SDO HMI 2014-07-03 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.08 | 35.98 | 16.50 | 34.97 | -16.21 | 232.52 | -56.79 | 110.92 | 0.8617 | -87.2 | -122.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 09:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.54 | 9.99 | 4.05 | 8.94 | -14.52 | 235.36 | -53.95 | 109.77 | 0.8338 | 678.0 | 360.7 | |
| 2.45 | -1.00 | 2.21 | -1.00 | -14.50 | 235.04 | -54.27 | 109.66 | 0.8367 | 324.4 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.78 | -16.40 | 234.13 | -55.19 | 111.59 | 0.8491 | 371.0 | 282.2 | |
| 0.00 | 0.27 | 0.00 | 0.26 | -16.88 | 233.52 | -55.80 | 111.96 | 0.8554 | 273.0 | 216.3 | |
| 0.00 | 1.00 | 0.00 | 0.97 | -15.93 | 232.56 | -56.75 | 110.62 | 0.8613 | 42.0 | 100.4 | |
| 0.00 | 3.82 | 0.00 | 3.74 | -16.45 | 232.27 | -57.05 | 111.14 | 0.8648 | -558.0 | -503.5 | |
| 10.09 | 18.99 | 10.24 | 19.28 | -16.93 | 231.14 | -58.17 | 111.37 | 0.8748 | -525.3 | -222.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
