SDO HMI 2014-07-04 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 212.74 | 1183.05 | 109.13 | 607.69 | -11.70 | 268.34 | -2.77 | 169.68 | 0.2644 | 315.7 | 113.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-04 18:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.18 | 0.00 | 0.62 | -12.84 | 279.50 | 8.39 | 207.22 | 0.3123 | 684.0 | 543.2 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -11.16 | 278.29 | 7.18 | 206.27 | 0.2781 | 872.0 | 683.1 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -13.82 | 278.11 | 7.00 | 201.98 | 0.3173 | 885.0 | 809.9 | |
| 0.00 | 1.09 | 0.00 | 0.55 | -8.22 | 277.73 | 6.62 | 209.92 | 0.2298 | 912.0 | 682.7 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -13.65 | 277.60 | 6.49 | 200.71 | 0.3117 | 711.0 | 569.9 | |
| 0.00 | 1.63 | 0.00 | 0.89 | -20.15 | 277.79 | 6.68 | 195.38 | 0.4132 | 816.0 | 719.2 | |
| 0.00 | 1.91 | 0.00 | 1.04 | -20.25 | 277.66 | 6.55 | 195.04 | 0.4142 | 746.0 | 511.3 | |
| 0.00 | 1.73 | 0.00 | 0.90 | -13.55 | 277.06 | 5.95 | 199.23 | 0.3071 | 938.0 | 741.8 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -13.90 | 276.75 | 5.64 | 197.95 | 0.3110 | 817.0 | 646.0 | |
| 0.00 | 1.45 | 0.00 | 0.76 | -13.58 | 276.59 | 5.48 | 197.78 | 0.3051 | 1008.0 | 759.2 | |
| 0.00 | 0.82 | 0.00 | 0.42 | -12.77 | 272.53 | 1.42 | 185.01 | 0.2781 | 899.0 | 703.1 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -12.96 | 272.47 | 1.36 | 184.73 | 0.2812 | 823.0 | 708.5 | |
| 0.00 | 2.72 | 0.00 | 1.40 | -12.64 | 272.28 | 1.17 | 184.16 | 0.2756 | 722.0 | 541.3 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -12.70 | 272.16 | 1.05 | 183.71 | 0.2766 | 866.0 | 611.2 | |
| 0.00 | 1.36 | 0.00 | 0.71 | -14.46 | 272.10 | 0.99 | 183.14 | 0.3058 | 582.0 | 467.1 | |
| 0.00 | 1.82 | 0.00 | 0.93 | -12.51 | 271.87 | 0.76 | 182.74 | 0.2731 | 753.0 | 699.0 | |
| 0.00 | 0.73 | 0.00 | 0.37 | -12.48 | 271.59 | 0.48 | 181.74 | 0.2724 | 866.0 | 696.9 | |
| 0.00 | 2.36 | 0.00 | 1.22 | -12.54 | 271.31 | 0.20 | 180.73 | 0.2733 | 844.0 | 949.5 | |
| 0.00 | 0.82 | 0.00 | 0.42 | -12.51 | 271.00 | -0.11 | 179.60 | 0.2728 | 905.0 | 855.3 | |
| 0.00 | 4.63 | 0.00 | 2.38 | -12.42 | 270.16 | -0.95 | 176.56 | 0.2716 | 927.0 | 787.3 | |
| 0.64 | 601.80 | 0.33 | 310.38 | -12.23 | 269.91 | -1.20 | 175.61 | 0.2687 | 1042.9 | -158.3 | |
