SDO HMI 2014-07-03 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 105.12 | 481.84 | 59.73 | 273.29 | 15.40 | 260.48 | -26.64 | 63.07 | 0.4865 | -252.0 | -140.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 13:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.73 | 0.00 | 1.47 | 17.78 | 268.23 | -18.89 | 50.30 | 0.4023 | -734.0 | -561.6 | |
| 0.00 | 1.00 | 0.00 | 0.55 | 18.09 | 265.73 | -21.38 | 52.93 | 0.4362 | -828.0 | -695.2 | |
| 0.00 | 3.00 | 0.00 | 1.65 | 16.65 | 264.81 | -22.31 | 56.80 | 0.4363 | -820.0 | -644.6 | |
| 0.00 | 3.18 | 0.00 | 1.73 | 13.94 | 264.84 | -22.28 | 62.49 | 0.4166 | -904.0 | -698.5 | |
| 0.00 | 1.09 | 0.00 | 0.60 | 16.26 | 264.10 | -23.02 | 58.33 | 0.4428 | -648.0 | -542.3 | |
| 0.00 | 1.91 | 0.00 | 1.04 | 12.44 | 264.34 | -22.78 | 66.28 | 0.4147 | -985.0 | -784.8 | |
| 0.00 | 0.91 | 0.00 | 0.50 | 15.82 | 263.91 | -23.20 | 59.41 | 0.4422 | 740.0 | 574.0 | |
| 0.00 | 1.18 | 0.00 | 0.64 | 12.47 | 264.13 | -22.98 | 66.39 | 0.4178 | -866.0 | -657.5 | |
| 0.00 | 2.91 | 0.00 | 1.59 | 12.65 | 264.08 | -23.03 | 66.02 | 0.4196 | -719.0 | -599.8 | |
| 0.00 | 1.00 | 0.00 | 0.56 | 18.55 | 263.34 | -23.78 | 54.72 | 0.4701 | -661.0 | -546.5 | |
| 0.00 | 1.00 | 0.00 | 0.55 | 13.36 | 263.71 | -23.41 | 64.78 | 0.4291 | -749.0 | -553.4 | |
| 0.00 | 1.54 | 0.00 | 0.87 | 17.38 | 261.68 | -25.44 | 58.49 | 0.4828 | -634.0 | -466.8 | |
| 1.64 | 291.95 | 0.91 | 164.00 | 15.03 | 261.86 | -25.26 | 62.84 | 0.4650 | -1141.1 | -317.8 | |
| 0.73 | -13.00 | 0.41 | -13.00 | 14.84 | 261.88 | -25.23 | 63.20 | 0.4636 | -828.6 | 999999 | |
| 49.51 | -13.00 | 27.78 | -13.00 | 15.78 | 261.73 | -25.39 | 61.49 | 0.4715 | -1207.0 | 999999 | |
| 1.73 | -13.00 | 0.97 | -13.00 | 15.03 | 261.68 | -25.43 | 62.99 | 0.4674 | -934.6 | 999999 | |
| 2.36 | -13.00 | 1.33 | -13.00 | 16.34 | 261.47 | -25.64 | 60.63 | 0.4785 | -533.8 | 999999 | |
| 1.18 | -13.00 | 0.67 | -13.00 | 15.95 | 261.25 | -25.87 | 61.55 | 0.4791 | -433.6 | 999999 | |
| 0.00 | 5.63 | 0.00 | 3.13 | 12.70 | 261.64 | -25.47 | 67.77 | 0.4551 | -825.0 | -679.7 | |
| 0.00 | 1.18 | 0.00 | 0.66 | 12.29 | 261.62 | -25.50 | 68.63 | 0.4535 | -854.0 | -691.8 | |
