SDO HMI 2014-07-03 00:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 12.89 | 0.00 | 8.65 | -12.98 | 254.85 | -39.41 | 113.20 | 0.6743 | 243.4 | 362.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 00:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.36 | 0.00 | 1.52 | -12.65 | 257.67 | -36.59 | 114.13 | 0.6395 | 895.0 | 733.2 | |
| 0.00 | 0.45 | 0.00 | 0.29 | -12.87 | 257.63 | -36.62 | 114.44 | 0.6410 | 716.0 | 614.8 | |
| 0.00 | 1.91 | 0.00 | 1.23 | -12.37 | 257.48 | -36.77 | 113.62 | 0.6405 | 624.0 | 488.2 | |
| 0.00 | 2.27 | 0.00 | 1.51 | -13.25 | 255.58 | -38.67 | 113.90 | 0.6676 | 660.0 | 552.4 | |
| 0.00 | 1.45 | 0.00 | 0.96 | -11.90 | 255.26 | -38.99 | 111.83 | 0.6655 | 565.0 | 433.9 | |
| 0.00 | 1.00 | 0.00 | 0.67 | -11.53 | 254.36 | -39.90 | 110.88 | 0.6749 | 393.0 | 472.6 | |
| 0.00 | 1.54 | 0.00 | 1.07 | -13.76 | 252.81 | -41.45 | 113.27 | 0.7022 | 582.0 | 398.5 | |
| 0.00 | 0.64 | 0.00 | 0.46 | -14.22 | 249.86 | -44.40 | 112.60 | 0.7369 | -729.0 | -600.1 | |
| 0.00 | 0.27 | 0.00 | 0.20 | -14.87 | 249.55 | -44.70 | 113.32 | 0.7426 | -545.0 | -508.7 | |
| 0.00 | 1.00 | 0.00 | 0.74 | -14.49 | 249.48 | -44.78 | 112.80 | 0.7420 | -727.0 | -507.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
