SDO HMI 2014-07-02 20:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 96.88 | 405.97 | 60.80 | 255.93 | 15.23 | 259.82 | -36.65 | 68.87 | 0.6191 | -332.4 | -114.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-02 20:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.82 | 0.00 | 0.49 | 15.98 | 264.59 | -31.88 | 65.48 | 0.5603 | -654.0 | -582.6 | |
| 0.00 | 0.64 | 0.00 | 0.37 | 12.25 | 264.91 | -31.57 | 71.84 | 0.5405 | -674.0 | -567.7 | |
| 0.00 | 3.00 | 0.00 | 1.76 | 12.44 | 264.77 | -31.70 | 71.57 | 0.5430 | -892.0 | -734.1 | |
| 0.00 | 1.09 | 0.00 | 0.67 | 18.44 | 263.42 | -33.05 | 62.12 | 0.5875 | -762.0 | -615.0 | |
| 0.00 | 0.91 | 0.00 | 0.54 | 15.05 | 263.85 | -32.62 | 67.44 | 0.5658 | -668.0 | -460.4 | |
| 0.00 | 1.36 | 0.00 | 0.83 | 17.38 | 262.88 | -33.59 | 64.12 | 0.5891 | -592.0 | -502.3 | |
| 0.00 | 0.82 | 0.00 | 0.50 | 17.34 | 262.35 | -34.12 | 64.48 | 0.5956 | -732.0 | -588.4 | |
| 38.95 | 222.89 | 24.01 | 137.41 | 15.87 | 261.72 | -34.75 | 67.13 | 0.5972 | -1200.3 | -385.6 | |
| 0.00 | 1.27 | 0.00 | 0.79 | 17.24 | 261.36 | -35.11 | 65.13 | 0.6077 | -695.0 | -552.9 | |
| 0.82 | 2.09 | 0.51 | 1.30 | 16.81 | 261.41 | -35.06 | 65.79 | 0.6051 | -574.8 | -385.1 | |
| 9.26 | -8.00 | 5.69 | -8.00 | 15.00 | 261.73 | -34.74 | 68.55 | 0.5936 | -998.9 | 999999 | |
| 3.81 | -8.00 | 2.36 | -8.00 | 16.43 | 261.45 | -35.02 | 66.37 | 0.6030 | -483.4 | 999999 | |
| 0.00 | 2.63 | 0.00 | 1.60 | 12.02 | 262.11 | -34.36 | 73.34 | 0.5784 | -820.0 | -608.2 | |
| 0.00 | 1.27 | 0.00 | 0.77 | 12.39 | 261.98 | -34.49 | 72.76 | 0.5813 | -712.0 | -557.8 | |
| 0.00 | 1.54 | 0.00 | 0.94 | 11.84 | 262.06 | -34.41 | 73.67 | 0.5785 | -727.0 | -511.1 | |
| 1.18 | -8.00 | 0.73 | -8.00 | 16.42 | 261.22 | -35.25 | 66.49 | 0.6059 | -268.3 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.62 | 17.14 | 261.07 | -35.40 | 65.44 | 0.6109 | -551.0 | -417.0 | |
| 0.82 | 2.63 | 0.49 | 1.59 | 10.39 | 262.06 | -34.41 | 76.15 | 0.5746 | -711.9 | -535.0 | |
| 3.36 | -8.00 | 2.09 | -8.00 | 16.23 | 261.03 | -35.44 | 66.89 | 0.6076 | -140.4 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.66 | 10.81 | 261.75 | -34.73 | 75.52 | 0.5801 | -515.0 | -372.2 | |
| 0.00 | 3.27 | 0.00 | 2.01 | 12.67 | 260.98 | -35.49 | 72.65 | 0.5956 | -900.0 | -683.2 | |
