SDO HMI 2014-07-03 02:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 137.79 | 736.37 | 90.70 | 486.00 | -19.66 | 258.20 | -34.95 | 125.09 | 0.6612 | 561.4 | 200.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 02:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.91 | 0.00 | 0.55 | -20.71 | 267.43 | -25.73 | 134.46 | 0.5710 | 558.0 | 452.2 | |
| 0.00 | 0.82 | 0.00 | 0.49 | -19.45 | 266.06 | -27.09 | 131.33 | 0.5740 | 722.0 | 632.7 | |
| 0.00 | 1.00 | 0.00 | 0.63 | -23.16 | 265.15 | -28.00 | 135.30 | 0.6160 | 719.0 | 596.1 | |
| 0.00 | 1.00 | 0.00 | 0.60 | -19.11 | 265.51 | -27.65 | 130.30 | 0.5771 | 750.0 | 626.3 | |
| 0.00 | 1.18 | 0.00 | 0.74 | -23.17 | 264.58 | -28.57 | 134.78 | 0.6216 | 838.0 | 575.6 | |
| 0.00 | 1.09 | 0.00 | 0.67 | -21.24 | 264.86 | -28.29 | 132.58 | 0.6021 | 547.0 | 464.1 | |
| 0.00 | 0.91 | 0.00 | 0.59 | -24.73 | 263.62 | -29.53 | 135.79 | 0.6444 | 596.0 | 429.6 | |
| 0.00 | 1.82 | 0.00 | 1.15 | -21.37 | 262.69 | -30.46 | 130.76 | 0.6255 | 817.0 | 643.2 | |
| 5.27 | 147.33 | 3.33 | 93.75 | -21.07 | 262.65 | -30.51 | 130.33 | 0.6236 | 1000.4 | 174.0 | |
| 1.45 | -9.00 | 0.92 | -9.00 | -20.67 | 262.70 | -30.45 | 129.85 | 0.6199 | 972.9 | 999999 | |
| 0.91 | -9.00 | 0.57 | -9.00 | -20.94 | 262.52 | -30.63 | 130.06 | 0.6239 | 1097.8 | 999999 | |
| 4.18 | -9.00 | 2.64 | -9.00 | -20.81 | 262.44 | -30.71 | 129.81 | 0.6237 | 1035.5 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.04 | -26.03 | 260.68 | -32.47 | 134.79 | 0.6821 | -623.0 | -512.2 | |
| 16.17 | -9.00 | 10.28 | -9.00 | -20.92 | 262.03 | -31.12 | 129.61 | 0.6289 | 897.8 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.57 | -18.09 | 261.89 | -31.26 | 125.64 | 0.6092 | 609.0 | 522.5 | |
| 0.00 | 2.00 | 0.00 | 1.31 | -22.64 | 260.60 | -32.56 | 130.63 | 0.6567 | -711.0 | -540.0 | |
| 1.09 | 78.02 | 0.70 | 50.47 | -20.72 | 260.77 | -32.38 | 128.32 | 0.6406 | -725.1 | -539.6 | |
| 0.00 | 1.63 | 0.00 | 1.04 | -19.39 | 261.08 | -32.07 | 126.79 | 0.6276 | -626.0 | -455.7 | |
| 1.73 | 4.90 | 1.12 | 3.18 | -21.30 | 260.52 | -32.64 | 128.86 | 0.6475 | -602.0 | -359.6 | |
| 5.54 | -17.00 | 3.57 | -17.00 | -20.60 | 260.57 | -32.58 | 127.99 | 0.6418 | -1038.9 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.64 | -19.30 | 260.80 | -32.35 | 126.44 | 0.6300 | -543.0 | -294.1 | |
