SDO HMI 2014-07-05 10:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.81 | 121.75 | 24.45 | 116.11 | 6.20 | 203.51 | -58.78 | 84.77 | 0.8556 | -578.6 | -147.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-05 10:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.91 | 0.00 | 0.83 | 8.86 | 205.08 | -57.22 | 81.60 | 0.8418 | -429.0 | -347.3 | |
| 1.64 | 13.45 | 1.51 | 12.40 | 6.54 | 204.59 | -57.71 | 84.37 | 0.8460 | -892.3 | -534.1 | |
| 2.45 | 91.22 | 2.32 | 86.76 | 6.40 | 203.68 | -58.62 | 84.53 | 0.8543 | -566.3 | -96.7 | |
| 20.08 | -3.00 | 19.05 | -3.00 | 5.97 | 203.63 | -58.66 | 85.04 | 0.8547 | -739.6 | 999999 | |
| 1.64 | 11.72 | 1.57 | 11.24 | 6.93 | 203.22 | -59.08 | 83.92 | 0.8585 | -288.5 | -280.9 | |
| 0.00 | 0.73 | 0.00 | 0.71 | 6.69 | 202.78 | -59.52 | 84.19 | 0.8623 | 228.0 | 211.9 | |
| 0.00 | 1.27 | 0.00 | 1.41 | 6.09 | 198.68 | -63.62 | 84.86 | 0.8962 | 508.0 | 402.7 | |
| 0.00 | 2.45 | 0.00 | 2.76 | 6.40 | 198.18 | -64.11 | 84.50 | 0.9000 | 434.0 | 316.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