| 0.00 | 1.09 | 0.00 | 0.68 | 15.11 | 260.24 | -36.24 | 69.00 | 0.6135 | -627.0 | -512.3 | |
| 0.00 | 0.73 | 0.00 | 0.45 | 14.02 | 260.44 | -36.03 | 70.65 | 0.6071 | -539.0 | -525.2 | |
| 0.00 | 2.18 | 0.00 | 1.36 | 14.45 | 260.28 | -36.19 | 70.02 | 0.6106 | -849.0 | -676.5 | |
| 0.00 | 2.18 | 0.00 | 1.37 | 15.47 | 259.85 | -36.62 | 68.59 | 0.6198 | 402.0 | 398.2 | |
| 0.00 | 1.09 | 0.00 | 0.68 | 14.29 | 260.04 | -36.43 | 70.38 | 0.6132 | -599.0 | -367.2 | |
| 2.27 | 6.63 | 1.45 | 4.23 | 16.55 | 259.26 | -37.21 | 67.17 | 0.6313 | 860.6 | 584.8 | |
| 0.00 | 1.36 | 0.00 | 0.86 | 13.99 | 259.23 | -37.24 | 71.16 | 0.6227 | 703.0 | 641.4 | |
| 0.00 | 0.82 | 0.00 | 0.51 | 13.31 | 259.36 | -37.12 | 72.18 | 0.6190 | -628.0 | -584.6 | |
| 0.00 | 0.91 | 0.00 | 0.57 | 14.01 | 259.07 | -37.40 | 71.17 | 0.6249 | 547.0 | 548.3 | |
| 0.00 | 1.09 | 0.00 | 0.69 | 13.46 | 259.17 | -37.30 | 72.01 | 0.6219 | -539.0 | -450.4 | |
| 2.63 | 18.07 | 1.68 | 11.59 | 15.53 | 258.72 | -37.75 | 68.95 | 0.6343 | 940.1 | 640.4 | |
| 0.00 | 0.82 | 0.00 | 0.52 | 16.09 | 258.56 | -37.91 | 68.16 | 0.6383 | 671.0 | 579.1 | |
| 0.00 | 1.63 | 0.00 | 1.04 | 15.25 | 258.66 | -37.81 | 69.41 | 0.6341 | 929.0 | 755.1 | |
| 1.63 | -32.00 | 1.05 | -32.00 | 15.65 | 258.45 | -38.02 | 68.87 | 0.6381 | 727.0 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.58 | 15.03 | 258.51 | -37.96 | 69.81 | 0.6353 | 592.0 | 545.9 | |
| 0.00 | 2.27 | 0.00 | 1.45 | 14.84 | 258.43 | -38.05 | 70.13 | 0.6357 | -322.0 | -177.0 | |
| 0.00 | 4.18 | 0.00 | 2.68 | 15.08 | 258.25 | -38.22 | 69.81 | 0.6387 | 891.0 | 481.3 | |
| 0.36 | 1.36 | 0.23 | 0.88 | 15.30 | 258.17 | -38.30 | 69.52 | 0.6405 | 806.2 | 649.4 | |
| 4.45 | 10.90 | 2.90 | 7.10 | 16.28 | 257.54 | -38.93 | 68.27 | 0.6516 | 785.2 | 706.3 | |
| 20.43 | 41.04 | 13.09 | 26.35 | 13.48 | 258.05 | -38.42 | 72.33 | 0.6364 | -931.1 | -104.5 | |
| 1.91 | 7.26 | 1.24 | 4.74 | 15.58 | 257.33 | -39.14 | 69.39 | 0.6519 | 950.3 | 753.7 | |
| 0.00 | 5.27 | 0.00 | 3.42 | 15.27 | 257.40 | -39.07 | 69.83 | 0.6500 | 434.0 | 321.1 | |
| 1.82 | 3.99 | 1.19 | 2.62 | 16.49 | 257.08 | -39.39 | 68.14 | 0.6579 | 642.0 | 460.3 | |
| 0.00 | 1.82 | 0.00 | 1.19 | 15.86 | 257.19 | -39.28 | 69.03 | 0.6546 | 808.0 | 708.8 | |
