SDO HMI 2014-07-06 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.36 | 44.89 | 8.80 | 34.57 | -12.71 | 298.30 | 47.60 | 250.22 | 0.7676 | 15.5 | 79.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-07-06 07:00:40 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.36 | 22.99 | 5.78 | 18.04 | -12.91 | 299.21 | 48.51 | 250.28 | 0.7779 | 774.1 | 548.4 | |
| 0.00 | 1.27 | 0.00 | 0.99 | -12.76 | 298.56 | 47.86 | 250.25 | 0.7706 | 350.0 | 380.8 | |
| 0.00 | 0.82 | 0.00 | 0.63 | -13.71 | 297.92 | 47.22 | 248.83 | 0.7669 | -241.0 | -151.9 | |
| 1.09 | 7.36 | 0.82 | 5.54 | -11.88 | 297.38 | 46.68 | 250.96 | 0.7554 | -613.2 | -509.9 | |
| 0.00 | 1.36 | 0.00 | 1.05 | -14.02 | 297.82 | 47.11 | 248.40 | 0.7668 | -203.0 | -166.6 | |
| 2.27 | 4.09 | 1.72 | 3.10 | -12.80 | 297.41 | 46.71 | 249.80 | 0.7586 | -392.3 | -287.1 | |
| 0.00 | 1.00 | 0.00 | 0.75 | -11.65 | 297.15 | 46.45 | 251.18 | 0.7522 | -551.0 | -477.7 | |
| 0.00 | 1.09 | 0.00 | 0.82 | -12.08 | 296.97 | 46.27 | 250.56 | 0.7516 | -586.0 | -524.2 | |
| 0.64 | 2.00 | 0.48 | 1.51 | -13.49 | 297.17 | 46.47 | 248.84 | 0.7582 | -474.0 | -408.8 | |
| 0.00 | 0.55 | 0.00 | 0.40 | -12.09 | 296.34 | 45.64 | 250.33 | 0.7447 | -614.0 | -469.3 | |
| 0.00 | 2.36 | 0.00 | 1.74 | -12.14 | 296.13 | 45.43 | 250.18 | 0.7426 | -490.0 | -337.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