| 1.73 | -21.00 | 0.89 | -21.00 | -12.39 | 269.85 | -1.26 | 175.43 | 0.2715 | 984.1 | 999999 | |
| 1.00 | 413.39 | 0.51 | 210.63 | -10.97 | 269.86 | -1.26 | 174.99 | 0.2475 | 867.0 | 505.0 | |
| 37.95 | -23.00 | 19.36 | -23.00 | -10.50 | 269.67 | -1.44 | 174.06 | 0.2398 | 1418.5 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.56 | -13.66 | 269.49 | -1.62 | 174.61 | 0.2932 | -876.0 | -645.0 | |
| 5.99 | -21.00 | 3.08 | -21.00 | -12.07 | 269.41 | -1.70 | 173.74 | 0.2668 | 1141.6 | 999999 | |
| 0.00 | 0.91 | 0.00 | 0.47 | -11.75 | 269.41 | -1.70 | 173.61 | 0.2615 | 962.0 | 788.7 | |
| 1.54 | -21.00 | 0.79 | -21.00 | -12.23 | 269.35 | -1.76 | 173.57 | 0.2696 | 1033.8 | 999999 | |
| 11.71 | -23.00 | 5.97 | -23.00 | -10.37 | 269.15 | -1.97 | 171.84 | 0.2388 | 1347.1 | 999999 | |
| 3.81 | -21.00 | 1.96 | -21.00 | -11.94 | 269.07 | -2.04 | 172.43 | 0.2654 | 1079.2 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.57 | -15.80 | 269.00 | -2.11 | 173.80 | 0.3296 | 708.0 | 570.6 | |
| 20.61 | -23.00 | 10.50 | -23.00 | -10.06 | 268.99 | -2.12 | 171.01 | 0.2339 | 1541.7 | 999999 | |
| 2.27 | -23.00 | 1.16 | -23.00 | -10.31 | 268.96 | -2.15 | 171.04 | 0.2382 | 1305.9 | 999999 | |
| 5.63 | -21.00 | 2.89 | -21.00 | -11.66 | 268.95 | -2.16 | 171.82 | 0.2609 | 1181.4 | 999999 | |
| 2.18 | -21.00 | 1.12 | -21.00 | -12.13 | 268.85 | -2.26 | 171.73 | 0.2691 | 743.4 | 999999 | |
| 2.36 | -21.00 | 1.21 | -21.00 | -11.44 | 268.76 | -2.35 | 171.00 | 0.2577 | 1242.8 | 999999 | |
| 9.72 | -21.00 | 5.01 | -21.00 | -12.51 | 268.72 | -2.39 | 171.48 | 0.2757 | 429.8 | 999999 | |
| 0.00 | 2.81 | 0.00 | 1.46 | -13.47 | 268.65 | -2.46 | 171.73 | 0.2918 | -907.0 | -789.7 | |
| 3.90 | -23.00 | 1.99 | -23.00 | -10.21 | 268.65 | -2.46 | 169.71 | 0.2375 | 1194.9 | 999999 | |
| 9.44 | -23.00 | 4.80 | -23.00 | -9.62 | 268.66 | -2.45 | 169.26 | 0.2276 | 1314.2 | 999999 | |
| 1.73 | -21.00 | 0.88 | -21.00 | -11.50 | 268.48 | -2.63 | 169.99 | 0.2596 | 888.3 | 999999 | |
| 0.00 | 2.54 | 0.00 | 1.33 | -15.74 | 268.40 | -2.71 | 172.03 | 0.3298 | 833.0 | 689.0 | |
| 2.09 | -21.00 | 1.07 | -21.00 | -11.16 | 268.39 | -2.72 | 169.40 | 0.2541 | 1280.6 | 999999 | |
| 0.00 | 2.18 | 0.00 | 1.14 | -15.55 | 268.34 | -2.77 | 171.77 | 0.3268 | 871.0 | 726.8 | |
| 2.36 | -21.00 | 1.21 | -21.00 | -11.06 | 268.27 | -2.84 | 168.86 | 0.2529 | 1171.8 | 999999 | |
