SDO HMI 2014-07-06 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 33.89 | 138.46 | 25.29 | 104.06 | 6.43 | 203.56 | -48.79 | 84.45 | 0.7532 | -699.8 | -233.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-06 04:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.18 | 0.00 | 0.82 | 6.71 | 207.66 | -44.69 | 83.91 | 0.7047 | -490.0 | -385.8 | |
| 0.00 | 1.00 | 0.00 | 0.73 | 6.07 | 204.75 | -47.60 | 84.90 | 0.7395 | -371.0 | -445.1 | |
| 3.00 | 13.99 | 2.20 | 10.29 | 6.67 | 204.63 | -47.72 | 84.08 | 0.7410 | -938.9 | -557.8 | |
| 3.54 | -3.00 | 2.61 | -3.00 | 6.85 | 204.52 | -47.83 | 83.85 | 0.7424 | -799.6 | 999999 | |
| 24.62 | 105.20 | 18.42 | 78.86 | 6.27 | 203.71 | -48.64 | 84.66 | 0.7516 | -1001.1 | -226.4 | |
| 0.00 | 1.82 | 0.00 | 1.38 | 8.29 | 203.04 | -49.31 | 82.00 | 0.7599 | -490.0 | -408.9 | |
| 1.54 | 10.45 | 1.17 | 7.94 | 7.15 | 203.03 | -49.32 | 83.50 | 0.7596 | -605.8 | -360.5 | |
| 0.55 | -7.00 | 0.41 | -7.00 | 6.94 | 203.01 | -49.34 | 83.78 | 0.7597 | -495.7 | 999999 | |
| 0.64 | -7.00 | 0.48 | -7.00 | 7.05 | 202.85 | -49.50 | 83.63 | 0.7615 | -346.9 | 999999 | |
| 0.00 | 1.09 | 0.00 | 0.91 | 7.08 | 198.67 | -53.68 | 83.72 | 0.8066 | 523.0 | 419.3 | |
| 0.00 | 1.82 | 0.00 | 1.51 | 6.78 | 198.72 | -53.63 | 84.10 | 0.8060 | 607.0 | 515.2 | |
| 0.00 | 1.27 | 0.00 | 1.06 | 6.40 | 198.47 | -53.88 | 84.57 | 0.8086 | 350.0 | 285.3 | |
| 0.00 | 0.64 | 0.00 | 0.56 | 7.02 | 196.81 | -55.53 | 83.82 | 0.8252 | 390.0 | 315.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