| 10.54 | -17.00 | 6.83 | -17.00 | -20.84 | 260.28 | -32.87 | 128.07 | 0.6466 | -934.8 | 999999 | |
| 0.91 | 3.18 | 0.60 | 2.08 | -21.75 | 259.93 | -33.22 | 128.98 | 0.6569 | -833.1 | -652.1 | |
| 1.54 | -17.00 | 1.00 | -17.00 | -20.68 | 260.13 | -33.03 | 127.74 | 0.6471 | -927.2 | 999999 | |
| 0.00 | 6.63 | 0.00 | 4.33 | -21.38 | 259.95 | -33.21 | 128.52 | 0.6540 | -634.0 | -619.9 | |
| 0.00 | 1.91 | 0.00 | 1.28 | -23.49 | 259.28 | -33.87 | 130.66 | 0.6760 | -503.0 | -332.7 | |
| 0.73 | -17.00 | 0.47 | -17.00 | -20.58 | 259.95 | -33.20 | 127.49 | 0.6482 | -799.6 | 999999 | |
| 1.45 | -17.00 | 0.95 | -17.00 | -20.85 | 259.73 | -33.42 | 127.67 | 0.6525 | -671.0 | 999999 | |
| 0.00 | 2.36 | 0.00 | 1.59 | -23.30 | 258.86 | -34.29 | 130.10 | 0.6788 | -572.0 | -479.5 | |
| 0.00 | 1.00 | 0.00 | 0.66 | -21.74 | 259.26 | -33.89 | 128.45 | 0.6636 | -474.0 | -347.7 | |
| 0.00 | 0.73 | 0.00 | 0.48 | -21.14 | 259.10 | -34.05 | 127.57 | 0.6611 | -388.0 | -299.1 | |
| 0.00 | 1.00 | 0.00 | 0.66 | -20.25 | 258.78 | -34.37 | 126.17 | 0.6584 | -673.0 | -498.4 | |
| 0.00 | 2.18 | 0.00 | 1.43 | -19.25 | 258.09 | -35.07 | 124.35 | 0.6593 | 353.0 | 242.3 | |
| 73.66 | 459.51 | 49.28 | 307.67 | -19.00 | 256.55 | -36.60 | 122.99 | 0.6744 | 1232.3 | 377.7 | |
| 12.26 | -34.00 | 8.18 | -34.00 | -18.45 | 256.49 | -36.66 | 122.22 | 0.6717 | 1283.6 | 999999 | |
| 0.36 | 2.00 | 0.26 | 1.44 | -23.60 | 253.89 | -39.26 | 127.06 | 0.7290 | -598.5 | -532.2 | |
| 0.00 | 0.73 | 0.00 | 0.50 | -17.17 | 253.76 | -39.39 | 118.89 | 0.6948 | -622.0 | -481.4 | |
| 0.00 | 0.82 | 0.00 | 0.58 | -19.55 | 252.93 | -40.23 | 121.50 | 0.7160 | -381.0 | -425.1 | |
| 0.00 | 1.27 | 0.00 | 0.88 | -18.03 | 253.32 | -39.83 | 119.77 | 0.7039 | -714.0 | -622.6 | |
| 0.00 | 1.27 | 0.00 | 0.90 | -19.29 | 252.88 | -40.27 | 121.14 | 0.7151 | -594.0 | -436.0 | |
| 0.00 | 1.00 | 0.00 | 0.70 | -18.86 | 253.01 | -40.15 | 120.66 | 0.7116 | -786.0 | -681.7 | |
| 0.00 | 1.09 | 0.00 | 0.83 | -24.29 | 250.98 | -42.17 | 126.14 | 0.7601 | -410.0 | -301.2 | |
| 0.00 | 1.54 | 0.00 | 1.08 | -18.08 | 252.81 | -40.35 | 119.55 | 0.7097 | -682.0 | -592.8 | |
| 0.00 | 1.00 | 0.00 | 0.71 | -18.88 | 252.49 | -40.66 | 120.40 | 0.7171 | -520.0 | -446.2 | |
| 0.00 | 1.09 | 0.00 | 0.78 | -19.72 | 252.11 | -41.05 | 121.24 | 0.7253 | -504.0 | -392.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