| 3.36 | 10.99 | 1.74 | 5.70 | -13.75 | 267.86 | -3.25 | 169.33 | 0.2987 | -1137.5 | -934.7 | |
| 0.91 | -46.00 | 0.47 | -46.00 | -13.94 | 267.86 | -3.25 | 169.44 | 0.3018 | -1003.3 | 999999 | |
| 6.90 | -21.00 | 3.57 | -21.00 | -12.89 | 267.75 | -3.36 | 168.37 | 0.2849 | -1423.6 | 999999 | |
| 0.00 | 1.00 | 0.00 | 0.51 | -10.91 | 267.68 | -3.43 | 166.48 | 0.2524 | 545.0 | 422.5 | |
| 4.81 | -21.00 | 2.49 | -21.00 | -13.24 | 267.55 | -3.56 | 167.99 | 0.2913 | -1117.2 | 999999 | |
| 0.00 | 1.82 | 0.00 | 0.95 | -14.39 | 267.50 | -3.61 | 168.62 | 0.3103 | -979.0 | -839.1 | |
| 0.00 | 1.63 | 0.00 | 0.85 | -14.39 | 267.25 | -3.86 | 167.85 | 0.3112 | -786.0 | -647.6 | |
| 28.15 | -21.00 | 14.55 | -21.00 | -12.86 | 267.25 | -3.86 | 166.67 | 0.2863 | -1486.4 | 999999 | |
| 4.00 | 16.52 | 2.04 | 8.45 | -10.50 | 267.28 | -3.83 | 164.55 | 0.2474 | 1027.6 | 634.9 | |
| 0.00 | 1.18 | 0.00 | 0.62 | -15.84 | 266.97 | -4.14 | 168.00 | 0.3355 | -781.0 | -600.6 | |
| 0.00 | 2.72 | 0.00 | 1.40 | -10.88 | 266.97 | -4.14 | 163.77 | 0.2551 | -406.0 | -291.6 | |
| 0.00 | 1.45 | 0.00 | 0.77 | -16.26 | 266.80 | -4.31 | 167.80 | 0.3429 | -779.0 | -602.2 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -8.59 | 266.94 | -4.17 | 160.65 | 0.2182 | 764.0 | 540.7 | |
| 21.06 | -21.00 | 10.90 | -21.00 | -12.99 | 266.84 | -4.27 | 165.44 | 0.2900 | -1252.3 | 999999 | |
| 0.00 | 1.36 | 0.00 | 0.69 | -7.48 | 266.92 | -4.19 | 158.69 | 0.2004 | 861.0 | 687.4 | |
| 2.45 | -21.00 | 1.27 | -21.00 | -12.68 | 266.78 | -4.33 | 164.96 | 0.2851 | -1134.3 | 999999 | |
| 0.00 | 0.82 | 0.00 | 0.42 | -9.22 | 266.84 | -4.28 | 161.16 | 0.2288 | 784.0 | 667.9 | |
| 0.00 | 1.54 | 0.00 | 0.79 | -10.56 | 266.72 | -4.39 | 162.50 | 0.2512 | -786.0 | -525.0 | |
| 1.27 | -21.00 | 0.66 | -21.00 | -12.58 | 266.56 | -4.55 | 164.15 | 0.2845 | -1025.7 | 999999 | |
| 7.08 | 17.25 | 3.60 | 8.77 | -8.94 | 266.56 | -4.55 | 159.61 | 0.2259 | 1185.8 | 846.5 | |
| 0.00 | 4.00 | 0.00 | 2.02 | -8.07 | 266.57 | -4.54 | 158.21 | 0.2120 | 658.0 | 795.0 | |
| 0.00 | 2.54 | 0.00 | 1.33 | -15.33 | 266.38 | -4.73 | 165.96 | 0.3295 | -718.0 | -672.3 | |
| 0.00 | 4.00 | 0.00 | 2.10 | -15.26 | 266.16 | -4.95 | 165.29 | 0.3294 | -952.0 | -824.3 | |
| 0.00 | 1.45 | 0.00 | 0.77 | -16.91 | 266.08 | -5.03 | 166.31 | 0.3559 | -861.0 | -652.2 | |
