63 | 11.11 | 254.00 | -44.14 | 77.19 | 0.7030 | 463.0 | 344.2 | |
| 0.00 | 1.00 | 0.00 | 0.70 | 10.70 | 253.77 | -44.37 | 77.81 | 0.7052 | 531.0 | 454.5 | |
| 0.00 | 0.73 | 0.00 | 0.51 | 12.17 | 253.22 | -44.92 | 75.85 | 0.7141 | 468.0 | 371.6 | |
| 0.00 | 0.54 | 0.00 | 0.41 | 18.30 | 250.94 | -47.20 | 68.14 | 0.7529 | 608.0 | 560.5 | |
| 0.00 | 1.63 | 0.00 | 1.16 | 9.24 | 252.53 | -45.60 | 80.03 | 0.7183 | 612.0 | 522.4 | |
| 0.00 | 1.54 | 0.00 | 1.14 | 14.11 | 251.03 | -47.11 | 73.63 | 0.7428 | 470.0 | 393.7 | |
| 0.00 | 1.00 | 0.00 | 0.73 | 11.11 | 251.24 | -46.90 | 77.64 | 0.7357 | 631.0 | 523.0 | |
| 0.00 | 0.82 | 0.00 | 0.62 | 16.45 | 249.81 | -48.33 | 70.82 | 0.7608 | 573.0 | 470.4 | |
| 0.00 | 1.18 | 0.00 | 0.86 | 9.27 | 250.86 | -47.27 | 80.17 | 0.7381 | 562.0 | 395.7 | |
| 0.00 | 1.54 | 0.00 | 1.14 | 10.36 | 250.29 | -47.85 | 78.77 | 0.7458 | 467.0 | 408.3 | |
| 0.00 | 1.00 | 0.00 | 0.78 | 16.90 | 248.38 | -49.75 | 70.56 | 0.7767 | 607.0 | 492.1 | |
| 0.00 | 1.09 | 0.00 | 0.81 | 10.23 | 250.04 | -48.10 | 78.98 | 0.7485 | 475.0 | 355.9 | |
| 0.00 | 1.63 | 0.00 | 1.23 | 11.85 | 249.54 | -48.59 | 76.89 | 0.7560 | 433.0 | 380.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
