SDO HMI 2014-07-03 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 247.35 | 1334.74 | 133.74 | 722.95 | -11.20 | 268.24 | -18.88 | 127.64 | 0.4029 | 457.8 | 136.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.54 | 0.00 | 0.80 | -12.81 | 279.79 | -7.32 | 155.61 | 0.3023 | 662.0 | 591.4 | |
| 0.00 | 3.54 | 0.00 | 1.83 | -10.71 | 277.85 | -9.27 | 146.42 | 0.2874 | 884.0 | 754.9 | |
| 0.00 | 0.64 | 0.00 | 0.33 | -13.08 | 277.67 | -9.45 | 150.12 | 0.3224 | 590.0 | 418.4 | |
| 0.00 | 1.09 | 0.00 | 0.60 | -20.09 | 277.17 | -9.95 | 157.58 | 0.4272 | 889.0 | 744.2 | |
| 0.00 | 0.73 | 0.00 | 0.39 | -14.88 | 276.11 | -11.00 | 149.09 | 0.3606 | 668.0 | 570.4 | |
| 0.00 | 2.45 | 0.00 | 1.30 | -11.85 | 271.94 | -15.18 | 135.02 | 0.3640 | 884.0 | 712.3 | |
| 0.00 | 1.73 | 0.00 | 0.93 | -13.53 | 271.35 | -15.77 | 137.13 | 0.3900 | 699.0 | 501.7 | |
| 0.00 | 1.54 | 0.00 | 0.83 | -12.40 | 271.07 | -16.05 | 134.51 | 0.3803 | 913.0 | 738.2 | |
| 0.91 | 2.54 | 0.49 | 1.37 | -12.31 | 270.36 | -16.76 | 133.12 | 0.3876 | 825.1 | 629.9 | |
| 4.54 | 1075.59 | 2.42 | 581.35 | -10.52 | 270.11 | -17.01 | 129.08 | 0.3720 | 1265.7 | 109.4 | |
| 6.81 | -10.00 | 3.64 | -10.00 | -10.99 | 269.92 | -17.20 | 129.76 | 0.3792 | 1060.0 | 999999 | |
| 5.54 | 10.36 | 2.98 | 5.57 | -12.07 | 269.85 | -17.27 | 131.81 | 0.3910 | 1095.3 | 806.8 | |
| 0.00 | 1.18 | 0.00 | 0.63 | -8.80 | 270.04 | -17.08 | 125.14 | 0.3564 | -563.0 | -292.6 | |
| 1.54 | -10.00 | 0.83 | -10.00 | -12.67 | 269.71 | -17.41 | 132.74 | 0.3991 | 840.6 | 999999 | |
| 0.00 | 2.82 | 0.00 | 1.52 | -12.38 | 269.73 | -17.39 | 132.23 | 0.3958 | 671.0 | 628.3 | |
| 37.61 | -10.00 | 20.10 | -10.00 | -10.50 | 269.69 | -17.43 | 128.35 | 0.3771 | 1400.4 | 999999 | |
| 0.91 | -10.00 | 0.49 | -10.00 | -11.09 | 269.56 | -17.56 | 129.38 | 0.3847 | 703.7 | 999999 | |
| 8.72 | -10.00 | 4.71 | -10.00 | -12.20 | 269.15 | -17.96 | 130.96 | 0.4009 | 976.9 | 999999 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -13.28 | 269.04 | -18.08 | 132.81 | 0.4134 | -113.0 | -99.1 | |
| 1.36 | -10.00 | 0.74 | -10.00 | -11.80 | 268.99 | -18.13 | 129.91 | 0.3988 | 1022.5 | 999999 | |
| 39.15 | -10.00 | 20.96 | -10.00 | -9.97 | 269.04 | -18.08 | 126.23 | 0.3805 | 1390.3 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -10.82 | 268.92 | -18.20 | 127.84 | 0.3900 | 660.0 | 476.8 | |
| 3.91 | -10.00 | 2.11 | -10.00 | -11.61 | 268.80 | -18.31 | 129.26 | 0.3992 | 906.0 | 999999 | |
| 5.63 | -10.00 | 3.04 | -10.00 | -11.86 | 268.78 | -18.33 | 129.73 | 0.4019 | 803.1 | 999999 | |
| 11.90 | -10.00 | 6.45 | -10.00 | -12.24 | 268.66 | -18.46 | 130.28 | 0.4073 | 223.8 | 999999 | |