| 0.00 | 1.18 | 0.00 | 0.77 | 16.05 | 257.10 | -39.37 | 68.78 | 0.6562 | 798.0 | 701.6 | |
| 0.00 | 0.73 | 0.00 | 0.48 | 16.11 | 256.96 | -39.51 | 68.75 | 0.6581 | 568.0 | 482.8 | |
| 1.82 | -42.00 | 1.19 | -42.00 | 15.60 | 256.96 | -39.51 | 69.49 | 0.6565 | 747.2 | 999999 | |
| 0.00 | 2.91 | 0.00 | 1.91 | 15.91 | 256.64 | -39.83 | 69.16 | 0.6614 | 681.0 | 620.9 | |
| 0.91 | 2.45 | 0.60 | 1.61 | 15.72 | 256.64 | -39.83 | 69.43 | 0.6608 | 713.1 | 555.8 | |
| 0.00 | 5.72 | 0.00 | 3.76 | 15.31 | 256.61 | -39.86 | 70.04 | 0.6599 | 583.0 | 655.2 | |
| 0.45 | 3.81 | 0.30 | 2.52 | 14.61 | 256.23 | -40.24 | 71.20 | 0.6626 | 877.0 | 728.3 | |
| 0.00 | 1.54 | 0.00 | 1.04 | 15.82 | 254.98 | -41.49 | 69.83 | 0.6813 | -732.0 | -552.9 | |
| 0.00 | 1.63 | 0.00 | 1.08 | 10.93 | 255.71 | -40.77 | 76.84 | 0.6607 | 672.0 | 515.4 | |
| 0.00 | 2.91 | 0.00 | 1.93 | 12.65 | 255.40 | -41.08 | 74.34 | 0.6681 | -744.0 | -547.1 | |
| 0.00 | 1.09 | 0.00 | 0.75 | 16.01 | 254.08 | -42.39 | 69.85 | 0.6926 | -678.0 | -465.7 | |
| 0.00 | 1.09 | 0.00 | 0.79 | 18.24 | 251.02 | -45.45 | 67.72 | 0.7337 | 750.0 | 514.4 | |
| 0.00 | 1.82 | 0.00 | 1.34 | 19.02 | 250.38 | -46.09 | 66.89 | 0.7428 | 558.0 | 473.2 | |
| 0.00 | 1.18 | 0.00 | 0.82 | 9.22 | 252.41 | -44.07 | 79.89 | 0.6996 | 558.0 | 422.1 | |
| 0.00 | 1.73 | 0.00 | 1.23 | 14.06 | 251.07 | -45.40 | 73.36 | 0.7232 | 583.0 | 460.8 | |
| 0.00 | 0.91 | 0.00 | 0.64 | 11.34 | 251.42 | -45.05 | 77.05 | 0.7144 | 706.0 | 584.4 | |
| 0.00 | 1.00 | 0.00 | 0.71 | 11.12 | 251.28 | -45.19 | 77.38 | 0.7156 | 741.0 | 626.5 | |
| 0.00 | 0.91 | 0.00 | 0.67 | 16.55 | 249.86 | -46.61 | 70.28 | 0.7423 | 371.0 | 417.7 | |
| 0.00 | 1.63 | 0.00 | 1.17 | 10.46 | 250.30 | -46.18 | 78.43 | 0.7265 | 536.0 | 439.3 | |
| 0.00 | 1.18 | 0.00 | 0.84 | 9.12 | 250.49 | -45.98 | 80.26 | 0.7227 | 569.0 | 440.5 | |
| 0.00 | 0.91 | 0.00 | 0.69 | 16.94 | 248.41 | -48.06 | 70.13 | 0.7589 | 585.0 | 509.0 | |
| 0.00 | 1.00 | 0.00 | 0.72 | 10.27 | 250.06 | -46.41 | 78.72 | 0.7290 | 371.0 | 310.4 | |
| 0.00 | 1.54 | 0.00 | 1.14 | 12.06 | 249.19 | -47.29 | 76.42 | 0.7415 | 437.0 | 271.4 | |
| 0.00 | 1.18 | 0.00 | 0.91 | 16.37 | 247.54 | -48.93 | 71.07 | 0.7670 | 365.0 | 322.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
