SDO HMI 2014-07-03 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 52.51 | 414.34 | 87.04 | 705.14 | -7.85 | 219.79 | -72.26 | 99.22 | 0.9559 | 347.6 | 30.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.27 | 340.41 | 0.42 | 534.16 | -9.04 | 221.61 | -70.44 | 100.63 | 0.9482 | 390.0 | 114.8 | |
| 40.25 | -1.00 | 61.67 | -1.00 | -8.35 | 221.63 | -70.42 | 99.92 | 0.9477 | 653.0 | 999999 | |
| 1.64 | -1.00 | 2.66 | -1.00 | -8.01 | 220.54 | -71.52 | 99.43 | 0.9534 | -98.7 | 999999 | |
| 0.00 | 1.45 | 0.00 | 2.55 | -9.01 | 219.24 | -72.81 | 100.34 | 0.9604 | -225.0 | -258.7 | |
| 2.54 | -1.00 | 4.38 | -1.00 | -7.57 | 219.40 | -72.65 | 98.86 | 0.9589 | -121.0 | 999999 | |
| 1.45 | -1.00 | 2.50 | -1.00 | -7.05 | 219.31 | -72.75 | 98.31 | 0.9591 | -37.5 | 999999 | |
| 0.00 | 2.00 | 0.00 | 3.52 | -6.21 | 218.89 | -73.16 | 97.40 | 0.9607 | -394.0 | -337.3 | |
| 0.00 | 1.27 | 0.00 | 2.33 | -7.35 | 218.31 | -73.74 | 98.53 | 0.9639 | -420.0 | -378.2 | |
| 0.00 | 2.45 | 0.00 | 4.88 | -7.39 | 217.01 | -75.04 | 98.44 | 0.9697 | -283.0 | -323.9 | |
| 0.00 | 1.36 | 0.00 | 2.84 | -7.39 | 216.39 | -75.66 | 98.39 | 0.9722 | -472.0 | -451.5 | |
| 0.00 | 2.00 | 0.00 | 4.55 | -8.32 | 215.19 | -76.86 | 99.23 | 0.9772 | -284.0 | -284.4 | |
| 0.00 | 1.45 | 0.00 | 3.31 | -8.04 | 215.23 | -76.82 | 98.95 | 0.9770 | -407.0 | -350.9 | |
| 1.36 | 31.43 | 2.89 | 64.71 | -6.36 | 216.00 | -76.05 | 97.30 | 0.9734 | -602.8 | -590.5 | |
| 0.00 | 1.36 | 0.00 | 3.08 | -6.52 | 215.26 | -76.80 | 97.40 | 0.9764 | -497.0 | -465.2 | |
| 0.00 | 0.27 | 0.00 | 0.63 | -7.04 | 214.84 | -77.21 | 97.89 | 0.9780 | -501.0 | -488.3 | |
| 4.18 | 6.27 | 10.29 | 15.43 | -6.43 | 214.16 | -77.89 | 97.21 | 0.9803 | -112.7 | -35.9 | |
| 0.82 | 22.62 | 2.23 | 63.15 | -6.49 | 213.03 | -79.03 | 97.19 | 0.9840 | 82.6 | 202.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