| 10.72 | -10.00 | 5.78 | -10.00 | -11.33 | 268.69 | -18.43 | 128.53 | 0.3979 | 1051.6 | 999999 | |
| 3.18 | -10.00 | 1.70 | -10.00 | -9.98 | 268.74 | -18.37 | 125.80 | 0.3844 | 1083.0 | 999999 | |
| 5.36 | -10.00 | 2.89 | -10.00 | -11.14 | 268.44 | -18.68 | 127.79 | 0.3992 | 968.9 | 999999 | |
| 2.18 | 7.81 | 1.21 | 4.33 | -15.44 | 268.05 | -19.06 | 135.06 | 0.4475 | 906.9 | 552.8 | |
| 4.63 | -10.00 | 2.51 | -10.00 | -11.81 | 268.29 | -18.82 | 128.89 | 0.4075 | 75.0 | 999999 | |
| 5.00 | -10.00 | 2.69 | -10.00 | -10.61 | 268.31 | -18.80 | 126.51 | 0.3959 | 937.7 | 999999 | |
| 1.82 | 3.82 | 1.00 | 2.09 | -13.69 | 267.71 | -19.40 | 131.56 | 0.4331 | -1091.3 | -842.4 | |
| 0.00 | 4.81 | 0.00 | 2.60 | -10.40 | 267.73 | -19.38 | 125.27 | 0.4014 | 631.0 | 535.6 | |
| 1.36 | -10.00 | 0.74 | -10.00 | -11.41 | 267.60 | -19.52 | 127.12 | 0.4124 | 687.1 | 999999 | |
| 0.00 | 2.27 | 0.00 | 1.25 | -13.95 | 267.29 | -19.83 | 131.42 | 0.4408 | -843.0 | -694.2 | |
| 0.00 | 0.91 | 0.00 | 0.49 | -10.63 | 267.52 | -19.59 | 125.43 | 0.4062 | -407.0 | -360.6 | |
| 49.14 | -10.00 | 26.92 | -10.00 | -12.65 | 267.24 | -19.88 | 128.99 | 0.4286 | -1234.4 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.58 | -7.42 | 267.48 | -19.64 | 118.34 | 0.3802 | 862.0 | 698.2 | |
| 0.00 | 1.09 | 0.00 | 0.59 | -11.17 | 267.12 | -20.00 | 125.98 | 0.4163 | -367.0 | -340.2 | |
| 0.00 | 1.45 | 0.00 | 0.79 | -9.88 | 267.11 | -20.01 | 123.34 | 0.4051 | 795.0 | 662.4 | |
| 0.00 | 1.18 | 0.00 | 0.63 | -7.70 | 267.11 | -20.01 | 118.55 | 0.3877 | 851.0 | 737.5 | |
| 0.00 | 1.00 | 0.00 | 0.54 | -7.86 | 267.07 | -20.05 | 118.86 | 0.3894 | 879.0 | 662.2 | |
| 0.91 | -10.00 | 0.50 | -10.00 | -12.50 | 266.68 | -20.43 | 127.96 | 0.4341 | -764.3 | 999999 | |
| 0.00 | 1.54 | 0.00 | 0.86 | -14.25 | 266.52 | -20.59 | 130.89 | 0.4528 | -845.0 | -689.5 | |
| 2.27 | 15.26 | 1.23 | 8.24 | -8.89 | 266.88 | -20.24 | 120.92 | 0.4001 | 1095.8 | 826.5 | |
| 0.00 | 1.18 | 0.00 | 0.64 | -8.11 | 266.92 | -20.20 | 119.25 | 0.3934 | 934.0 | 770.2 | |
| 0.00 | 2.00 | 0.00 | 1.11 | -14.70 | 266.35 | -20.77 | 131.42 | 0.4593 | -764.0 | -634.6 | |
| 3.82 | -45.00 | 2.06 | -45.00 | -8.80 | 266.72 | -20.40 | 120.53 | 0.4016 | 977.6 | 999999 | |
| 0.00 | 2.00 | 0.00 | 1.12 | -15.99 | 266.04 | -21.08 | 133.14 | 0.4757 | -840.0 | -569.6 | |
| 1.54 | 22.35 | 0.84 | 12.19 | -10.49 | 266.34 | -20.77 | 123.62 | 0.4205 | 854.2 | 112.9 | |
| 0.00 | 2.09 | 0.00 | 1.13 | -7.81 | 266.48 | -20.64 | 118.05 | 0.3974 | 913.0 | 723.0 | |
| 0.00 | 1.09 | 0.00 | 0.59 | -7.90 | 266.27 | -20.84 | 118.04 | 0.4010 | 878.0 | 712.5 | |
| 6.81 | 60.86 | 3.70 | 33.10 | -8.74 | 266.16 | -20.96 | 119.75 | 0.4089 | 982.0 | 326.9 | |