| 0.00 | 2.36 | 0.00 | 1.23 | -14.43 | 266.02 | -5.09 | 164.19 | 0.3167 | -979.0 | -764.9 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -8.60 | 266.04 | -5.07 | 156.91 | 0.2238 | 930.0 | 748.1 | |
| 0.00 | 2.36 | 0.00 | 1.20 | -9.35 | 266.00 | -5.11 | 158.01 | 0.2359 | 1143.0 | 750.3 | |
| 0.00 | 0.91 | 0.00 | 0.48 | -16.88 | 265.83 | -5.28 | 165.63 | 0.3564 | -692.0 | -570.2 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -8.75 | 265.91 | -5.20 | 156.67 | 0.2271 | 787.0 | 685.7 | |
| 0.00 | 1.27 | 0.00 | 0.65 | -10.35 | 265.89 | -5.22 | 159.12 | 0.2524 | 784.0 | 581.4 | |
| 0.00 | 1.18 | 0.00 | 0.60 | -6.86 | 265.94 | -5.17 | 152.94 | 0.1976 | 929.0 | 717.2 | |
| 0.00 | 4.09 | 0.00 | 2.12 | -13.12 | 265.61 | -5.50 | 161.66 | 0.2979 | -498.0 | -289.0 | |
| 0.00 | 1.00 | 0.00 | 0.52 | -14.50 | 265.51 | -5.60 | 162.76 | 0.3201 | -822.0 | -664.5 | |
| 2.18 | 6.08 | 1.11 | 3.10 | -9.10 | 265.41 | -5.70 | 155.33 | 0.2360 | 1055.5 | 846.6 | |
| 0.00 | 2.18 | 0.00 | 1.11 | -8.29 | 265.40 | -5.72 | 153.73 | 0.2236 | 879.0 | 588.9 | |
| 0.00 | 1.54 | 0.00 | 0.81 | -14.66 | 265.13 | -5.98 | 161.82 | 0.3246 | -908.0 | -768.0 | |
| 1.91 | 8.26 | 0.98 | 4.23 | -10.01 | 265.18 | -5.93 | 156.03 | 0.2516 | 874.0 | 608.5 | |
| 0.00 | 1.82 | 0.00 | 0.93 | -10.32 | 265.11 | -6.00 | 156.29 | 0.2569 | 648.0 | 632.9 | |
| 2.00 | -82.00 | 1.02 | -82.00 | -9.91 | 265.06 | -6.05 | 155.43 | 0.2510 | 1110.1 | 999999 | |
| 0.00 | 3.81 | 0.00 | 2.00 | -14.69 | 264.75 | -6.36 | 160.79 | 0.3272 | -820.0 | -732.7 | |
| 0.00 | 2.63 | 0.00 | 1.35 | -9.51 | 264.66 | -6.45 | 153.30 | 0.2478 | 858.0 | 745.8 | |
| 0.00 | 2.18 | 0.00 | 1.13 | -12.75 | 264.55 | -6.56 | 157.96 | 0.2982 | -1067.0 | -819.2 | |
| 0.00 | 2.45 | 0.00 | 1.29 | -15.69 | 264.33 | -6.78 | 160.68 | 0.3449 | -762.0 | -612.4 | |
| 0.00 | 1.36 | 0.00 | 0.72 | -14.89 | 264.33 | -6.78 | 159.84 | 0.3325 | -901.0 | -763.7 | |
| 0.00 | 1.54 | 0.00 | 0.81 | -15.08 | 264.29 | -6.82 | 159.94 | 0.3357 | -830.0 | -656.1 | |
| 0.00 | 1.73 | 0.00 | 0.90 | -13.35 | 264.09 | -7.02 | 157.38 | 0.3104 | -650.0 | -596.2 | |
| 0.00 | 1.45 | 0.00 | 0.77 | -15.24 | 263.74 | -7.37 | 158.66 | 0.3414 | -923.0 | -817.8 | |
| 0.00 | 1.63 | 0.00 | 0.84 | -8.46 | 262.63 | -8.48 | 144.20 | 0.2505 | -836.0 | -692.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