| 0.00 | 1.64 | 0.00 | 0.91 | 12.56 | 261.21 | -25.91 | 68.34 | 0.4608 | -797.0 | -619.7 | |
| 0.00 | 2.00 | 0.00 | 1.13 | 15.62 | 260.37 | -26.74 | 62.87 | 0.4889 | 252.0 | 123.4 | |
| 4.36 | 9.99 | 2.46 | 5.65 | 14.31 | 260.41 | -26.71 | 65.37 | 0.4811 | -925.2 | -605.3 | |
| 0.00 | 1.36 | 0.00 | 0.78 | 16.65 | 260.04 | -27.07 | 61.21 | 0.4995 | 787.0 | 563.3 | |
| 0.00 | 1.00 | 0.00 | 0.56 | 12.67 | 260.46 | -26.65 | 68.60 | 0.4720 | -871.0 | -656.5 | |
| 0.00 | 2.45 | 0.00 | 1.40 | 15.58 | 259.88 | -27.24 | 63.32 | 0.4954 | 838.0 | 533.2 | |
| 0.00 | 1.27 | 0.00 | 0.73 | 16.86 | 259.47 | -27.64 | 61.27 | 0.5084 | 771.0 | 700.6 | |
| 0.00 | 3.45 | 0.00 | 1.96 | 14.86 | 259.70 | -27.42 | 64.82 | 0.4938 | -141.0 | -231.8 | |
| 0.00 | 1.73 | 0.00 | 0.98 | 15.10 | 259.59 | -27.53 | 64.42 | 0.4966 | -550.0 | -437.7 | |
| 0.00 | 1.18 | 0.00 | 0.67 | 15.57 | 259.52 | -27.59 | 63.59 | 0.5001 | 814.0 | 597.6 | |
| 2.00 | 3.54 | 1.15 | 2.04 | 16.85 | 259.22 | -27.89 | 61.47 | 0.5116 | 740.0 | 558.9 | |
| 2.00 | 40.06 | 1.15 | 23.04 | 15.46 | 258.90 | -28.22 | 64.24 | 0.5081 | 528.2 | 481.5 | |
| 0.00 | 1.18 | 0.00 | 0.68 | 16.46 | 258.74 | -28.37 | 62.52 | 0.5157 | 709.0 | 521.0 | |
| 0.00 | 0.64 | 0.00 | 0.37 | 15.86 | 258.51 | -28.61 | 63.77 | 0.5154 | 782.0 | 652.4 | |
| 1.09 | 2.91 | 0.63 | 1.69 | 16.45 | 258.20 | -28.92 | 62.93 | 0.5228 | 735.0 | 517.8 | |
| 10.17 | -32.00 | 5.86 | -32.00 | 14.98 | 258.39 | -28.73 | 65.46 | 0.5124 | 1039.7 | 999999 | |
| 0.00 | 0.64 | 0.00 | 0.37 | 16.38 | 258.10 | -29.01 | 63.11 | 0.5238 | 659.0 | 462.7 | |
| 0.00 | 3.36 | 0.00 | 1.95 | 16.10 | 258.04 | -29.08 | 63.66 | 0.5231 | 682.0 | 661.2 | |
| 0.00 | 1.27 | 0.00 | 0.74 | 15.16 | 258.07 | -29.04 | 65.33 | 0.5176 | 600.0 | 493.5 | |
| 17.08 | 26.52 | 9.81 | 15.24 | 13.55 | 258.23 | -28.89 | 68.23 | 0.5077 | -972.3 | -420.8 | |
| 0.00 | 2.82 | 0.00 | 1.64 | 16.50 | 257.75 | -29.36 | 63.14 | 0.5290 | 786.0 | 553.5 | |
| 0.00 | 1.54 | 0.00 | 0.92 | 20.09 | 257.04 | -30.08 | 57.59 | 0.5596 | -649.0 | -572.7 | |
| 0.00 | 1.64 | 0.00 | 0.95 | 15.94 | 257.77 | -29.34 | 64.13 | 0.5257 | 954.0 | 839.6 | |