| 5.63 | 8.81 | 3.06 | 4.79 | -9.43 | 266.12 | -21.00 | 121.16 | 0.4149 | 1076.2 | 799.6 | |
| 0.00 | 1.09 | 0.00 | 0.59 | -7.84 | 266.11 | -21.00 | 117.73 | 0.4028 | 571.0 | 446.5 | |
| 0.00 | 1.27 | 0.00 | 0.69 | -7.13 | 266.08 | -21.03 | 116.09 | 0.3982 | 703.0 | 514.6 | |
| 0.00 | 1.27 | 0.00 | 0.70 | -10.28 | 265.86 | -21.26 | 122.60 | 0.4252 | -451.0 | -261.9 | |
| 0.00 | 0.91 | 0.00 | 0.50 | -9.59 | 265.87 | -21.24 | 121.21 | 0.4194 | 629.0 | 518.5 | |
| 1.45 | 38.15 | 0.80 | 20.93 | -10.50 | 265.58 | -21.54 | 122.71 | 0.4308 | 845.7 | 307.1 | |
| 0.00 | 1.54 | 0.00 | 0.84 | -7.32 | 265.78 | -21.34 | 116.20 | 0.4039 | 724.0 | 554.6 | |
| 6.45 | -53.00 | 3.52 | -53.00 | -9.28 | 265.60 | -21.52 | 120.25 | 0.4208 | 919.2 | 999999 | |
| 3.18 | -59.00 | 1.74 | -59.00 | -10.20 | 265.30 | -21.82 | 121.77 | 0.4320 | 836.3 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.76 | -12.47 | 265.11 | -22.00 | 125.90 | 0.4535 | -677.0 | -485.0 | |
| 0.00 | 3.45 | 0.00 | 1.89 | -9.48 | 265.08 | -22.03 | 120.08 | 0.4294 | 939.0 | 819.9 | |
| 1.09 | 2.00 | 0.61 | 1.12 | -13.65 | 264.66 | -22.46 | 127.47 | 0.4696 | -888.8 | -757.4 | |
| 0.64 | 2.09 | 0.35 | 1.15 | -9.83 | 264.99 | -22.12 | 120.68 | 0.4333 | 878.7 | 769.8 | |
| 0.00 | 1.73 | 0.00 | 0.98 | -15.90 | 264.37 | -22.74 | 130.88 | 0.4937 | -669.0 | -529.1 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -13.43 | 264.58 | -22.54 | 126.99 | 0.4686 | -791.0 | -618.5 | |
| 0.00 | 1.18 | 0.00 | 0.66 | -13.17 | 264.57 | -22.55 | 126.53 | 0.4665 | -781.0 | -685.8 | |
| 0.00 | 1.45 | 0.00 | 0.82 | -13.88 | 264.43 | -22.69 | 127.59 | 0.4744 | -711.0 | -539.6 | |
| 0.00 | 2.36 | 0.00 | 1.30 | -9.37 | 264.69 | -22.43 | 119.41 | 0.4339 | 878.0 | 704.5 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -15.97 | 264.06 | -23.06 | 130.61 | 0.4980 | -489.0 | -519.4 | |
| 0.00 | 6.36 | 0.00 | 3.59 | -14.39 | 264.17 | -22.95 | 128.16 | 0.4822 | -774.0 | -704.2 | |
| 0.00 | 1.54 | 0.00 | 0.88 | -15.75 | 263.67 | -23.45 | 129.80 | 0.5005 | -714.0 | -490.2 | |
| 0.00 | 2.09 | 0.00 | 1.17 | -12.65 | 264.01 | -23.10 | 124.94 | 0.4690 | -542.0 | -419.2 | |
| 1.64 | 4.91 | 0.93 | 2.78 | -14.34 | 263.77 | -23.35 | 127.60 | 0.4866 | -867.3 | -652.9 | |
| 0.00 | 1.27 | 0.00 | 0.72 | -14.73 | 263.55 | -23.57 | 128.00 | 0.4927 | -627.0 | -544.8 | |
| 0.00 | 3.18 | 0.00 | 1.74 | -4.35 | 263.12 | -24.00 | 107.18 | 0.4263 | 742.0 | 565.7 | |
| 0.00 | 2.09 | 0.00 | 1.21 | -15.79 | 262.10 | -25.02 | 128.10 | 0.5192 | -92.0 | -132.9 | |
| 0.00 | 1.09 | 0.00 | 0.61 | -8.66 | 261.12 | -26.00 | 114.64 | 0.4787 | -663.0 | -539.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
