SDO HMI 2014-07-03 20:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 132.83 | 804.79 | 79.08 | 480.82 | -19.36 | 257.64 | -25.60 | 132.95 | 0.5590 | 713.2 | 267.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-03 20:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.36 | 0.00 | 0.77 | -20.95 | 267.78 | -15.45 | 148.52 | 0.4785 | 778.0 | 580.5 | |
| 0.00 | 2.00 | 0.00 | 1.15 | -22.68 | 267.11 | -16.13 | 149.41 | 0.5057 | 659.0 | 567.7 | |
| 0.00 | 1.18 | 0.00 | 0.68 | -22.48 | 266.99 | -16.24 | 149.02 | 0.5041 | 851.0 | 642.1 | |
| 0.00 | 0.91 | 0.00 | 0.52 | -21.55 | 265.90 | -17.33 | 146.30 | 0.5014 | 723.0 | 611.7 | |
| 0.00 | 0.91 | 0.00 | 0.51 | -19.76 | 265.30 | -17.93 | 143.16 | 0.4852 | 736.0 | 618.3 | |
| 0.00 | 1.00 | 0.00 | 0.57 | -19.96 | 265.21 | -18.03 | 143.28 | 0.4884 | 689.0 | 579.2 | |
| 0.00 | 0.82 | 0.00 | 0.46 | -19.70 | 265.10 | -18.13 | 142.78 | 0.4863 | 786.0 | 683.9 | |
| 0.00 | 0.91 | 0.00 | 0.53 | -23.24 | 264.15 | -19.09 | 145.76 | 0.5362 | 794.0 | 645.3 | |
| 0.00 | 0.54 | 0.00 | 0.31 | -20.42 | 263.68 | -19.56 | 141.67 | 0.5079 | 604.0 | 634.0 | |
| 0.00 | 1.54 | 0.00 | 0.90 | -21.84 | 262.57 | -20.67 | 141.99 | 0.5341 | 714.0 | 611.1 | |
| 12.98 | 134.19 | 7.53 | 78.15 | -20.84 | 262.58 | -20.66 | 140.73 | 0.5229 | 1094.1 | 253.1 | |
| 15.71 | -11.00 | 9.15 | -11.00 | -20.85 | 262.12 | -21.11 | 140.14 | 0.5273 | 1002.9 | 999999 | |
| 0.73 | 39.86 | 0.43 | 23.46 | -20.18 | 260.54 | -22.70 | 137.27 | 0.5358 | -1001.1 | -709.5 | |
| 0.00 | 4.63 | 0.00 | 2.74 | -21.12 | 260.32 | -22.92 | 138.24 | 0.5476 | -486.0 | -486.1 | |
| 6.99 | -13.00 | 4.11 | -13.00 | -20.52 | 260.31 | -22.93 | 137.44 | 0.5415 | -1030.1 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.52 | -18.20 | 260.65 | -22.58 | 134.63 | 0.5146 | 681.0 | 496.9 | |
| 0.00 | 4.63 | 0.00 | 2.78 | -22.41 | 259.70 | -23.54 | 139.17 | 0.5667 | -471.0 | -572.6 | |
| 0.00 | 0.54 | 0.00 | 0.32 | -21.36 | 259.88 | -23.35 | 138.05 | 0.5543 | -705.0 | -565.7 | |
| 1.82 | 4.18 | 1.08 | 2.48 | -21.13 | 259.78 | -23.46 | 137.62 | 0.5530 | -817.9 | -615.2 | |
| 0.54 | 1.82 | 0.32 | 1.08 | -20.77 | 259.59 | -23.64 | 136.93 | 0.5512 | -738.3 | -602.1 | |
| 0.00 | 1.45 | 0.00 | 0.88 | -22.72 | 259.21 | -24.03 | 138.99 | 0.5746 | -523.0 | -380.9 | |
| 0.00 | 2.18 | 0.00 | 1.30 | -20.82 | 258.94 | -24.29 | 136.24 | 0.5582 | -621.0 | -401.2 | |
| 0.00 | 1.18 | 0.00 | 0.73 | -23.41 | 257.65 | -25.59 | 138.12 | 0.5959 | -293.0 | -238.6 | |
| 0.00 | 2.09 | 0.00 | 1.23 | -17.05 | 256.92 | -26.32 | 128.72 | 0.5453 | 222.0 | 222.2 | |
| 53.84 | 572.00 | 32.28 | 343.77 | -18.92 | 256.58 | -26.66 | 131.09 | 0.5653 | 1422.8 | 393.9 | |
| 0.00 | 2.63 | 0.00 | 1.65 | -23.02 | 255.39 | -27.85 | 135.35 | 0.6139 | -622.0 | -569.6 | |
| 19.25 | -25.00 | 11.54 | -25.00 | -18.44 | 256.19 | -27.04 | 130.02 | 0.5654 | 1365.0 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.85 | -22.99 | 255.17 | -28.07 | 135.10 | 0.6158 | -776.0 | -669.5 | |
| 20.97 | -25.00 | 12.64 | -25.00 | -18.81 | 255.91 | -27.33 | 130.26 | 0.5716 | 1093.1 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.17 | -20.41 | 255.02 | -28.22 | 131.61 | 0.5949 | 684.0 | 512.1 | |
| 0.00 | 1.63 | 0.00 | 1.04 | -23.60 | 254.12 | -29.12 | 134.86 | 0.6313 | -647.0 | -580.1 | |
| 0.00 | 1.09 | 0.00 | 0.67 | -18.90 | 253.50 | -29.73 | 128.15 | 0.5988 | 328.0 | 226.1 | |
| 0.00 | 1.27 | 0.00 | 0.78 | -17.53 | 253.62 | -29.62 | 126.30 | 0.5869 | -681.0 | -557.5 | |
| 0.00 | 1.27 | 0.00 | 0.80 | -20.37 | 253.01 | -30.22 | 129.72 | 0.6157 | -866.0 | -564.0 | |
| 0.00 | 1.00 | 0.00 | 0.65 | -23.76 | 252.15 | -31.08 | 133.30 | 0.6516 | -626.0 | -513.3 | |
| 0.00 | 1.00 | 0.00 | 0.62 | -19.37 | 253.07 | -30.16 | 128.42 | 0.6072 | -727.0 | -591.4 | |
| 0.00 | 1.36 | 0.00 | 0.84 | -18.17 | 252.79 | -30.44 | 126.51 | 0.6011 | -720.0 | -601.5 | |
| 0.00 | 1.63 | 0.00 | 1.03 | -19.99 | 252.42 | -30.82 | 128.69 | 0.6191 | -724.0 | -563.1 | |
| 0.00 | 1.00 | 0.00 | 0.62 | -18.11 | 252.58 | -30.65 | 126.24 | 0.6031 | -789.0 | -631.4 | |
| 0.00 | 1.27 | 0.00 | 0.79 | -18.24 | 252.48 | -30.76 | 126.35 | 0.6052 | -459.0 | -524.2 | |
| 0.00 | 1.18 | 0.00 | 0.74 | -18.48 | 252.32 | -30.91 | 126.54 | 0.6087 | -743.0 | -632.7 | |
| 0.00 | 1.82 | 0.00 | 1.14 | -19.14 | 252.18 | -31.05 | 127.34 | 0.6151 | -475.0 | -419.5 | |
| 0.00 | 2.54 | 0.00 | 1.59 | -18.72 | 251.89 | -31.34 | 126.52 | 0.6152 | -606.0 | -581.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