| 0.00 | 3.27 | 0.00 | 1.90 | 15.31 | 257.83 | -29.28 | 65.21 | 0.5217 | 748.0 | 569.6 | |
| 0.00 | 1.27 | 0.00 | 0.74 | 15.81 | 257.65 | -29.47 | 64.44 | 0.5267 | 822.0 | 648.6 | |
| 0.00 | 0.64 | 0.00 | 0.37 | 15.62 | 257.53 | -29.58 | 64.85 | 0.5273 | 780.0 | 695.0 | |
| 1.64 | 3.00 | 0.95 | 1.75 | 15.58 | 257.21 | -29.91 | 65.13 | 0.5314 | 939.5 | 766.3 | |
| 0.00 | 2.45 | 0.00 | 1.43 | 15.79 | 257.14 | -29.98 | 64.78 | 0.5335 | 886.0 | 777.9 | |
| 0.55 | 2.27 | 0.32 | 1.33 | 16.45 | 256.88 | -30.23 | 63.80 | 0.5403 | 622.5 | 452.7 | |
| 5.45 | 19.08 | 3.20 | 11.21 | 16.07 | 256.91 | -30.21 | 64.44 | 0.5380 | 942.6 | 664.9 | |
| 3.27 | -50.00 | 1.92 | -50.00 | 15.91 | 256.61 | -30.51 | 64.92 | 0.5412 | 885.8 | 999999 | |
| 0.00 | 2.00 | 0.00 | 1.18 | 16.24 | 256.25 | -30.86 | 64.55 | 0.5475 | 521.0 | 456.6 | |
| 0.00 | 2.00 | 0.00 | 1.18 | 15.55 | 256.26 | -30.86 | 65.74 | 0.5441 | 543.0 | 486.6 | |
| 0.36 | 1.64 | 0.21 | 0.97 | 14.57 | 255.64 | -31.47 | 67.80 | 0.5479 | 804.5 | 672.3 | |
| 0.00 | 1.09 | 0.00 | 0.64 | 12.70 | 255.62 | -31.49 | 71.12 | 0.5407 | -538.0 | -495.2 | |
| 0.00 | 0.73 | 0.00 | 0.43 | 13.25 | 255.21 | -31.90 | 70.33 | 0.5484 | -784.0 | -586.0 | |
| 0.00 | 0.73 | 0.00 | 0.45 | 11.26 | 251.71 | -35.41 | 75.07 | 0.5903 | 705.0 | 625.4 | |
| 0.00 | 0.82 | 0.00 | 0.51 | 13.67 | 251.25 | -35.87 | 71.27 | 0.6033 | 599.0 | 542.3 | |
| 0.00 | 0.91 | 0.00 | 0.55 | 9.60 | 251.81 | -35.31 | 77.84 | 0.5851 | 768.0 | 620.0 | |
| 0.00 | 1.45 | 0.00 | 0.89 | 11.04 | 251.47 | -35.65 | 75.51 | 0.5930 | 641.0 | 575.4 | |
| 0.00 | 0.64 | 0.00 | 0.39 | 10.58 | 251.53 | -35.58 | 76.27 | 0.5910 | 744.0 | 587.0 | |
| 0.00 | 0.91 | 0.00 | 0.56 | 9.57 | 251.62 | -35.49 | 77.95 | 0.5876 | 591.0 | 483.0 | |
| 0.00 | 1.54 | 0.00 | 0.95 | 10.72 | 251.21 | -35.91 | 76.11 | 0.5958 | 687.0 | 611.6 | |
| 0.00 | 0.64 | 0.00 | 0.39 | 9.93 | 251.27 | -35.84 | 77.43 | 0.5932 | 752.0 | 636.6 | |
| 0.00 | 0.45 | 0.00 | 0.29 | 14.10 | 250.12 | -37.00 | 70.99 | 0.6196 | 669.0 | 564.0 | |
| 0.00 | 1.91 | 0.00 | 1.24 | 18.24 | 248.83 | -38.29 | 65.20 | 0.6505 | 616.0 | 537.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
