SDO HMI 2014-07-05 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 31.18 | 144.80 | 16.15 | 75.26 | 11.53 | 279.80 | 15.32 | 299.95 | 0.3001 | -463.2 | -404.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-05 06:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.91 | 0.00 | 0.53 | 12.77 | 295.00 | 30.51 | 289.16 | 0.5262 | -843.0 | -637.8 | |
| 0.00 | 1.36 | 0.00 | 0.79 | 13.99 | 293.93 | 29.45 | 291.96 | 0.5164 | -747.0 | -645.3 | |
| 0.00 | 0.91 | 0.00 | 0.53 | 15.26 | 294.02 | 29.53 | 294.25 | 0.5235 | -713.0 | -539.0 | |
| 0.00 | 1.27 | 0.00 | 0.70 | 11.13 | 289.83 | 25.34 | 288.59 | 0.4449 | -681.0 | -476.5 | |
| 0.00 | 1.18 | 0.00 | 0.65 | 10.87 | 289.08 | 24.60 | 288.47 | 0.4327 | -746.0 | -491.9 | |
| 0.00 | 1.09 | 0.00 | 0.59 | 8.40 | 288.48 | 24.00 | 283.07 | 0.4147 | -538.0 | -518.3 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 11.98 | 282.00 | 17.51 | 297.48 | 0.3332 | -835.0 | -687.1 | |
| 0.00 | 1.45 | 0.00 | 0.77 | 12.99 | 282.04 | 17.55 | 300.15 | 0.3412 | -969.0 | -806.2 | |
| 0.00 | 2.27 | 0.00 | 1.19 | 12.62 | 281.98 | 17.49 | 299.25 | 0.3376 | -859.0 | -690.4 | |
| 0.00 | 3.36 | 0.00 | 1.76 | 11.45 | 281.83 | 17.34 | 296.24 | 0.3272 | -774.0 | -657.6 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 11.00 | 281.67 | 17.19 | 295.13 | 0.3218 | -858.0 | -690.9 | |
| 0.00 | 1.54 | 0.00 | 0.82 | 16.23 | 281.98 | 17.49 | 308.07 | 0.3681 | -850.0 | -712.2 | |
| 0.00 | 2.45 | 0.00 | 1.28 | 10.75 | 281.53 | 17.04 | 294.60 | 0.3180 | -903.0 | -801.3 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 10.48 | 281.48 | 16.99 | 293.85 | 0.3156 | -829.0 | -674.1 | |
| 0.00 | 0.55 | 0.00 | 0.28 | 7.82 | 280.80 | 16.31 | 286.19 | 0.2910 | -539.0 | -496.5 | |
| 0.00 | 1.09 | 0.00 | 0.57 | 9.50 | 280.85 | 16.36 | 291.61 | 0.3001 | -807.0 | -654.1 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 7.43 | 280.66 | 16.17 | 284.97 | 0.2871 | -933.0 | -747.4 | |
| 0.00 | 1.36 | 0.00 | 0.70 | 8.78 | 280.26 | 15.78 | 289.90 | 0.2870 | -622.0 | -547.1 | |
| 0.64 | 2.27 | 0.33 | 1.18 | 9.24 | 280.25 | 15.77 | 291.43 | 0.2894 | -1135.0 | -930.8 | |
| 0.00 | 1.00 | 0.00 | 0.52 | 8.36 | 279.83 | 15.34 | 288.94 | 0.2780 | -761.0 | -618.0 | |
| 24.44 | 85.86 | 12.67 | 44.49 | 10.99 | 279.89 | 15.41 | 297.47 | 0.2952 | -1203.9 | -631.8 | |
| 1.82 | -21.00 | 0.94 | -21.00 | 10.60 | 279.81 | 15.32 | 296.35 | 0.2911 | -1065.1 | 999999 | |
| 3.73 | -21.00 | 1.93 | -21.00 | 11.46 | 279.79 | 15.30 | 299.03 | 0.2971 | -976.6 | 999999 | |
| 0.00 | 1.45 | 0.00 | 0.75 | 11.32 | 278.91 | 14.43 | 299.98 | 0.2833 | -582.0 | -503.6 | |
| 0.00 | 2.00 | 0.00 | 1.04 | 12.99 | 278.62 | 14.13 | 305.49 | 0.2935 | -794.0 | -721.0 | |
| 0.00 | 2.18 | 0.00 | 1.12 | 11.76 | 278.14 | 13.65 | 302.71 | 0.2758 | -900.0 | -697.0 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 11.36 | 277.89 | 13.40 | 301.90 | 0.2689 | -948.0 | -796.6 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 12.27 | 277.30 | 12.81 | 305.91 | 0.2687 | -779.0 | -673.6 | |
| 0.00 | 0.45 | 0.00 | 0.23 | 13.22 | 277.35 | 12.86 | 308.67 | 0.2787 | 714.0 | 570.2 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 12.81 | 275.50 | 11.02 | 311.69 | 0.2506 | 728.0 | 605.1 | |
| 0.00 | 2.18 | 0.00 | 1.12 | 13.06 | 275.39 | 10.90 | 312.74 | 0.2519 | 1034.0 | 838.5 | |
| 0.00 | 0.91 | 0.00 | 0.46 | 12.42 | 275.17 | 10.68 | 311.31 | 0.2420 | 876.0 | 706.1 | |
| 0.00 | 1.36 | 0.00 | 0.70 | 13.47 | 275.18 | 10.70 | 314.47 | 0.2540 | 752.0 | 651.7 | |
| 0.00 | 3.00 | 0.00 | 1.53 | 12.88 | 275.09 | 10.61 | 312.96 | 0.2462 | 969.0 | 868.2 | |
| 0.00 | 2.18 | 0.00 | 1.11 | 12.30 | 275.00 | 10.52 | 311.35 | 0.2386 | 1044.0 | 842.0 | |
| 0.00 | 1.09 | 0.00 | 0.56 | 13.63 | 274.90 | 10.42 | 315.66 | 0.2525 | 744.0 | 538.0 | |
| 0.00 | 1.45 | 0.00 | 0.75 | 16.15 | 274.97 | 10.48 | 321.91 | 0.2845 | -875.0 | -688.9 | |
| 0.00 | 1.00 | 0.00 | 0.51 | 14.06 | 274.67 | 10.18 | 317.52 | 0.2550 | 1118.0 | 922.3 | |
| 0.00 | 1.00 | 0.00 | 0.51 | 14.50 | 274.40 | 9.91 | 319.44 | 0.2575 | 808.0 | 646.8 | |
| 0.00 | 1.73 | 0.00 | 0.88 | 11.23 | 274.02 | 9.53 | 310.43 | 0.2143 | 622.0 | 517.1 | |
| 0.00 | 0.82 | 0.00 | 0.42 | 14.82 | 274.00 | 9.51 | 321.39 | 0.2572 | 813.0 | 582.8 | |
| 0.55 | 1.91 | 0.28 | 0.98 | 15.50 | 273.94 | 9.45 | 323.24 | 0.2655 | 823.8 | 659.9 | |
| 0.00 | 0.91 | 0.00 | 0.46 | 14.42 | 273.50 | 9.02 | 321.84 | 0.2467 | 850.0 | 673.7 | |
| 0.00 | 1.27 | 0.00 | 0.65 | 16.23 | 272.69 | 8.20 | 328.56 | 0.2637 | 736.0 | 559.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
