SDO HMI 2014-07-03 01:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.72 | 22.98 | 14.17 | 25.30 | -16.09 | 232.70 | -61.00 | 109.75 | 0.8944 | -128.2 | -8.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 01:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 1.53 | -16.57 | 234.12 | -59.58 | 110.60 | 0.8849 | 502.0 | 371.3 | |
| 3.91 | 6.36 | 3.99 | 6.50 | -14.68 | 234.77 | -58.93 | 108.66 | 0.8765 | 537.8 | 288.1 | |
| 0.00 | 1.09 | 0.00 | 1.13 | -14.98 | 234.39 | -59.32 | 108.91 | 0.8801 | 260.0 | 238.2 | |
| 0.00 | 1.18 | 0.00 | 1.28 | -16.16 | 233.17 | -60.53 | 109.93 | 0.8914 | 223.0 | 133.4 | |
| 0.00 | 1.00 | 0.00 | 1.13 | -16.45 | 231.89 | -61.81 | 109.96 | 0.9012 | -510.0 | -537.6 | |
| 8.81 | 11.90 | 10.18 | 13.73 | -16.76 | 231.44 | -62.26 | 110.20 | 0.9048 | -486.2 | -340.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
